Offerings
Offering
Innodisk Embedded SO-DIMM modules DDR4 ECC SODIMM offers the industry's fastest memory speed with 3200MT/s, and it is fully compatible with the Intel® Purely platform. The modules come equipped with 30μ” Gold Fingers, include single-bit error correction and are designed for networking and server use. All are available in 4GB, 8GB, 16GB, and 32GB capacities. 2133MT/s, 2400MT/s, 2666MT/s, 2933MT/s modules are also available. ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Product features: small outline dual In-line memory module, single error correction and detection available. Fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, anti-sulfuration protection against harsh environments JEDEC standard 1.2V (1.26V-1.14V), operating environment : 0°C - 85°C30μ” gold fingerRoHS compliance CE/FCC certification.
Offering
Overview: The JESD79-5 DDR5 SDRAM specification has significant improvements in capacity, speed, and voltage. By structure-wise, the power management IC (PMIC) is moved onto the DIMM, reducing redundant power management circuitry on the motherboard for unused DIMM slots in previous generations. The DDR5 specification is bringing the maximum potential capacity for a single DDR5 DIMM to 128GB, a theoretical maximum transfer speed of 6400MT/s which is doubling the rate of DDR4, along with the improved power consumption as 1.1V.Specification: The modules comply with all relevant JEDEC standards and are available in 16GB and 32GB capacities, as 4800MT/s. Product features: high capacity and speed (maximum potential up to 128GB & 6400MT/s), fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, on module power management IC (JEDEC standard: 1.1V), operating environment: 0°C - 85°C.
Offering
Overview:DDR4 UDIMM offers the industry's fastest memory speed with 3200MT/s - the perfect fit for any surveillance, automation, and embedded application. The modules comply with all relevant JEDEC standards and are available in 4GB, 8GB, 16GB, and 32GB capacities. 2133MT/s, 2400MT/s, 2666MT/s, 2933 MT/s, and 3200MT/s modules are also available. Product features: fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, anti-sulfuration protection against harsh environments JEDEC standard 1.2V (1.26V-1.14V), operating environment : 0°C - 85°CRoHS compliance CE/FCC certification.
Offering
Overview:DDR4 ECC UDIMM VLP offers a low profile design and the industry's fastest memory speed with 3200MT/s. The modules come equipped with 30μ” Gold Fingers, include single-bit error correction and are designed for networking and server use. The modules are available in 4GB, 8GB, and 16GB capacities. 2133MT/s, 2400MT/s, 2666MT/s and 2933MT/s modules are also available. VLP modules are specialized for use in 1U systems, such as blade server data centers, where system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact. ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use Hamming Code or Triple Modular Redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Product features: very low profile specialized for use in 1U system, single error correction and detection available, fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, anti-sulfuration protection against harsh environments JEDEC standard 1.2V (1.26V-1.14V), operating environment : 0°C - 85°C30μ” gold fingerRoHS Compliance CE/FCC certification.
Offering
Designed for industrial systems, Innodisk’s Wide Temperature DRAM modules are best suited for applications that must work in extreme temperatures. These modules use industrial-grade SDRAM components with 30u” gold finger to ensure that the memory maintains its high-quality signal, even at temperatures as low as -40ºC or as high as 85ºC.Overview:DDR4 WT (wide temperature) UDIMM offers a compact design and the industry's fastest memory speed with 3200MT/s - the perfect fit for any in-vehicle, surveillance, automation, and embedded application. The modules comply with all relevant JEDEC standards, can operate in temperatures from -40ºC to 85ºC, and are available in 4GB, 8GB, 16GB, and 32GB capacities. 2133MT/s, 2400MT/s, 2666MT/s, and 2933MT/s modules are also available. Features JEDEC standard 1.2V(1.26V-1.14V).Power supplyJEDEC standard 288-pin dual in-line memory module 8-bit pre-fetch, on die termination with ODT pin Bi-directional differential data strobe, average refresh period 7.8us at lower than TCASE 85°C, 3.9us at 85°C
Offering
Overview:DDR3 ECC SODIMM ULP is an ultra-low-profile, compact industrial memory module that provides lasting performance, and is designed for the server, telecom, and networking markets. The modules come equipped with 30μ” Gold Fingers and include single-bit error correction. 2GB and 4GB capacities are available, as well as data transfer rates of 1333MT/s and 1600MT/s. ULP modules are specialized for use in 1U systems, such as blade server data centers, where system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact. ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Product features: Small outline dual In-line memory module, ultra-Low profile feature specialized for use in 1U system single error correction and detection available, fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards, JEDEC standard 1.5V (1.425V-1.575V) & 1.35V (1.28V-1.45V)operating environment : 0°C - 85°C30μ” gold finger RoHS compliance CE/FCC certification.
