Offerings
Offering
Intel® 12th/13th Gen Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor, support LGA 1700 CPU Up to 35/65/125W Max, Intel® R680E Chipset2 x 262-pin DDR5 4800MHz SO-DIMM supports up to 64GB, dual channel (non ECC)4 x Intel® i226-LM 2.5 gigabit controller, realtek ALC888S with stereo class D 2W4Ω x 22 x DP++, 1 x HDMI 2.1b (LSPCON support): 8K@60Hz1 x 2CH LVDS or eDP2 x SATA III4 x USB 3.2 Gen 2 & 4x USB 3.2 Gen 1 in I/O, 2 x USB 3.2 Gen 1, 2 x USB 2.0 via headers1 x PCIe x 16 Gen 51 x M.2 (2230) E-Key, supports Wi-Fi module with PCIe x 2 Gen 4 & USB 2.02 x M.2 (2242/2280) M-Key, supports PCI-e x 4 Gen 4 SSD2 x RS232/422/485, 3 x RS23216-bits GPIO, support RAID 0, 1 ATX Power.
Offering
Intel® 12th Gen Core™ i9/i7/i5/i3/Pentium®/Celeron® Processor, support H610E/Q670E2-DIMM Up to 64GB dual channel DDR5 SO-DIMM 4800MHz3-storage (2.5” Drive Bay & 2-M.2 B/M)3-expansion (mPCIe & 2-M.2 E/B)Rich I/O 8-USB, 6-COM, 2-LAN, support 5G, Wi-Fi 6E, 2.5G LANDC in +12V-24V, wide voltage, support HW TPM 2.0.
Offering
ECM-RPLP is a small yet powerful and fanless 3.5 inch Single Board Computer (SBC) built with the 13th Gen Intel® Core™ Processor Onboard with many additional game-changing features. When coupling with select Intel® Core™ i7 and i5 processor, ECM-RPLP delivers integrated Intel® Iris® Xe Graphic performance. Two DisplayPorts 1.4a @60Hz with 4096x2160 resolution, and one 18/24 bits Dual Channel LVDS are provided at external I/O. eDP is optional. The board supports 3 independent displays (2xDP + LVDS/eDP). USB Type C Thunderbolt™ 4. ECM-RPLP provides integrated USB Type C Thunderbolt™ 4 connector delivering up to 40 Gbps data transfer speed. The board also provides 4 x USB 3.2 connectors at rear IO, and 2 x USB 2.0 onboard headers for 3 x USB 2.0 ports. DDR5 SODIMM Sockets, 3 x M.2 Sockets Two SODIMM sockets support two DDR5 4800MHz memory modules up to 32GB. M.2 E-Key supports CNVi module, M.2 M-Key supports NVMe module, and M.2 B-Key with Nano SIM card socket for cellular communication module. Fanless Operation The ECM-RPLP is bottom layer soldered processor design. This design enables fanless operation by using a Passive Heatsink (15W) with optional Fan (28W) while maximizing the space for key features on the top side of the board allowing ease of installation of the DDR5 memory and M.2 modules. Additionally, two COM port headers support up to 4 COM ports, one SATA III connectors for storage. Two LAN ports powered by Intel® I226-LM Ethernet Controllers deliver 2.5GbE speed.
Offering
NUC-RPLP is equipped with BCM ECM-RPLP 3.5inch SBC inside. Main features include small form factor embedded system with flexibility of adding additional external USB ports at rear I/O panel. Intel® Core™ i7/i5/i3 SoC Processor supports up to 12 Cores, Intel® Raptor Lake P Platform. 2 x DDR5 SODIMM sockets support up to 64GB system memory. Integrated Intel® Iris Xe Graphic/ Intel® UHD Graphics (CPU Dependent). 2 x DP++ support Dual Displays. Supports 3 Independent Displays. Integrated USB Type C Thunderbolt 4. Dual Intel® I226-LM Ethernet Controllers (2.5 GbE), 2 x LAN Ports. M.2 E-Key CNVi, M.2 M-Key NVMe, M.2 B-Key with Nano SIM Card Slot. 4 x USB 3.2 (rear side), 2 x USB 2.0 (front side). Flexible I/O Bay for 6 x USB 2.0 and 1 x COM Port. 12V-24V DC-In, and Fanless Operation.
Offering
MX-ADLPS Mini ITX motherboard adopts Intel’s breakthrough core technology – the first multichip package (MCP) Intel® Core™ processor platform in a socket, formerly Alder Lake PS platform. The socketed LGA multichip package (CPU+PCH) brings together the graphics and lower processor base power of Intel’s mobile processor with the benefits of Intel’s desktop processors. This architecture provides greater flexibility for compact design of a main board as well as scalable computing performance from the selections of Intel® Core SoC processors. Combining with additional cutting-edge technology enhancements including Thunderbolt 4, Iris Xe graphics, 4 DP++ 4K/8K displays, 2.5GbE LAN, the MX-ADLPS can be used for a wide range of deep learning, machine vision, and AI driven applications such as retail POS with object recognition, intelligent kiosk with object detection and analytic functions, medical imaging with AI assistance, digital surveillance, IoT video applications and more.
