O-RAN Intel® FPGA IP

The Extensible Radio Access Network (O-RAN WG4 Fronthaul Interface) defines a fronthaul interface between a lower-layer split distributed unit (DU) and remote unit (RU) in an Evolved Universal Terrestrial Access Network (E-UTRAN) and Next-Generation Radio Access Network (NG-RAN) system with a lower layer functional split-7-2x based architecture. The O-RAN IP implements control and user plane protocol specified in O-RAN-FH.CUS.0-v03.00.

Read the O-RAN Intel® FPGA IP user guide ›

Read the O-RAN Intel® FPGA IP design example user guide ›

O-RAN Intel® FPGA IP

  • Overview

Features

  • Support for CAT-A RU (up to 8 spatial streams)
  • Support for CAT-B RU (precoding in RU)
  • Support for section extensions from 1 to 11
  • Bandwidth saving:
    • Programmable static bit-width fixed-point IQ
    • Real-time variable bit-width
    • Compressed IQ
    • Block floating-point compression
    • μ-law compression
    • Variable bit-width per channel (per data section)
    • Static configuration of U-plane IQ format and compression header
  • Transmission blanking energy savings
  • Preconfigured transport delay method CU–RU timing
  • Section type 0, type 1, and type 3

IP Status



Ordering Status

Production

Ordering Code

IP-ORAN-FH

View all Show less

Related Links

Documentation

  • The emerging need for fronthaul compression white paper

Device Support

  • Intel® Agilex™ 7 FPGAs
  • Intel® Stratix® 10
  • Intel® Arria® 10
  • IDT CPRI compression IP (Partner page)

Additional Resources

Find IP

Find the right Altera® FPGA Intellectual Property core for your needs.

Technical Support

For technical support on this IP core, please visit Support Resources or Intel® Premier Support. You may also search for related topics on this function in the Knowledge Center and Communities.

IP Evaluation and Purchase

Evaluation mode and purchasing information for Altera® FPGA Intellectual Property cores.

IP Base Suite

Free Altera® FPGA IP Core licenses with an active license for Quartus® Prime Standard or Pro Edition Software.

Design Examples

Download design examples and reference designs for Altera® FPGA devices.

Contact Sales

Get in touch with sales for your Altera® FPGA product design and acceleration needs.
