The Concepion®-tXf-L-v2 12th Gen is designed to support you in applications such as quality inspection and automatic control in modern manufacturing. The robust embedded PC shines with high performance in a small space at ambient conditions up to 60°C. In addition to 2x PCIe 5.0 slots, two 2.5" drives installed in the shuttle as well as two M.2 slots are available. High flexibility is offered by numerous interfaces and GPU, VPU or FPGA options. In addition, Intel® Core™ i CPUs of the 12th generation with up to 16 cores and 24 threads bring an enormous performance boost. The robust platform is Windows 11 ready.
Offering
The CPU-180-01 is a COM-HPC Client module that features the 11th Gen Intel Core CPUs. Designed for fanless applications in harsh environments where long term reliability is a must, the CPU-180-01 delivers up to 4 CPU cores and 96 GPU execution units and in-band ECC RAM. If features an all-soldered down design to improve resilience and thermal coupling, and comes with a -40 to +85C operating temperature. Both the CPU and the integrated GPU deliver great performance improvements compared to the previous Core generation, and offer AI and Deep Learning, with a combination of INT8 and VNNI instructions. Video encoding and decoding capabilites are also brought to the next level with dual decode boxes capable of up to 40 simultaneous 1080p streams at 30fps. The CPU-180-01 brings novel capabilities: it features Time Sensitive Networking (TSN) on an Ethernet port capable of up to 2.5GbE, which combined with Time Coordinated Computing (TCC) enables soft Real Time applications. TSN is an evolution of the Ethernet standard that provides time determinism to networked communications, while staying completely compatible with the exisiting Ethernet infrastructures. TCC bridges the sinchronization of the internal clocks with the network to achieve microsecond accuracy. The CPU-180-01 features the latest high speed interfaces: PCIe Gen 4, with a bandwidth that is twice the previous generation and Thunderbolt 4 / USB 4 that enable PCIe, Video, USB and Power Delivery over a single, standard connector. Supported operating systems include Everyware Linux (based on Yocto), Ubuntu and Windows 10 IoT Enterprise; additionally, the CPU-180-01 supports Everyware Software Framework (ESF), a commercial, enterprise-ready edition of Eclipse Kura, the open source Java/OSGi middleware for IoT gateways. Professional Services are available for the CPU-180-01, starting from BIOS personalization and including carrier board design, system development and production. Deep module customization, such as feature changes are also available.
Offering
The CPU-180-02 is a rugged module based on the COM-HPC Client and provides additional capabilities, such as Functional Safety (FuSa) signals via proprietary extensions. Designed for fanless applications in harsh environments where long term reliability is a must, the CPU-180-02 features the 11th Gen Intel Core CPUs and delivers up to 4 CPU cores, 96 GPU execution units and in-band ECC RAM. It comes with an all-soldered down design to improve resilience and thermal coupling, and comes with a -40 to +85C operating temperature. The CPU-161-20 is also suitable for Functional Safety applications, and is certifiable according to IEC 61508-2:2010 SIL2 / ISO 13849-1 Cat 3 PL = d. FuSa specific signals are provided to the carrier board via a proprietary extension that allows the customer implementation of a safety agent. Both the CPU and the integrated GPU deliver great performance improvements compared to the previous Core generation, and offer AI and Deep Learning, with a combination of INT8 and VNNI instructions. Video encoding and decoding are also brought to the next level with dual decode boxes capable of up to 40 simultaneous 1080p streams at 30fps. The CPU-180-02 brings novel capabilities: it features Time Sensitive Networking (TSN) on an Ethernet port capable of up to 2.5GbE, which combined with Time Coordinated Computing (TCC) enables soft Real Time applications with microsecond accuracy. The CPU-180-02 features the latest high speed interfaces: PCIe Gen 4, with a bandwidth that is twice the previous generation and Thunderbolt 4 / USB 4 that enable PCIe, Video, USB and Power Delivery over a single, standard connector. Supported operating systems include Everyware Linux (based on Yocto), Ubuntu and Windows 10 IoT Enterprise; additionally, the CPU-180-02 supports Everyware Software Framework (ESF), a commercial, enterprise-ready edition of Eclipse Kura, the open source Java/OSGi middleware for IoT gateways. Professional Services are available for the CPU-180-02, starting from BIOS personalization and including carrier board design, system development and production. Deep module customization, such as feature changes are also available.
Offering
The Advme8088 is a 6U, 1-slot wide VME CPU board with the Intel® Xeon® D-1700 series processor. It is ideal for high-end Edge applications where reliability and long life cycle are critical requirements, with soldered down CPU and RAM to deliver the highest level of resilience and the best cooling perfomance. It supports Wind River VxWorks, offering a great platform for real time applications. Two XMC slots alllow expandability and support both PCIe Gen 3 x8 and Serial RapidIO, which is also delivered to the VXS interface.
Offering
CPU-190-01 is a COM-HPC Size D Edge Server on Module. It features the Intel® Xeon® D-1700 CPU and up to 256GB of ECC/nonECC memory. It provides massive expansion capabilities, with 35 PCIe lanes and 5x 10GbE ports., plus one 2.5GbE interface. The CPU-190-01 is the ideal plaform for workload consolidation, supporting Linux and Windows 10 IoT Enterprise. Highly reliable and compact, it can power AI workloads at the Edge, thanks to Intel Deep Learning Boost (VNNI) and AVX-512 acceleration. Support for ECC memory and Virtual Raid on CPU make the CPU-190-01 a very reliable for server class applications even in harsh operating environments.
Offering
The ReliaCOR 34-19 is a rugged 4U, rackmount Edge Server featuring the Intel® Xeon ® D-1700. With up to 256GB of ECC/nonECC DDR4 memory and high core density, it is a workhorse that supports workload consolidation and virtualization at the Edge. Two removable U.2 NVMEs and plenty high performance network interfaces (4x 10GbE, 4x 2.5GbE) and support for TSN and fiber optic provide reliable resources in demanding industrial applications. The ReliaCOR 34-19 is very expandable, with one x16 G4, four x4 G4 and two x1 G3 PCIe slots, plus one M.2 SATA/NVME x4 socket