Offering
Overview:DDR4 XR-DIMM is Innodisk's most robust memory module - perfect for critical-mission applications and harsh environments. Furthermore, both ECC and Wide Temperature ( -40ºC to 85ºC) features are available to further optimize the module if needed. With its 300-pin socket connector, Innodisk’s XR-DIMM exceeds the pin number standard established by the SFF Special Interest Group (SFF-SIG), ensuring a firm connection between the CPU and DRAM module. The series includes 8GB and 16GB capacities and transfer rates of 2400 MT/s. ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Product features: customized connector prevents DIMM from coming loose under challenging conditions, equipped with 2 mounting holes to ensure a firm connection single error correction and detection available, fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards, anti-sulfuration protection against harsh environments. Designed for aerospace and mission-critical applications and other harsh environment, usage JEDEC standard 1.2V (1.26V - 1.14V). Operating environment: -40°C - 85°CRoHS compliance CE/FCC certification for the XR DIMM, all features can be customized which also requires establishing a newly customized project line. We suggest first assessing if the product specifications are in accordance with your needs.
Offering
Overview:DDR3 SODIMM VLP is a compact memory module that offers a very low-profile design, and it is fully compatible with 1U server applications and other small-scale devices. The modules comply with all relevant JEDEC standards and are available in 2GB, 4GB and, 8GB capacities, with data transfer rates of 1333MT/s, 1600MT/s, and 1866MT/s. VLP modules are specialized for use in 1U systems, such as blade server data centers, where system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact. Product features: small outline dual In-line memory module very low profile specialized for use in 1U system. Fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards JEDEC standard 1.5V (1.425V-1.575V) & 1.35V (1.28V-1.45V), operating environment : 0°C - 85°CRoHS compliance CE/FCC certification.
Offering
Overview:DDR3 ECC SODIMM memory(small outline) is an industrial standards memory module that provides lasting performance and is designed for the server and networking markets. DDR3 ECC SODIMM memory comes equipped with 30μ” Gold Fingers and includes single-bit error correction. 2GB, 4GB, and 8GB capacities are available, as well as data transfer rates of 1066MT/s, 1333MT/s, 1600MT/s, and 1866MT/s. ECC memory modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC memory modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Product features: small outline dual In-line memory module, single error correction and detection available, fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards JEDEC standard 1.5V (1.425V-1.575V) & 1.35V (1.28V-1.45V). Operating environment : 0°C - 85°C30μ” gold fingerRoHS, complianceCE/FCC certification.
Offering
Overview:DDR4 WT (wide temperature) RDIMM offers the industry's fastest memory speed with 3200MT/s, and it is fully compatible with the Intel® Purley platform. The modules come equipped with 30μ” gold finger and include single-bit error correction and a register to enhance clock, command, and control signals. The modules comply with all relevant JEDEC standards and can operate in temperatures from -40ºC to 85ºC. All are available in 4GB, 8GB, and 16GB capacities, while the 2133MT/s, 2400MT/s and 2666MT/s modules also include 32GB.ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Product features: Register that enhances clock, command, and control signals single error correction and detection available, fully tested and optimized for stability and performance uses original IC to meet strict industrial standards, anti-sulfuration protection against harshe environments JEDEC standard 1.2V (1.26V-1.14V), operating environment: -40°C - 85°C30μ” gold finger RoHS compliance CE/FCC certification.
Offering
Overview:DDDR3 ECC UDIMM VLP is a very low-profile and industrial memory module that provides lasting performance and is designed for the server and networking market. The modules come equipped with 30μ” gold fingers and include single-bit error correction. 2GB, 4GB and, 8GB capacities are available, as well as data transfer rates of 1333MT/s, 1600MT/s, and 1866MT/s. VLP modules are specialized for use in 1U systems, such as blade server data centers, where system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact. ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Specifications: very low profile specialized for use in 1U system, single error correction and detection available. Fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards JEDEC standard 1.5V (1.425V-1.575V) & 1.35V (1.28V-1.45V), operating environment : 0°C - 85°C30μ” gold finger RoHS compliance CE/FCC certification.
