Vertical Segment
Desktop
Processor Number
i7-11700KF
Lithography
14 nm
Recommended Customer Price
$411.00-$421.00

CPU Specifications

Total Cores
8
Total Threads
16
Max Turbo Frequency
5.00 GHz
Intel® Turbo Boost Max Technology 3.0 Frequency
5.00 GHz
Intel® Turbo Boost Technology 2.0 Frequency
4.90 GHz
Processor Base Frequency
3.60 GHz
Cache
16 MB Intel® Smart Cache
Bus Speed
8 GT/s
TDP
125 W
Configurable TDP-down Base Frequency
3.10 GHz
Configurable TDP-down
95 W

Supplemental Information

Marketing Status
Discontinued
Launch Date
Q1'21
Embedded Options Available
No
Use Conditions
PC/Client/Tablet
Datasheet

Memory Specifications

Max Memory Size (dependent on memory type)
128 GB
Memory Types
DDR4-3200
Max # of Memory Channels
2
Max Memory Bandwidth
50 GB/s
ECC Memory Supported
No

Expansion Options

Scalability
1S Only
PCI Express Revision
4.0
PCI Express Configurations
Up to 1x16+1x4, 2x8+1x4, 1x8+3x4
Max # of PCI Express Lanes
20

Package Specifications

Sockets Supported
FCLGA1200
Max CPU Configuration
1
Thermal Solution Specification
PCG 2019A
TJUNCTION
100°C
Package Size
37.5 mm x 37.5 mm

Advanced Technologies

Intel® Gaussian & Neural Accelerator
2.0
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
Intel® Optane™ Memory Supported
Yes
Intel® Thermal Velocity Boost
No
Intel® Turbo Boost Max Technology 3.0
Yes
Intel® Turbo Boost Technology
2.0
Intel® Hyper-Threading Technology
Yes
Intel® 64
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2, Intel® AVX-512
Idle States
Yes
Enhanced Intel SpeedStep® Technology
Yes
Thermal Monitoring Technologies
Yes
Intel® Identity Protection Technology
Yes

Security & Reliability

Intel® Software Guard Extensions (Intel® SGX)
No
Intel® AES New Instructions
Yes
Secure Key
Yes
Intel® OS Guard
Yes
Intel® Trusted Execution Technology
No
Execute Disable Bit
Yes
Intel® Boot Guard
Yes
Intel® Stable IT Platform Program (SIPP)
No
Intel® Virtualization Technology (VT-x)
Yes
Intel® Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
