13.1. GTS DisplayPort PHY Duplex Mode IP Generation Flow

When you generate a duplex mode design example, a single transceiver core appears in the top-level Verilog of the design example, as shown below:
The DS tool is grayed out since the design does not include any simplex IPs.
Figure 57. Dual Simplex (DS) Assignment Editor
