Vertical Segment
Server
Processor Number
3508U
Lithography
Intel 7
Recommended Customer Price
$415.00-$425.00
Use Conditions
Server/Enterprise

CPU Specifications

Total Cores
8
Total Threads
8
Max Turbo Frequency
2.2 GHz
Processor Base Frequency
2.10 GHz
Cache
22.5 MB
Intel® UPI Speed
0 GT/s
Max # of UPI Links
0
TDP
125 W

Intel® Speed Select Technology - Performance Profile (Intel® SST-PP)

Supplemental Information

Marketing Status
Launched
Launch Date
Q4'23
Servicing Status
Baseline Servicing
Embedded Options Available
Yes

Memory Specifications

Max Memory Size (dependent on memory type)
4 TB
Memory Types
DDR5 @ 4400 MT/s (1 DPC &2DPC)
Max # of Memory Channels
8
ECC Memory Supported
Yes

Expansion Options

Scalability
1S Only
PCI Express Revision
5
Max # of PCI Express Lanes
80

Package Specifications

Sockets Supported
FCLGA4677
Package Carrier
E1B
DTS Max
98 °C
TCASE
83

Intel® On Demand Available Upgrades

Advanced Technologies

Intel® Data Streaming Accelerator (DSA)
1 default devices
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Resource Director Technology (Intel® RDT)
Yes
Intel® Speed Shift Technology
Yes
Intel® Turbo Boost Technology
2.0
Intel® Transactional Synchronization Extensions
Yes
Intel® 64
Yes
Instruction Set Extensions
Intel® AMX, Intel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512
# of AVX-512 FMA Units
1
Intel® Volume Management Device (VMD)
Yes

Security & Reliability

Intel® Trust Domain Extensions (Intel® TDX)
No
Intel® Crypto Acceleration
Yes
Intel® QuickAssist Software Acceleration
Yes
Intel® Platform Firmware Resilience Support
Yes
Intel® Control-Flow Enforcement Technology
Yes
Intel® Total Memory Encryption - Multi Key
Yes
Intel® Total Memory Encryption
Yes
Intel® AES New Instructions
Yes
Intel® Software Guard Extensions (Intel® SGX)
Yes with Intel® SPS
Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX
64 GB
Intel® OS Guard
Yes
Intel® Trusted Execution Technology
Yes
Execute Disable Bit
Yes
Intel® Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intel® Virtualization Technology (VT-x)
Yes
Intel® Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
