Intel® Xeon® CPU Max 9460 Processor (97.5M Cache, 2.20 GHz)
Essentials
|
Product Collection
|
|
|---|---|
|
Code Name
|
|
|
Vertical Segment
|
Server
|
|
Processor Number
|
9460
|
|
Lithography
|
Intel 7
|
|
Recommended Customer Price
|
$8750.00
|
CPU Specifications
|
Total Cores
|
40
|
|---|---|
|
Total Threads
|
80
|
|
Max Turbo Frequency
|
3.50 GHz
|
|
Processor Base Frequency
|
2.20 GHz
|
|
Cache
|
97.5 MB
|
|
Intel® UPI Speed
|
16 GT/s
|
|
Max # of UPI Links
|
3
|
|
TDP
|
350 W
|
Supplemental Information
|
Marketing Status
|
Launched
|
|---|---|
|
Launch Date
|
Q1'23
|
|
Servicing Status
|
Baseline Servicing
|
|
Embedded Options Available
|
No
|
|
Use Conditions
|
Server/Enterprise
|
Memory Specifications
|
Max Memory Size (dependent on memory type)
|
4 TB
|
|---|---|
|
Memory Types
|
Up to DDR5 4800 MT/s 1DPC
Up to DDR5 4400 MT/s 2DPC |
|
Max # of Memory Channels
|
8
|
|
Maximum High Bandwidth Memory (HBM)†
|
64 GB
|
|
ECC Memory Supported ‡
|
Yes
|
Expansion Options
|
Scalability
|
2S
|
|---|---|
|
PCI Express Revision
|
5.0
|
|
Max # of PCI Express Lanes
|
80
|
Package Specifications
|
Sockets Supported
|
FCLGA4677
|
|---|---|
|
Package Carrier
|
E1C
|
|
DTS Max
|
97 °C
|
|
TCASE
|
77°C
|
|
Package Size
|
100mm x 56.5mm
|
Advanced Technologies
|
Intel® Data Streaming Accelerator (DSA)
|
4 default devices
|
|---|---|
|
Intel® Advanced Matrix Extensions (AMX)
|
Yes
|
|
Intel® Speed Select Technology – Core Power
|
Yes
|
|
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
|
Yes
|
|
Intel® Resource Director Technology (Intel® RDT)
|
Yes
|
|
Intel® Speed Shift Technology
|
Yes
|
|
Intel® Turbo Boost Technology ‡
|
2.0
|
|
Intel® Hyper-Threading Technology ‡
|
Yes
|
|
Intel® Transactional Synchronization Extensions
|
Yes
|
|
Intel® 64 ‡
|
Yes
|
|
Instruction Set Extensions
|
Intel® AMX, Intel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512
|
|
# of AVX-512 FMA Units
|
2
|
Security & Reliability
|
Intel® Crypto Acceleration
|
Yes
|
|---|---|
|
Intel® Platform Firmware Resilience Support
|
Yes
|
|
Intel® Control-Flow Enforcement Technology
|
Yes
|
|
Intel® Total Memory Encryption
|
Yes
|
|
Intel® AES New Instructions
|
Yes
|
|
Intel® Software Guard Extensions (Intel® SGX)
|
Yes with Intel® SPS
|
|
Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX
|
128 GB
|
|
Intel® OS Guard
|
Yes
|
|
Intel® Trusted Execution Technology ‡
|
Yes
|
|
Execute Disable Bit ‡
|
Yes
|
|
Intel® Boot Guard
|
Yes
|
|
Intel® Run Sure Technology
|
Yes
|
|
Mode-based Execute Control (MBEC)
|
Yes
|
|
Intel® Virtualization Technology (VT-x) ‡
|
Yes
|
|
Intel® Virtualization Technology for Directed I/O (VT-d) ‡
|
Yes
|
|
Intel® VT-x with Extended Page Tables (EPT) ‡
|
Yes
|
