?tpqrt2

Computes a QR factorization of a real or complex “triangular-pentagonal” matrix, which is composed of a triangular block and a pentagonal block, using the compact WY representation for Q.

Syntax

call stpqrt2 ( m , n , l , a , lda , b , ldb , t , ldt , info )

call dtpqrt2 ( m , n , l , a , lda , b , ldb , t , ldt , info )

call ctpqrt2 ( m , n , l , a , lda , b , ldb , t , ldt , info )

call ztpqrt2 ( m , n , l , a , lda , b , ldb , t , ldt , info )

call tpqrt2 ( a , b , t [ , info ] )

Include Files

mkl.fi , mkl_lapack.f90

Description

stpqrt dtpqrt ctpqrt ztpqrt tpqrt

The input matrix C is an ( n + m )-by- n matrix

where A is an n -by- n upper triangular matrix, and B is an m -by- n pentagonal matrix consisting of an ( m - l )-by- n rectangular matrix B1 on top of an l -by- n upper trapezoidal matrix B2 :

The upper trapezoidal matrix B2 consists of the first l rows of an n -by- n upper triangular matrix, where 0 ≤ l ≤ min( m , n ). If l =0, B is an m -by- n rectangular matrix. If m = l = n , B is upper triangular. The matrix W contains the elementary reflectors H(i) in the i th column below the diagonal (of A ) in the ( n + m )-by- n input matrix C so that W can be represented as

Thus, V contains all of the information needed for W , and is returned in array b .

NOTE:

V has the same form as B :

The columns of V represent the vectors which define the H(i) s.

The ( m + n )-by-( m + n ) block reflector H is then given by

H = I - W*T*W^{T} for real flavors, and

H = I - W*T*W^{H} for complex flavors

where W^T is the transpose of W , W^H is the conjugate transpose of W , and T is the upper triangular factor of the block reflector.

Input Parameters

m

INTEGER . The total number of rows in the matrix B ( m ≥ 0).

n

INTEGER . The number of columns in B and the order of the triangular matrix A ( n ≥ 0).

l

INTEGER . The number of rows of the upper trapezoidal part of B (min( m , n ) ≥ l ≥ 0).

a , b

REAL for stpqrt2 DOUBLE PRECISION for dtpqrt2 COMPLEX for ctpqrt2 COMPLEX*16 for ztpqrt2 .

Arrays: a , size ( lda , n ) contains the n -by- n upper triangular matrix A .

b , size ( ldb , n ) , the pentagonal m -by- n matrix B . The first ( m - l ) rows contain the rectangular B1 matrix, and the next l rows contain the upper trapezoidal B2 matrix.

lda

INTEGER . The leading dimension of a ; at least max(1, n ).

ldb

INTEGER . The leading dimension of b ; at least max(1, m ) .

ldt

INTEGER . The leading dimension of t ; at least max(1, n ).

Output Parameters

a

The elements on and above the diagonal of the array contain the upper triangular matrix R .

b

The pentagonal matrix V .

t

REAL for stpqrt2 DOUBLE PRECISION for dtpqrt2 COMPLEX for ctpqrt2 COMPLEX*16 for ztpqrt2 .

Array, size ( ldt , n ) .

The upper n -by- n upper triangular factor T of the block reflector.

info

INTEGER .

If info = 0, the execution is successful.
If info < 0 and info = -i , the i th argument had an illegal value.
If info = -1011 , memory allocation error occurred.

Return Values

No return value, info is an Output Parameter.
