Intel® Cyclone® 10 GX Transceiver PHY User Guide

ID 683054
Date 4/14/2023
Document Table of Contents Recommended Reset Sequence

How to Enable Model 1

Choose the Intel® Cyclone® 10 GX Default Settings for the Transceiver PHY Reset Controller IP. This populates the reset duration fields with the correct values required by the transceiver reset sequencer (TRS).

Figure 147.  Cyclone® 10 GX Default Settings Preset
Figure 148. Transmitter and Receiver Reset Sequence