Offering
Intel® LGA4677 Socket supports 4th Gen. Intel® Xeon® Scalable Processor (Max. TDP at 250W)Intel® C741 Chipset 6 x DDR5 4800/ 4400 MHz RDIMM up to 1.5TBTPM 2.0 onboard IPMI 2.0 with AST 2600 BMC controller onboard.1 x Intel I210AT 1Giga-bit Ethernet1 x Intel I226-LM 2.5Giga-bit Ethernet1 x Intel® X550-AT2 10Giga-bit Ethernet(Optional)5 x SATA III Support RAID 0,1,5,101 x internal RS232 port4 x USB 3.2 Gen1 port & 2 x USB 2.0 port at Edge I/O4 x internal USB 3.2 Gen1 Port1 x M.2 M-Key PCIe 3.0 x4 NVMe SSD, 2242/2260/2280/22110 form factor12" x 9.6" (304.8mm x 243.84mm), PCB thickness is 2.54mm.
Offering
Intel® 11th Tiger Lake-U Processor Intel® Iris® Xe/UHD Graphics Single Memory Socket, Max. Up to 32GB DDR4 3200MT/s. Dual Display, DP++ 1.4Dual Intel® Gigabit Ethernet, 2.5GbE, 1GbETriple Storage, 2.5” Drive Bay, 2-M.2 SSD Triple M.2 Slot, Key-E/B/M for Wi-Fi, LTE, SSD and I/O module. Support iAMT, SATA RAID 0/1Default dTPM 2.0, Wall Mount Kit
Offering
Intel® 11th Tiger Lake-U Processor, Intel® Iris® Xe Graphics Single Memory Socket, Max. Up to 32GB DDR4 3200Dual Display, HDMI 2.0bDual Intel® Gigabit Ethernet, 2.5GbE, 1GbETriple M.2 Slot, Key-E/B/M for Wi-Fi, LTE, SSD, I/O module, supports iAMT, kensington lock default dTPM 2.0, mounting kit.
Offering
31.2” E Ink Public Display (Black and White)Onboard Intel® Celeron® SoC BGA Processor N3350 (with CPU Bottom Mounted)Single DRAM Socket, Max. Up to 8GB DDR3L 1866MHz1 x SATA III / 2 x HDMI 1.4 / 1 x COM / 2 x LAN / 4 x USB3.0+19 DC Voltage InputOperating temp. 0-50 degreesDual mPCIe Expansion Slot TPM 2.0Open frame design(full flat)Option for Wi-Fi & BT functionP-cap touch(optional)Front light module(optional)VESA mount compliant(400 × 200 mm)
Offering
Intel Atom® Processor Z3735F2GB RAM8GB or 32GB eMMCPCAP Touch10/100 Ethernet (PXE Boot)Touch board interface (Power/ Brightness/ Volume/ LED)16Bit programmable GPIORS232(TX/RX) or RS485DC 12-24V Input
Offering
21.5” 16:9 1080P Display with PCAP Multi touchOnboard 6th Generation Intel® Core™ i7/ i5 / i3/ or Celeron® ProcessorSupport 1x 260 pin SO-DIMM up to 16GB DDR4 SDRAMAnti-Microbial Finish4x USB3.0, 1x RS-232/422/485, 1x RS-232, 2x Intel® Gigabit LANInfineon TPM2.0Dual LED Reading Light BarStylish Front OSD keypad touch control buttonFront Panel IP65 & Fanless DesignUltra-slim design only at 45.5mm thickness5-kV Isolation USB/ COM/ LAN ports by IET moduleOptional Handset with Barcode Scanner/ MSR/ SCR/ NFC/ RFID mdouleOptional WIFI/ BT v4.0 and Li-ion smart battery pack
Offering
Onboard Intel Atom® SoC E3845 ProcessorsOne 204-pin SODIMM Socket Up to 8GB DDR3L 1333MHz SDRAMRRich I/O, 1 VGA, 1 LVDS, 1 DC-Out, 1 8-bit GPIO, 1 CFast, 1 2.5"" Swappable Drive by, 2 Line-out, 2 Mic-in, 2 LAN, 2 COM, 3 USB, 5 Antenna MountingPower Management and Low Voltage Protection DesignRugged Fanless Design Compliant with MIL StandardWake on RTC/SMS Via WWAN ModuleOptional CAN modules support SAE J1939 or J1708
Offering
High Reliability Gold Plating ConnectorsSocket LGA 1151 supports 8th/9th Generation Intel® Core™/Pentium®/ Celeron® Processors, (formerly Coffee Lake/Coffee Lake Refresh)Intel® Q370 PCH4 x Gold Plated DIMM Up to 64GB Dual Channel DDR4 2400Mhz Optional ECC Memory Support2 x Gigabit LAN: Intel® I219-LM and Intel® I211-ATRich expansion interfaces with gold plated slots6 x SATA III, 9 x USB 3.0, 6 x USB 2.0, 6 x COMSupports SATA RAID 0, 1, 5 and 10Intel AMT 12TPM 2.0 * Please note product specifications and product images are subject to change without notice.