Offering
Overview:DDR3 UDIMM is an industrial memory module that provides lasting performance and is designed for surveillance, automation, and embedded markets. The modules comply with all relevant JEDEC standards and are available in 2GB, 4GB, and 8GB capacities, and with data transfer rates of 1066MT/s, 1333MT/s, 1600MT/s, and 1866MT/s. Product features: fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards JEDEC standard 1.5V (1.425V -1.575V) & 1.35V (1.28V-1.45V), operating environment : 0°C - 85°CRoHS compliance CE/FCC certification.
Offering
Overview:DDR4 Ultra-temperature SODIMM offers a compact design and the industry's fastest memory speed with 3200MT/s - the perfect fit for any in-vehicle, surveillance, automation and embedded application. The modules comply with all relevant JEDEC standards, can operate in temperatures from -40ºC to 125ºC, and are available in 16GB and 32GB capacities. 2133MT/s, 2400MT/s 2666MT/s and 2933MT/s modules are also available. Features small outline dual In-line memory module, fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, anti-sulfuration protection against harsh environments JEDEC standard 1.2V (1.26V-1.14V), operating environment: -40°C - 125°C45μ” gold fingerRoHS compliance CE/FCC certification, drop test ISTA-1A (International Safe Transit Association), gold finger insert and extract 100 times, thermal shock (MIL-STD-810G).
Offering
Overview:DDR4 ECC SODIMM VLP is a compact and a very low-profile module that offers the industry's fastest memory speed with 2666MT/s, and it is fully compatible with the Intel® Purley platform and 1U devices. The modules come equipped with 30μ” Gold Fingers, include single bit error correction and is designed for networking and server use. All are available in 4GB and 8GB capacities. 2400MT/s module is also available. VLP DIMM modules are specialized for use in 1U systems, such as blade server data centers, where system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact. ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use Hamming Code or Triple Modular Redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Specifications: small outline dual In-line memory module, very low profile specialized for use in 1U system, single error correction and detection available, fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, anti-sulfuration protection against harsh environments JEDEC standard 1.2V (1.26V-1.14V), operating environment : 0°C - 85°C30μ” gold finger RoHS compliance CE/FCC certification.
Offering
Overview:DDR4 RDIMM VLP is a compact and a very low-profile module that offers the industry's fastest memory speed with 3200MT/s, and it is fully compatible with the Intel® Purley platform and 1U devices. The modules come equipped with 30μ” Gold Fingers and include single bit error correction and a register to enhance clock, command, and control signals. All are available in 4GB, 8GB, 16GB and 32GB capacities. 2133MT/s, 2400MT/s, 2666MT/s, and 2933MT/s modules are also available. VLP DIMM modules are specialized for use in 1U systems, such as blade server data centers, where system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact. ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Features: very low profile specialized for use in 1U system register for enhancing clock, command, and control signals, single error correction and detection available, fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards, anti-sulfuration protection against harsh environments JEDEC standard 1.2V (1.26V-1.14V), operating environment : 0°C - 85°C30μ” gold fingerRoHS compliance CE/FCC certification.
Offering
Overview:DDR3 ECC UDIMM is an industrial memory module that provides lasting performance and is designed for the server and networking markets. The modules come equipped with 30μ” Gold Fingers and include single-bit error correction. 2GB, 4GB, and 8GB capacities are available, as well as data transfer rates of 1066MT/s, 1333MT/s, 1600MT/s, and 1866MT/s. ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Specifications: single error correction and detection available. Fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, JEDEC standard 1.5V (1.425V-1.575V) & 1.35V (1.28V-1.45V)operating environment : 0°C - 85°C30μ” gold finger RoHS compliance CE/FCC certification.
Offering
Overview: The JESD79-5 DDR5 SDRAM specification has significant improvements in capacity, speed, and voltage. By structure-wise, the Power Management IC (PMIC) is moved onto the DIMM, reducing redundant power management circuitry on the motherboard for unused DIMM slots in previous generations. The DDR5 specification is bringing the maximum potential capacity for a single DDR5 DIMM to 128GB, a theoretical maximum transfer speed of 6400MT/s which is doubling the rate of DDR4, along with the improved power consumption as 1.1V.The modules come equipped with 30μ” Gold Fingers, and another significant structural change is dual-channel DIMM architecture. For DDR5, each DIMM has two 40-bit channels (32 data bits plus 8 ECC data bits). Two independent subchannels improve memory access efficiency, leading to greater speeds with higher efficiency. The modules comply with all relevant JEDEC standards and are available in 16GB and 32GB capacities, as 4800MT/s. Specification: high capacity and speed (maximum potential up to 128GB & 6400MT/s), small outline dual In-line memory module, single error correction and detection available, fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, on module power management IC (JEDEC Standard: 1.1V)30μ” gold finger, operating environment: 0°C - 85°C.
