Intel® FPGAs and SoC FPGAs
Intel® FPGAs offer a wide variety of configurable embedded SRAM, high-speed transceivers, high-speed I/Os, logic blocks, and routing. Built-in intellectual property (IP) combined with outstanding software tools lower FPGA development time, power, and cost.
Intel® FPGAs and SoC FPGAs
Resources to Help You Get Started Today
FPGA Design Software, Tools, Intel® Quartus® Prime Software
Intel provides a complete suite of development tools for every stage of your design.
Intel® FPGA Intellectual Property
The Intel® FPGA Intellectual Property (IP) portfolio covers a wide variety of applications with their combination of soft and hardened IP cores along with reference designs.
Intel® FPGA Development Kits
Intel and its partners offer a large selection of development kits to accelerate your FPGA design process.
FPGA Platforms: SmartNICs and Infrastructure Processing Units
Intel® FPGA acceleration boards and platforms include SmartNICs and Infrastructure Processing Units (IPUs).
Download FPGA Product Catalog
Intel® SoC FPGA Ecosystem
Intel® SoC FPGAs are ARM processor-based and inherit the strength of the ARM eco-system. Intel, our ecosystem partners, and the Intel® SoC FPGA user community provide a wide range of options to meet your SoC FPGA development needs.
More FPGA Support Resources
Check out other resources to learn how to use/design with FPGAs.
Frequently Asked Questions About Intel® FPGAs & SoC FPGAs
FPGA or field programmable gate array is a semiconductor integrated circuit with customized electrical functionality to accelerate key workloads.
FPGA is a semiconductor IC where the design engineer can change most of the electrical functionality inside the device during the PCB assembly process or even after the equipment has been shipped to customers out in the ‘field.’
SoC FPGA devices integrate both processor and FPGA architectures into a single device.
Integrating the high-level management functionality of processors and the stringent, real-time operations, extreme data processing, or interface functions of an FPGA (Field Programmable Gate Array) into a single device forms an even more powerful embedded computing platform.
Consequently, they provide higher integration, lower power, small board size, and higher bandwidth communication between the processor and FPGA. They also include a rich set of peripherals, on-chip memory, an FPGA-style logic array, and high-speed transceivers.
Flexibility
FPGA functionality can change upon every power-up of the device.
Acceleration
Get products to market quickly and increase your system performance.
Integration
Today’s FPGAs include chiplet-based heterogenous integration, on-die processors, transceivers, RAM blocks, digital signal processor (DSP) engines, and more.
Total Cost of Ownership (TCO)
While ASICs may cost less per unit than an equivalent FPGA, building them requires a non-recurring expense (NRE), expensive software tools, specialized design teams, and long manufacturing cycles.
Intel is committed to supporting a long life cycle for its FPGA product families until 2035 (except for HBM2-based devices of Intel® Stratix® 10 FPGA variants: MX, NX, DX, along with Configuration Devices [EPCQ-A]). With extended product longevity mitigating the risk of obsolescence and minimizing the cost of redesigns, customers will have peace of mind designing with our products.
In the event of unforeseen supply disruption, such as vendor discontinuance, change in government regulations, or production tools obsolescence, Intel will inform its customers.

Subscribe to the Intel® FPGA Newsletter
Do you want the latest info about Intel® FPGAs, programmable accelerators, development flows, and solutions? Looking for hot tips on training and tools? Fill out your details to subscribe to the Intel Inside Edge Monthly Newsletter.