Offering
Onboard 6th Gen Intel® Core™ SoC i7/i5/i3 or Intel® Celeron® BGA ProcessorOne 260-pin SODIMM Socket Up to 16GB DDR4 2133MHz SDRAMExpansion Slot Supports 1 Mini PCIe Slot, 1 M.2, 1 IET InterfaceFront Access Swappable 2.5" Drive Bay, 2 SIM CardRugged Design for Vibration & Shock ProtectionFanless Operating from -20 ~ 60°C, Support IP50Power Input: Typical 12/24 Vdc ( +9~ 32V )Supports Intel® iAMT 11.0, TPM2.0, Turbo Boost Technology, vPro, Wake on LANService Window, Easy to Install M.2, Memory and Mini PCIe Module
Offering
10.01 inch LCD with PCAP Touch Panel1280 x 800 Resolution Intel Atom® x5-Z8300 / Z8350 Processor: 1.44GHz 2GB RAM 32GB eMMC PCAP Touch 10/100/1000 Ethernet (PXE Boot)Touch board interface (Power/ Brightness/ Volume/ LED) 16Bit programmable GPIO RS232 (TX/RX) or RS485 Typical DC 19V Input, Optional 12V & 24V support Supports Windows 10 IoT (64-bit) Optional Power Over Ethernet 802.3AT (10" only)
Offering
Intel Atom® Processor Z3735F2GB RAM8GB or 32GB eMMCPCAP Touch10/100 Ethernet (PXE Boot)Touch board interface (Power/ Brightness/ Volume/ LED)16Bit programmable GPIORS232(TX/RX) or RS485DC 12-24V Input
Offering
Intel® Pentium®/Celeron®/Atom® ProcessorOne 204-pin SODIMM Socket Up to 8GB DDR3L 1866MHz SDRAMRich I/O, 1 DP, 1 LVDS, 1 DC-Out, 1 8-bit GPIO, 1 M.2 SSD, 1 SD Card, 1 2.5" Swappable Drive Bay, 2 Line-out, 2 Mic-in, 2 LAN, 2 COM, 4 USB, 5 Antenna MountingOnboard u-box M8N concurrent GNS module (GPS/QZSS, GLONASS, BeiDou)Rugged Fanless Design Compliant with MIL-STD-810GPower Management and Low Voltage Protection DesignWake on RTC/SMS Via WWAN ModuleOptional CAN modules supports OBD II, SAE J1939 or J1708Wide Range DC Power Input from 9 ~ 36VFanless Operating from -20/40 ~ 70°CSupports TPM 1.2/2.0 (Factory Option), SD card(SD 3.0)
Offering
Features: Onboard Intel® Pentium®/ Intel® Celeron®/ Intel Atom® SoC BGA Processor One 204-pin DDR3L SODIMM Socket, Supports Up to 8GB DDR3L 1866MTs SDRAM (Non-ECC) Triple Display (Dual HDMI, LVDS) 1 SATA III, 4 USB 3.0, 1 USB 2.0 ,6 COM, 1x Mini-PCIe,1x M.2, 8-bit GPIO Fanless Operation
Offering
Intel® Q370 PCHSocket LGA 1151 supports 8th Generation Intel® Core™/Pentium®/Celeron® Processors (formerly Coffee Lake)4 x DIMM Up to 64GB Dual Channel DDR4 2400Mhz Optional ECC Memory SupportExpansion Slots: 1 x PCIe x16, 2 x PCIe x1, 2 x PCIe x4, 2 x PCI, 1 x M.2 Type M 2242, 2260, 2280 Slot (with PCIe x4 & SATA III), 1 x M.2 Type A/E 2232 (with USB & PCIe x1)Onboard I/O: 5 x SATA III, 1 x SATA III shared with M.2, 4 x USB 2.0 Headers with Shroud (8 Ports on Header), 2 x USB 3.1 Gen 2 Header, 5 x RS-232, 1 x RS-232/422/485 Headers, LPT Header, LPC HeaderExternal I/O: 1 x HDMI, 2 x DP, 1 x VGA, 2 x RJ45+Dual USB 3.1 Gen 1 (Stacked)(4 x USB 3.1 Ports), 2 xUSB 3.1 Gen 2 Type-A Connectors, 1 x USB 3.1 Gen 2 Type-C Connectors, 1 x 3 Jacks Audio ConnectorTPM 2.0ATX Form Factor 12" x 9.6"* Please Note that all product specifications and product images are subject to change without notice
Offering