Offering
Overview:DDR3 UDIMM VLP is a memory module that offers a very low-profile design, and it is fully compatible with 1U server applications and other small-scale devices. The modules comply with all relevant JEDEC standards and are available in 2GB, 4GB, and 8GB capacities and with data transfer rates of 1066MT/s, 1333MT/s, 1600MT/s, and 1866MT/s. VLP modules are specialized for use in 1U systems, such as blade server data centers, where system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact. Specifications: very low profile specialized for use in 1U system, fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards- JEDEC standard 1.5V (1.425V-1.575V) and 1.35V (1.28V-1.45V), operating environment : 0°C - 85°CRoHS compliance CE/FCC certification.
Offering
Innodisk Embedded ECC U-DIMM modules are general DRAM modules meant to be used as standard products for general embedded applications such as IPC and PC systems. These modules are compliant with JEDEC standards and are available in DDR1, DDR2, DDR3, and DDR4.ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Specifications series: standard module type: DDR4 long DIMM data rate: 2133 MT/s, 2400 MT/s, 2666 MT/s, 2933 MT/s, 3200 MT/s Capacity: 4GB, 8GB, and 16GBFunction: ECC unbuffered memory pin number: 288pin. Width: 72 Bits. Voltage: 1.2VPCB. Height: 1.23 Inches. Operation temperature: 0°C - +85°C features JEDEC standard 1.2V(1.26V-1.14V). Power supplyJEDEC standard 288-pin dual In-line memory module8-bit pre-fetch, on die termination with ODT pin Bi-directional differential data strobe, average refresh period 7.8us at lower than TCASE 85°C, 3.9us at 85°C
Offering
Overview:DDR4 Ultra-temperature SODIMM offers a compact design and the industry's fastest memory speed with 3200MT/s - the perfect fit for any in-vehicle, surveillance, automation and embedded application. The modules comply with all relevant JEDEC standards, can operate in temperatures from -40ºC to 125ºC, and are available in 16GB and 32GB capacities. 2133MT/s, 2400MT/s 2666MT/s and 2933MT/s modules are also available. ECC modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Features: small outline dual In-line memory module single error correction and detection available fully tested and optimized for stability and performance uses original IC to meet strict industrial standards, anti-sulfuration protection against harsh environments EDEC standard 1.2V (1.26V-1.14V), operating environment: -40°C - 125°C45μ” gold finger RoHS compliance CE/FCC certification drop test ISTA-1A (International Safe Transit Association)gold finger insert and extract 100 times thermal shock (MIL-STD-810G).
Offering
Overview:DDR3 SODIMM memory (small outline) is a compact industrial standards memory module that fits neatly into any embedded, surveillance, and automation setup. DDR3 SODIMM memory complies with all relevant JEDEC standards and are available in 1GB, 2GB, 4GB, and 8GB capacities and with data transfer rates of 1066MT/s, 1333MT/s, 1600MT/s, and 1866MT/s. Specifications: small outline dual In-line memory module fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards JEDEC standard 1.5V (1.425V-1.575V) & 1.35V (1.28V-1.45V), operating environment : 0°C - 85°CRoHS compliance CE/FCC certification.
Offering
Overview:The JESD79-5 DDR5 specification has significant improvements in capacity, speed and voltage. By structure wise, the Power Management IC (PMIC) is moved onto the DIMM, reducing redundant power management circuitry on the motherboard for unused DIMM slots in previous generations. The DDR5 specification is bringing the maximum potential capacity for a single DDR5 DIMM to 128GB, a theoretical maximum transfer speed of 6400MT/s which is doubling the rate of DDR4, along with the improved power consumption as 1.1V.The modules come equipped with 30μ” Gold Fingers. and another significant structural change is dual-channel DIMM architecture. For DDR5, each DIMM has two 40-bit channels (32 data bits plus 8 ECC data bits). Two independent subchannels improve memory access efficiency, leading to greater speeds with higher efficiency. The modules comply with all relevant JEDEC standards and are available in 16GB and 32GB capacities, as 4800MT/s. Specification: high capacity and speed (maximum potential up to 128GB & 6400MT/s),register for enhancing clock, command, and control signals single-bit, error correction and detection available, fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, on module power management IC (JEDEC standard: 1.1V),operating environment: 0°C - 85°C, anti-sulfuration protection against harsh environments30μ” gold fingerRoHS compliance CE/FCC certification.
