14. Duplex and Dual Simplex PHY Modes ( Agilex™ 5 Designs Only)

For designs with supported HSSI IP targeting Agilex™ 5 FPGAs only, you can generate either a Duplex PHY or a Dual Simplex PHY. If your board layout is Duplex-capable, instantiate a Duplex PHY to simplify your design. This eliminates the need for the DS tool and its complex workflow.

When you generate a duplex mode design example, a single transceiver core appears in the top-level Verilog of the design example, as shown below:
The DS tool is grayed out because the design does not include any simplex IPs.
Figure 61. Dual Simplex (DS) Assignment Editor