Gold Plated Connectors* Intel® Q370 PCHSocket LGA 1151 supports 8th generation Intel® Core™/Pentium®/Celeron® Processors (formerly Coffee Lake)2 x Gold Plated DIMM Up to 32GB Dual Channel DDR4 2400Mhz Optional ECC Memory Support2 x Gigabit LAN: Intel® I219-LM and Intel® I211-ATExpansion Slots: 1 x PCIe x 16 Slot (Gold Plated), 1 x M.2 Type M 2242, 2280 Slot (with USB, PCIe x4 & SATA III) (Gold Plated), 1 x M.2 Type A/E 2232 (with USB & PCIe x2) (Gold Plated)Onboard I/O: 2 x SATA III Connectors (Red) (Gold Plated),1 x SATA III Connector, 1 x USB 2.0 Headers with Shroud (2 Ports on Header) (Gold Plated), 1 x USB 3.1 Gen 1 Header with Shroud (2 Ports On Header) (Gold Plated), 1 x RS-232 Headers, 1 x LVDS Header (Gold Plated)(Optional eDP)External I/O: 1 x HDMI (30μ Gold Plated), 2 x DisplayPort Connector (Gold Plated) (4k/2k Capable), 2 x RJ45 & Dual USB 3.1 Gen 2 (Stacked), 2 x USB 3.1 Gen 1 Ports, 1 x USB Type-C (USB 3.1 Gen 2 Speed), 1 x 3 Jacks Audio Connector6.7" x 6.7"TPM 2.0* Please Note that all product specifications and product images are subject to change without notice
Offering
Onboard 6th Generation Intel® Core™ i7, i5, and i3 BGA ProcessorOne 260-pin DDR4 SODIMM Socket, Supports Up to 16GB DDR4 2133 SDRAM (only support non-ECC)Dual-channel 18/24-bit LVDS, HDMITriple Display (LVDS, 2x HDMI)2 SATA III, 1 Mini PCIe, 4 USB 3.0,1 M.2 (2242) SSD, 2 USB 2.0, 2 COM, 8-bit GPIOHD Audio, Dual Gigabit EthernetTPM 2.0/1.2 (Both optional)iAMT 11
Offering
LGA1151 Socket supports 8th Gen Intel® Coffee Lake C2/C4/C6 ProcessorsIntel H310 PCH2 x SoDIMM supports up to 32GB Dual Channel DDR4 2400 MHz System MemoryRich Expansion Interface: 1 x PCIe x4, 1 x M.2 Type M 2242/2280, 1 x M.2 Type A/E 2230Supports Dual Display: 1 x HDMI, 1 x DisplayPort, 1 x LVDS4 x USB 3.1 Gen 1, 4 x USB 2.02 x COM, 2 x SATA III12V-24V Wide Range DC-InTPM 2.0
Offering
7th Generation Intel® Core™ i7/i5/i3 Processor Mobile Intel® QM175 ChipsetOne 260-pin SODIMM Socket Up to 16GB DDR4 2400MHz SDRAMRich I/O, 1 SATA III, 1 Mini PCIe, 1 M.2, 1 Line-Out, 1 Mic-In, 2 LAN, 2 HDMI, 2 USB 2.0, 4 USB 3.0, 2 COMFanless
Offering
LGA1151 socket supports 2C/4C/6C Intel® Xeon® E, Core™-i, Pentium®, Celeron® processors4 x DIMM sockets support 2666/2400/2133 MHz UDIMM up to 64GB system memorySupports ECC Memory using compatible processors1 x PCIe x16, 2 x PCIe x4, 2 x PCIe x1, 2 x PCI, 2 x M.2Supports Triple Displays1 x HDMI, 2 x DisplayPorts, 1 x VGAOnboard USB: 8 x USB 2.0 and 1 x USB 3.1 Gen 2 Header (2 Ports on Header)External USB: 6 x USB 3.1 Gen 1 (Speed up to 5Gbps) and 1 x USB 3.1 Gen 2 Type-C (Speed up to 10Gbps) Connectors6 x COM PortsTPM 2.0
Offering
A digital signage kit that plays coordinated content when customers engage with items on the shelf. The smart shelf provides product knowledge and targeted advertising and then stores all data in the cloud.Detect Movement of Product and Trigger the AdvertisementGood for Complex Products or Promote Specific Items with Attractive Advertisement, Product Details or Discount Voucher Advantages:Engage customers with targeted advertisements and product informationImprove productivity of store employees by reducing the time spent describing products to customersIncrease insights on product placement with by Power BI
Offering
6th Gen Intel® Sky Lake-U ProcessorSingle DRAM Socket, Max. Up to 16GB DDR4 2133MHzRich I/O, 1 SATA III, 1 Mini PCIe, 1 M.2, 2 COM, 2 USB 2.0, 4 USB 3.0 , 2HDMI, 2LANFanless Operating from -10 °C- 60°CWide Range DC Power Input from 12V - 26VCompact Size, 177mm x 123mm x 50mmOptional VESA. DIN Rail KitTPM 2.0/1.2 (Factory Option)
Offering
Onboard 7th Gen Intel®Core ™ i7/i5/i3 BGA Processor One 260-pin DDR4 SODIMM Socket, Supports Up to 16GB DDR4 2400 SDRAM (only support non-ECC)Dual-channel 18/24-bit LVDS,HDMITriple Display (LVDS, 2x HDMI)2 SATA III, 1 Mini PCIe, 4 USB 3.0,1 M.2 (2242) B-Key, 2 USB 2.0, 2 COM, 8-bit GPIOHD Audio, Dual Gigabit EthernetTPM 2.0/1.2 (Both optional)iAMT 11