Offering
Overview:DDR4 registered SO-DIMM offers the industry's fastest memory speed with 2666MT/s, and it is fully compatible with the Intel® platform. The modules come equipped with 30μ” Gold Fingers and include single bit error correction and a register to enhance clock, command, and control signals. All are available in 8GB, and 16GB capacities. 2133MT/s, 2400MT/s, 2666MT/s modules are also available. Registered modules are designed to detect and correct single-bit errors that occur during data storage and transmission. ECC modules use hamming code or triple modular redundancy for error detection and correction, and manage error corrections on their own, without requesting that the data source resend original data. Features JEDEC standard 1.2V(1.26V-1.14V) Power supply JEDEC standard 260-pin dual In-line memory module8-bit pre-fetch on die termination with ODT pin Bi-directional differential data strobe average refresh period 7.8us at lower than TCASE 85°C, 3.9us at 85°C
Offering
Overview: The JESD79-5 DDR5 SDRAM specification has significant improvements in capacity, speed and voltage. By structure wise, the Power Management IC (PMIC) is moved onto the DIMM, reducing redundant power management circuitry on the motherboard for unused DIMM slots in previous generations. The DDR5 specification is bringing the maximum potential capacity for a single DDR5 DIMM to 128GB, a theoretical maximum transfer speed of 6400MT/s which is doubling the rate of DDR4, along with the improved power consumption as 1.1V. The modules comply with all relevant JEDEC standards and are available in 16GB and 32GB capacities, as 4800MT/s. Specification: high capacity and speed (maximum potential up to 128GB & 6400MT/s), small outline dual In-line memory module fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, on module power management IC (JEDEC standard: 1.1V), operating environment: 0°C - 85°C, anti-sulfuration protection against harsh environments RoHS compliance CE/FCC certification.
Offering
Overview: The JESD79-5 DDR5 SDRAM specification has significant improvements in capacity, speed and voltage. By structure wise, the Power Management IC (PMIC) is moved onto the DIMM, reducing redundant power management circuitry on the motherboard for unused DIMM slots in previous generations. The DDR5 specification is bringing the maximum potential capacity for a single DDR5 DIMM to 128GB, a theoretical maximum transfer speed of 6400MT/s which is doubling the rate of DDR4, along with the improved power consumption as 1.1V.The modules come equipped with 30μ”gold fingers, and another significant structural change is dual-channel DIMM architecture. For DDR5, each DIMM has two 40-bit channels (32 data bits plus 8 ECC data bits). Two independent subchannels improve memory access efficiency, leading to greater speeds with higher efficiency. The modules comply with all relevant JEDEC standards and are available in 16GB and 32GB capacities, as 4800MT/s. Specification: high capacity and speed (maximum potential up to 128GB & 6400MT/s), single error correction and detection available, fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, on module power management IC (JEDEC standard: 1.1V)30μ” gold finger operating environment: 0°C - 85°C.
