Developer Reference for Intel® oneAPI Math Kernel Library for C
?ggrqf
Computes the generalized RQ factorization of two matrices.
Syntax
lapack_intLAPACKE_sggrqf ( intmatrix_layout , lapack_intm , lapack_intp , lapack_intn , float*a , lapack_intlda , float*taua , float*b , lapack_intldb , float*taub );
lapack_intLAPACKE_dggrqf ( intmatrix_layout , lapack_intm , lapack_intp , lapack_intn , double*a , lapack_intlda , double*taua , double*b , lapack_intldb , double*taub );
lapack_intLAPACKE_cggrqf ( intmatrix_layout , lapack_intm , lapack_intp , lapack_intn , lapack_complex_float*a , lapack_intlda , lapack_complex_float*taua , lapack_complex_float*b , lapack_intldb , lapack_complex_float*taub );
lapack_intLAPACKE_zggrqf ( intmatrix_layout , lapack_intm , lapack_intp , lapack_intn , lapack_complex_double*a , lapack_intlda , lapack_complex_double*taua , lapack_complex_double*b , lapack_intldb , lapack_complex_double*taub );
Include Files
mkl.h
Description
sggrqf dggrqf cggrqf zggrqf ggrqf
The routine forms the generalized RQ factorization of an m -by- n matrix A and an p -by- n matrix B as A = R*Q , B = Z*T*Q , where Q is an n -by- n orthogonal/unitary matrix, Z is a p -by- p orthogonal/unitary matrix, and R and T assume one of the forms:
or
where R11 or R21 is upper triangular, and
or
where T11 is upper triangular.
In particular, if B is square and nonsingular, the GRQ factorization of A and B implicitly gives the RQ factorization of A * B-1 as:
A*B^{-1} = (R*T^{-1})*Z^{T} (for real flavors) or A*B^{-1} = (R*T^{-1})*Z^{H} (for complex flavors).
Input Parameters
- matrix_layout
-
Specifies whether matrix storage layout is row major ( LAPACK_ROW_MAJOR ) or column major ( LAPACK_COL_MAJOR ).
m
The number of rows of the matrix A ( m≥ 0 ).
p
The number of rows in B ( p≥ 0 ).
n
The number of columns of the matrices A and B ( n≥ 0 ).
- a , b , work
-
REAL for sggrqf DOUBLE PRECISION for dggrqf COMPLEX for cggrqf DOUBLE COMPLEX for zggrqf . Arrays:
a (size max(1, lda * n ) for column major layout and max(1, lda * m ) for row major layout) contains the m -by- n matrix A .
The second dimension of a must be at least max(1, n ).
b (size max(1, ldb * n ) for column major layout and max(1, ldb * p ) for row major layout) contains the p -by- n matrix B .
The second dimension of b must be at least max(1, n ). work is a workspace array, its dimension max(1, lwork) .
lda
The leading dimension of a ; at least max(1, m ) for column major layout and max(1, n ) for row major layout .
ldb
The leading dimension of b ; at least max(1, p ) for column major layout and max(1, n ) for row major layout .
lwork
The size of the work array; must be at least max(1, n , m , p ).
If lwork = -1 , then a workspace query is assumed; the routine only calculates the optimal size of the work array, returns this value as the first entry of the work array, and no error message related to lwork is issued by xerbla . See Application Notes for the suggested value of lwork .
Output Parameters
- a , b
-
Overwritten by the factorization data as follows: on exit, if m ≤ n , the upper triangle of the subarray a (1: m , n - m +1: n ) contains the m -by- m upper triangular matrix R ; on exit, if m ≤ n , element Ri j (1<= i ≤ j ≤ m ) of upper triangular matrix R is stored in a[(i - 1) + (n - m + j - 1)*lda] for column major layout and in a[(i - 1)*lda + (n - m + j - 1)] for row major layout. if m > n , the elements on and above the ( m - n )th subdiagonal contain the m -by- n upper trapezoidal matrix R ; the remaining elements, with the array taua , represent the orthogonal/unitary matrix Q as a product of elementary reflectors. The elements on and above the diagonal of the array b contain the min( p , n )-by- n upper trapezoidal matrix T ( T is upper triangular if p≥n ); the elements below the diagonal, with the array taub , represent the orthogonal/unitary matrix Z as a product of elementary reflectors.
- taua , taub
-
REAL for sggrqf DOUBLE PRECISION for dggrqf COMPLEX for cggrqf DOUBLE COMPLEX for zggrqf . Arrays, size at least max (1, min( m , n )) for taua and at least max (1, min( p , n )) for taub . The array taua contains the scalar factors of the elementary reflectors which represent the orthogonal/unitary matrix Q . The array taub contains the scalar factors of the elementary reflectors which represent the orthogonal/unitary matrix Z .
- work(1)
-
If info = 0 , on exit work(1) contains the minimum value of lwork required for optimum performance. Use this lwork for subsequent runs.
Return Values
This function returns a value info .
If info=0 , the execution is successful.
If info = -i , the i -th parameter had an illegal value.
LAPACK 95 Interface Notes
There exist FORTRAN 77 and FORTRAN 95 interfaces for this routine. See the Intel® oneMKL Fortran Developer Reference for details.
Application Notes
The matrix \(Q\) is represented as a product of elementary reflectors
\(Q = H(1) H(2) \cdots H(k)\) , where k = min(m,n) .
Each \(H\) (i) has the form
\(H(i) = I - \tau_{a} v v^{T}\) for real flavors, or
\(H(i) = I - \tau_{a} v v^{H}\) for complex flavors,
where taua is a real/complex scalar, and v is a real/complex vector with vn - k + i = 1, vn - k + i + 1:n = 0.
On exit, v1:n - k + i - 1 is stored in a(m-k+i,1:n-k+i-1) and taua is stored in taua(i)[i - 1] .
The matrix \(Z\) is represented as a product of elementary reflectors
\(Z = H(1) H(2) \cdots H(k)\) , where k = min(p,n) .
Each \(H\) (i) has the form
\(H(i) = I - \tau_{b} v v^{T}\) for real flavors, or
\(H(i) = I - \tau_{b} v v^{H}\) for complex flavors,
where taub is a real/complex scalar, and v is a real/complex vector with v1:i - 1 = 0, vi = 1.
On exit, vi + 1:p is stored in b(i+1:p, i) and taub is stored in taub(i)[i - 1] .