Offering
The Medix Care Solution enables communication between medical staff and patients, empowering services at the point of care, while providing analytics to facilitate hospital management:> Communication to Nursing station> Digital Patient Records at Bedside> Wide Range of Clinical Efficiencies Features> Versatile Computer Platforms> Enhances mobility and enables BYOD initiatives: - Bedside Terminals - TV - Set-Top-Box - Tablet - BYOD - Any X86/ Intel based Bedside Terminal > Fit your healthcare environment: - Front face IP65 protects against the ingress of fluids and dust - Rare design compliant to IP54 standards> Provide thermal management ensuring higher reliability and silent operation
Offering
Onboard Intel® Apollo Lake SoC with Integrated ChipsetOne 204-pin DDR3L SODIMM Socket Supports Up to 8GB3 USB, 1 COM, 1 x LANWide Voltage +12V - +26V Input, ErP PowerBacklight Controlled by PWMFull System IP65 & IPX9KFanless Operation
Offering
8th Generation Intel® Processors (6-Core)Intel® Q370 Express ChipsetIntel® UHD Graphics 630/610Memory Max. Up to 32GB DDR4 2666mPCIe,M.2 Key-E, M.2 Key-B Expansion Slots-25~70/-40C~70C Operating Temperature9~36Vdc DC Input, with Vehicle Power ManagementSupport RAID 0/1/5/10, Firmware TPM 2.0, iATM 12.0CE, FCC, IP50, E Mark, ISO7637-2 Certified
Offering
Intelligent digital signage solution harnessing real-time data insights to identify demographics and display relevant, interactive and personalized ads. Helps to enhance the shopping experience and encourage purchasing with facial recognition for personalized ads and promotional information. Providing a user-friendly content management system for store owners to create and manage advertisements. Retailers could edit content, set displaying schedule and synchronize multiple digital signage devices at the same time. Why need Interactive Digital Signage with Facial Recognition in the retail stores?Smart signage with facial recognition to catch customer focus and shopping intensivePop up right advertisement to target audiencesCollect shopper behavior and get reliable statistics & market feedback dataPromotes strategic marketing improvements through the collection of customer statistics Target marketsRestaurantShopping MallChain StoreHotelHospitality
Offering
Intel® Atom™ x5-Z8350 Processor: 2M Cache, up to 1.92 GHz2GB / 4GB RAM32GB / 64G eMMCPCAP Touch10/100/1000 Ethernet (PXE Boot)Touch button (Power/ Brightness/ Volume/ LED)RS232 or RS422 or RS485DC 12-24V Input or Powered LAN 802.3ATNFC ReaderSmart Card ReaderAMIC2.0MP Camera75 x 75mm VESA MountPlastic has AntibacterialOptional Handset
Offering
OFT10W-3455J 10.1" Open Frame Tablet features PCAP touchscreen 1280x800 and is built with our ECM-3455J 3.5" SBC small form factor inside. The tablet is equipped with onboard Intel® Celeron® J3455 Quad Core SoC 2.3GHz Burst Frequency, codenamed Apollo Lake platform, with integrated Intel® HD Graphics 500 delivering outstanding computing performance with lower TDP. The OFT10W-3455J is equipped with 4GB RAM, 32GB eMMC, and Wi-Fi (802.11 a/c/b/g/n) & Bluetooth 5.0. for wireless communication. Multi-OS support includes Window 10, Linux and Android. The tablet provides rich external IO interfaces include dual RJ45 LAN ports, HDMI, 4 USB 3.0, Line-out, DC-in and optional RS-232/422/485 COM port. The tablet supports 9V to 36V wide range DC input.
