6.3.1. BCAM Flush Operations

You can use the flush operation to remove all entries from the BCAM database or to initialize the table memory after a reset.

To perform a flush operation, follow these steps in the AXI-Lite interface:

  1. Write to the mgmt_ctrl register, specifying op_type = 0x0.
  2. Poll the mgmt_ctrl register until the busy bit = 0x0.
The time taken for a flush operation varies depending on the memory configuration, but will be less than max[100, MAX_ENTRIES] cycles. The following waveforms illustrate a BCAM flush operation, where the address of mgmt_ctrl register is 0xb0, due to CSR_BASEADDR + CSR_ADDROFF + offset -> 0 + 0x60 + 0x50 = 0xB0.
Figure 27. Flush Operation on BCAM
