Vertical Segment
Server
Processor Number
4514Y
Lithography
Intel 7
Recommended Customer Price
$780.00-$790.00
Use Conditions
Server/Enterprise

CPU Specifications

Total Cores
16
Total Threads
32
Max Turbo Frequency
3.4 GHz
Processor Base Frequency
2 GHz
Cache
30 MB
Intel® UPI Speed
16 GT/s
Max # of UPI Links
2
TDP
150 W

Intel® Speed Select Technology - Performance Profile (Intel® SST-PP)

ConfigActive CoresBase FrequencyTDPDescription
4514Y (0)162.0150
4514Y (1)122.1135
4514Y (2)82.6135

Supplemental Information

Marketing Status
Launched
Launch Date
Q4'23
Servicing Status
Baseline Servicing
Embedded Options Available
Yes

Memory Specifications

Max Memory Size (dependent on memory type)
4 TB
Memory Types
Up to DDR5 4400 MT/s (1DPC & 2DPC)
Max # of Memory Channels
8
ECC Memory Supported
Yes

Expansion Options

Scalability
2S
PCI Express Revision
5.0
Max # of PCI Express Lanes
80

Package Specifications

Sockets Supported
FCLGA4677
Package Carrier
E1B
DTS Max
90 °C
TCASE
79
Package Size
77.5mm x 56.5mm

Intel® On Demand Available Upgrades

Activation ModelQATDLBDSAIAASGX512
SGX 512GB512
Analytics Suite 11
Intel® Virtual RAID on CPU (Intel® VROC) Activation Options
VROC RAID1 Only, VROC Standard, VROC Premium

Advanced Technologies

Intel® On Demand Activation Model
Yes
Intel® Data Streaming Accelerator (DSA)
1 default devices
Intel® Advanced Matrix Extensions (AMX)
Yes
Intel® Speed Select Technology – Core Power
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
High Priority Cores
NA
Intel® Resource Director Technology (Intel® RDT)
Yes
Intel® Speed Shift Technology
Yes
Intel® Turbo Boost Technology
2.0
Intel® Hyper-Threading Technology
Yes
Intel® Transactional Synchronization Extensions
Yes
Intel® 64
Yes
Instruction Set Extensions
Intel® AMX, Intel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512
# of AVX-512 FMA Units
2
Intel® Volume Management Device (VMD)
Yes

Security & Reliability

Intel® Trust Domain Extensions (Intel® TDX)
Yes
Intel® Crypto Acceleration
Yes
Intel® QuickAssist Software Acceleration
Yes
Intel® Platform Firmware Resilience Support
Yes
Intel® Control-Flow Enforcement Technology
Yes
Intel® Total Memory Encryption - Multi Key
Yes
Intel® Total Memory Encryption
Yes
Intel® AES New Instructions
Yes
Intel® Software Guard Extensions (Intel® SGX)
Yes with Intel® SPS
Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX
64 GB
Intel® OS Guard
Yes
Intel® Trusted Execution Technology
Yes
Execute Disable Bit
Yes
Intel® Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intel® Virtualization Technology (VT-x)
Yes
Intel® Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