Offering
The RX680R is a Micro ATX motherboard built with LGA1700 CPU socket, Intel® R680E PCH with x8 Gen4 DMI and is capable to support the 12th Gen Intel® Core™ i9/i7/i5/i3, Pentium®, Celeron® processor family up to 16 Cores 24 Threads Hybrid. Select processors support Integrated Intel® Iris® Xe Graphic. The board provides 4 x DIMM slots DDR5 5200MHz system memory up to 128GB with ECC support. Rich expansion slots include 1 x Gen 5 PCIe x16, 2 x Gen 4 PCIe x4, 1 x Gen 3 PCIe x4 Open Ended, 1 x M.2 M-Key 2242/2280/22110 NVMe (Gen 4 PCIe x4 + SATA III), 1 x M.2 M-Key 2242/2280/22110 NVMe (Gen 3 PCIe x4 + SATA III), and 1 x M.2 E-Key 2230 with CNVi Support (PCIe x 1 + USB 2.0). Two of the Intel® I225/226-LM Ethernet controllers onboard delivering 2.5GbE network speed. Infineon® TPM 2.0 is supported. The RX680R supports up to 4 independent displays via 4 DisplayPort. For USB interfaces, there are 6 x USB 3.2 Gen 2x1 Ports, 1 x USB 3.2 Gen 2x2 Type-C at the rear IO panel, and 1 x USB 3.2 Gen 2x1 Header (2 Ports), 4 x USB 2.0 Headers (8 Ports) and 1 x Thunderbolt Header onboard. The board also provides 6 COM ports, 4 SATA III and supports Windows 10, 11 and Linux OS.
Offering
Onboard 11th Gen. Intel® Core™ SoC i7/i5/i3 & Celeron® BGA Processor 2 x 260-pin DDR4 3200 MHz SO-DIMM supports up to 64GB (non ECC only) 2 x DP++, 2 x DP, 1 x LVDS, 1 x eDP (Maximum: 6 for quadruple independent displays) 1 x Intel® I225IT 2.5 Gigabit Ethernet 1 x Intel® I219LM Gigabit Ethernet PHY 2 x Intel® I210IT Gigabit Ethernet (BOM optional) 1 x M.2 Type B 3042/3052/2242/2260/2280 (with 1 x PCI-e x1 (default) or SATA, USB 3.0 with 1 x SIM card slot, support WWAN+GNSS or NVMe SSD SATA 2 share with M.2 key B SATA1 x M.2 Key E 2230 support WiFi module and CNVi (1 x PCI-e x1 & USB 2.0 Signal)GPIO 16bitOnboard support TPM 2.0
Offering
Intel® 12th Gen Core™ i9/i7/i5/i3 Processor, supports LGA1700 CPU Up to 125W MaxIntel® R680E4 DIMM Up to 128GB Dual Channel DDR4 3200MHz 2 x Intel® i225-LM 2.5G Gigabit Controller1 x Intel® X550-AT2 10G Gigabit Controller2 x DP++, 1 x HDMI4 x SATA III2 x PCIe x16 slot for 1 x PCIe x16 Gen5 or 2 x PCIe x8 Gen42 x PCIe x4 Gen 41 x PCIe x4 slot for 1 x PCIe x2 Gen 3 only1 x PCIe x4 Gen32 x 4-deck USB3.2 connector at I/O for 8 port USB3.2 Gen21 x USB3.2 Gen1 Vertical Type A1 x dual deck RJ45 for 2 x 10G LAN1 x dual deck RJ45 for 2 x 2.5G LAN2 x M.2 Key M 2242/2280/221102 x RS232/422/485, 4 x RS232Support RAID 0, 1, 5, 10
Offering
Bottom Layer Soldered ProcessorSingle 260-pin SO-DIMM DRAM Socket,Max, Up to 32GB DDR4 3200MTs (non-ECC Supported)Four Display, 2 x DP++, 1 x 2CH LVDS, 1 x eDPExpansion Slot,M.2 Key-B, M.2 Key-E, M.2 Key-M Three Gigabit Ethernet, 1 x 2.5GbE, 2 x 1GbE
Offering
PICMG COM R3.0 Type 6 module with Intel® 11th Generation Core™ i7 / i5 / i3, Celeron® BGA 10nm ProcessorsUp to 3x 260-pin DDR4 3200 SO-DIMM with up to 96 GByte Intel®Xe(Gen 12) graphics, media, and display with up to 32EUFlexible I/O support with 4 SATA3.0 (6.0GB/s), 4 USB3.2 Gen.2x1(10Gbp/s), 8 USB 2.0, 8-bit GPIO, 1 Gen4PEGx16, 8-PCIex11 x 2.5GbE Ethernet via Intel® I225LM
Offering
RX610H Micro-ATX motherboard is built with LGA1700 CPU socket, Intel® H610E PCH with x4 Gen4 DMI and is capable to support the 12th Gen Intel® Core™ i9/i7/i5/i3, Pentium®, Celeron® processors, up to 16 Cores 24 Threads Hybrid. Select processors support Integrated Intel® Iris® Xe Graphic. 4 DIMM slots support DDR5 4800MHz system memory up to 64GB. The board provide rich expansion interfaces including 1 x Gen 5 PCIe x16, 1 x Gen 3 PCIe x1, 2 x Gen 3 PCIe x1, 1 x M.2 M-Key 2242/2280/22110 NVMe (PCIe x4 + SATA III), and 1 x M.2 E-Key 2230 with CNVi Support (PCIe x1 share with slot4 + USB 2.0). For communication, the RX610H is equipped with Intel® I255-V and Intel® I219-V Ethernet controller support 2.5GbE and 1GbE via 2 LAN ports. RX610H supports 3 multi-displays via 1 HDMI and 2 DisplayPort. TPM 2.0 hardware security is supported. RX610H provides 2 x USB 2.0 Type A, 4 x USB 3.2 Type A, 2 x USB 2.0 Headers (4 Ports), 1 x USB 3.2 Gen 1 Header (2 Ports), 6 COM ports and 4 SATA III. Window 10, 11 and Linux OS are supported.
Offering
ECM-3455J is equipped with the 14nm Intel® Celeron® J3455 Quad Core 10 watts TDP low power SoC processor with integrated Intel® HD Graphics 500. The onboard 32GB eMMC is convenient and cost effective for most industrial applications. The J3455 quad-core CPU offers exceptional value-performance for applications in industrial, medical, healthcare, factory, and retail markets. For applications require larger capacity, the option of 64GB eMMC onboard is available for qualifying OEMs on a build to order basis. ECM-3455J is unique fanless design using the solid aluminum block heat-spreader to help transfer and release the heat with the reliability of not active fan. The low profile design of the ECM-3455J suits space saving applications that require fanless, and quiet operations. The board provides many cellular/WiFi/Bluetooth communication friendly I/O interfaces including M.2, mini-PCIe with SATA, uSIM support, I²C, SMBus, plus two Gigabit Ethernet LAN ports, and TPM 2.0 for hardware based security. While most of the small form factor motherboards with wide range DC power design supports from 12V to 24V, BCM ECM-3455J 3.5" SBC supports from 9V to 36V adding additional value and flexibility to suit wider range embedded applications: Industrial control Human Machine Interface (HMI) Digital Signage Small Point-of-Sale Terminal, Retail Kiosk Interactive Self-serve Kiosk Medical and Healthcare equipment Besides common OS support for Windows 10 IoT for x86 platform SBC, ECM-3455J also supports Linux and Android OS for mobile devices that require more computing power, more expansion and I/O interfaces with low power consumptions.
Offering
The BCM MX6412J is a fanless and Thin Mini-ITX motherboard designed on the low power embedded SoC Elkhart Lake platform. It features the latest 10nm architecture with the onboard Intel® Celeron® 6412J Quad Core processor with 1.5MB L2 Cache and up to 2.60 GHz CPU burst frequency with a low TDP of 10 watts. Its two DIMM slots support 3200MT/s DDR4 memory modules up to 32GB. MX6412J is a Mini-ITX motherboard with four LAN ports with two LAN supporting 2.5GbE speed. All of this I/O is on a low profile (single stack I/O) design. Also unique is the MX6412J supports up to three 4K/HD displays simultaneously. These two features are great solutions for network gateways and digital signage applications. The MX6412J is an ideal solution for applications that require a balance between cost and performance with practical features like the four LAN ports and support for three independent displays all within a 10W CPU TDP envelope.
Offering
MX610HD is a thin (low profile) Mini-ITX motherboard built with LGA1700 CPU socket, Intel® H610E PCH with x4 Gen4 DMI and capable to support the 12th Gen Intel® Core™ i9/i7/i5/i3, Pentium®, Celeron® processor family, up to 16 Cores 24 Threads Hybrid. Two SODIMM slots support DDR5 4800MHz system memory up to 64GB. MX610HD provides 1 x Gen 4 PCIe x16, 1 x M.2 M-Key 2242/2280 NVMe (PCIe x4 + SATA III), and 1 x M.2 E-Key 2230 with CNVi Support (PCIe x 1 + USB 2.0) expansion interfaces. Built-in dual LAN Intel® I225-LM and Intel® I219-LM Ethernet Controllers provide 2.5GbE and 1 GbE communication speed. The board supports TPM 2.0 and up to 3 independent displays via 1 HDMI, 1 DisplayPort and LVDS/eDP.
Offering
19" 4U Chassis 430mm(W) x 174.8mm(H) x 528mm(D) 1 x 1300W PS2 ATX PSU 3 x Front Accessible 2.5" storage bay Intel® Xeon® processors 12 x DDR4 2933/ 2666/ 2400/ 2133 MHz RDIMM/ LRDIMM up to 1.5TB IPMI 2.0 with AST 2500 BMC controller onboard 4 x Intel® I210AT Giga-bit Ethernet
Offering
BC680R is a ATX motherboard built with LGA1700 CPU socket, Intel® R680E PCH with x8 Gen4 DMI and capable to support 12th Gen Intel® Core® i9/i7/i5/i3, Pentium®, Celeron®, up to 16 Cores 24 Threads Hybrid Processors. 4 x DIMM slots support DDR5 4800MHz system memory up to 128GB with ECC support. The board provide rich expansion slots including 1 x Gen 5 PCIe x16, 2 x Gen 4 PCIe x4, 1 x Gen 3 PCIe x4, 1 x Gen 3 PCIe x1, 2 x Gen 3 PCIe x1 Open Ended, 1 x M.2 M-Key 2242/2280/22110 NVMe (PCIe x4 + SATA III), 1 x M.2 M-Key 2242/2280/22110 NVMe (PCIe x4 Only), and 1 x M.2 E-Key 2230 with CNVi Support (PCIe x 1 + USB 2.0). For LAN ports, BC680R is spec'd with 2 of the Intel® I225-LM Ethernet controllers providing 2.5GbE speed via 2 RJ45 interfaces. When coupled with select processors, the board supports integrated Intel® Iris® Xe Graphic and 4 multiple displays via 2 HDMI and 2 DisplayPorts. BC680R provide rich USB interfaces including 2 x USB 3.2 Gen 2x1 (6 Ports), 1 x USB 3.2 Gen 2x2 Type-C, 4 x USB 2.0 Headers (8 Ports), 1 x USB 3.2 Gen 2 (2 Ports), and 1 x Thunderbolt™ Header. The board also provides 6 COM ports and 4 SATA III and supports Windows 10, 11 and Linux OS.
Offering
19" 4U Chassis 430mm(W) x 174.8mm(H) x 528mm(D) 1 x 500W PS2 ATX PSU 3 x Front Accessible 2.5" storage bay Intel® Core™ i7/i5/i3/ Pentium® / Celeron® / Xeon® E processors 4 x DDR4 2666MHz ECC and Non-ECC DIMM support up to 128GB (ECC memory supported by specific CPU SKUs) IPMI 2.0 with AST 2500 BMC controller onboard 7 x Intel® I210AT Giga-bit Ethernet
Offering
MX610H is a Mini-ITX motherboard built with LGA1700 CPU socket, Intel® H610E PCH with x4 Gen4 DMI and capable to support the 12th Gen Intel® Core® i9/i7/i5/i3, Pentium® , Celeron® processor family, code named the Alder Lake platform, up to 16 Cores 24 Threads Hybrid. Two SODIMM slots support DDR5 5200MHz system memory up to 64GB. MX610H provides 1 x Gen 4 SMT Type PCIe x16, 1 x M-Key M.2 2242/2280 NVMe (PCIe x4 + SATA III), 1 x E-Key M.2 2230 with CNVi Support (PCIe x 1 + USB 2.0) expansion interfaces. Built-in dual LAN Intel® I225-LM and Intel® I219-LM Ethernet Controllers provide 2.5GbE and 1 GbE network speed. The board supports TPM 2.0 and up to 3 independent displays via 1 x HDMI, 2 x DisplayPort and/or LVDS/eDP. The MX610H Mini-ITX also provides rich high-speed IO interfaces including 4 x USB 3.2 Gen 1x1 Ports, 2 x USB 2.0 Type A, 1 x USB 3.2 Gen 1x1 Header (2 Ports), 2 x USB 2.0 Headers (4 Ports), 4 x COM ports and 3 x SATA III. Windows 10, 11 and Linux supported.
Offering
The MX670QD is a Mini-ITX motherboard built with LGA1700 CPU socket, Intel® Q670E PCH with x8 Gen4 DMI and is capable to support the 12th generation Intel® Core™ i9/i7/i5/i3, Pentium®, Celeron® processor family up to 16 Cores 24 Threads Hybrid. Select processors support Integrated Intel® Iris® Xe Graphic onboard. The board provides 2 SODIMM slots and support DDR5 5200MHz up to 128GB system memory. Rich expansion slots include 1 x Gen 5 PCIe x16, 2 x M.2 M-Key 2242/2280 NVMe (PCIe x4 + SATA III), and 1 x M.2 E-Key 2230 with CNVi Support (PCIe x 1 + USB 2.0). There are two Intel® I225-LM Ethernet Controllers onboard delivering 2.5GbE network speed via two RJ45 LAN ports. Infineon® TPM 2.0 is supported. The MX670QD provides 4 DisplayPorts and a onboard LVDS connector to support up to 4 independent display. For IO interfaces, the board provides 6 x USB 3.2 Gen 2x1 Type-A, 1 x USB 3.2 Gen 2x2 Type-C at the rear IO panel, and 1 x USB 3.2 Gen 2x1 (2 Ports), 2 x USB 2.0 Headers (4 Ports), 2 COM ports and 2 SATA III. The MX670QD supports 12V-24V Wide Range DC-In and Windows 10, 11 and Linux OS.