Offering
Innodisk Embedded VLP modules are general DRAM modules meant to be used as standard products for general embedded applications such as IPC and PC systems. These modules are compliant with JEDEC standards and are available in DDR1, DDR2, DDR3, and DDR4.Low-Profile DIMM modules are specialized for use in 1U systems, such as blade server data centers, where the system height is lower than 1.18 inches. The design of these modules improves airflow inside a compact system and reduces thermal impact. Specifications series: very low-profile (VLP)module type: DDR4 LONG DIMM data rate: 2133 MT/s, 2400 MT/s, 2666 MT/s, 2933MT/s, 3200 MT/s capacity: 4GB, 8GB, and 16GB. Function: Non-ECC unbuffered memory pin number: 288pin. Width: 64Bits. Voltage: 1.2VPCB. Height: 0.738 inch. Operation temperature: 0°C - +85°C. Features: JEDEC standard 1.2V(1.14V-1.26V).Power supply JEDEC standard 288-pin dual in-line memory module8-bit pre-fetch, on die termination with ODT pinBi-directional differential data strobe, average refresh period 7.8us at lower than TCASE 85°C, 3.9us at 85°C
Offering
Innodisk embedded U-DIMM modules are general DRAM modules meant to be used as standard products for general embedded applications such as IPC and PC systems. These modules are compliant with JEDEC standards and available in DDR1, DDR2, DDR3 and DDR4.Specifications series: standard module type: DDR4 long DIMM data rate: 2133 MT/s, 2400 MT/s, 2666 MT/s capacity: 4GB, 8GB, and 16GB. Function: non-ECC unbuffer memory pin number: 288pin. Width: 64Bits. Voltage: 1.2VPCB. Height: 1.23 Inches. Operation temperature: 0°C - +85°C features JEDEC standard 1.2V(1.26V-1.14V) power supply JEDEC standard 288-pin dual in-line memory module8 bit pre-fetch. On die termination with ODT pinBi-directional differential data strobe average refresh period 7.8us at lower then TCASE 85°C, 3.9us at 85°C
Offering
Innodisk provides a range of exclusive and advanced DRAM modules to fulfill special needs, such as for rugged environments and special mini-sizes. VLP Mini DIMM modules are designed with 17.9mm high dimensions specifically for networking applications. They are compliant with JEDEC standards and are designed to improve thermal resistance. With the ECC function, the VLP Mini DIMM also ensures that data is corrected when corrupted data bits are found during data retrieval. Offered in capacities from 2, 4, and 16GB.Speeds from DDR3 to DDR4 (1333, 1600, 2133, and 2400 MT/s).Functionalities for registered, ECC, and non-ECC.
Offering
Designed for industrial systems, Innodisk’s Wide Temperature DRAM modules are best suited for applications that must work in extreme temperatures. These modules use industrial-grade SDRAM components with 30u” gold finger to ensure that the memory maintains its high-quality signal, even at temperatures as low as -40ºC or as high as 85ºC.Overview:DDR4 WT (wide temperature) SODIMM offers a compact design and the industry's fastest memory speed with 3200MT/s - the perfect fit for any in-vehicle, surveillance, automation, and embedded application. The modules comply with all relevant JEDEC standards, can operate in temperatures from -40ºC to 85ºC, and are available in 4GB, 8GB, 16GB, and 32GB capacities. 2133MT/s, 2400MT/s and 2666MT/s modules are also available. Features JEDEC standard 1.2V(1.26V-1.14V). Power supply JEDEC standard 260-pin dual in-line memory module8-bit pre-fetch, on die termination with ODT pinBi-directional differential data strobe, average refresh period 7.8us at lower than TCASE 85°C, 3.9us at 85°C
Offering
Innodisk Embedded SO-DIMM modules are general DRAM modules meant to be used as standard products for general embedded applications such as IPC and PC systems. These modules are compliant with JEDEC standards and available in DDR1, DDR2, DDR3 and DDR4.Small-outline DIMMs (SO-DIMM) modules are general DRAM modules meant to be uses as standard products for embedded applications with limited space. These modules are compliant with JEDEC standards and help in eliminating the need for changing designs due to space issues. Specifications series: standard module type: DDR4 long DIMM data rate: 2133 MT/s, 2400 MT/s, 2666 MT/s capacity: 4GB, 8GB, and 16GB function: non-ECC unbuffer memory. Pin number: 288pin. Width: 64Bits. Voltage: 1.2VPCB. Height: 1.23 Inches, Operation temperature: 0°C - +85°C.Features:JEDEC standard 1.2V(1.26V - 1.14V) power supply JEDEC standard 288-pin dual In-line memory module8 bit pre-fetch. On die termination with ODT pin Bi-directional differential data strobe. Average refresh period 7.8us at lower then TCASE 85°C, 3.9us at 85°C
Offering
Overview: DDR5 WT UDIMM ULP offers an ultra low-profile design and the industry's fastest memory speed with 4800MT/s, and it is fully compatible with the Intel® Purely platform and 1U devices. The modules comply with all relevant JEDEC standards and are available in 16GB, and 32GB capacities. VLP modules are specialized for use in 1U systems, such as blade server data centers, where the system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact.DR4, along with the improved power consumption of 1.1V. The modules come equipped with 30μ” Gold Fingers, and another significant structural change is dual-channel DIMM architecture. For DDR5, each DIMM has two 40-bit channels (32 data bits plus 8 ECC data bits). Two independent subchannels improve memory access efficiency, leading to greater speeds with higher efficiency. The modules comply with all relevant JEDEC standards and are available in 16GB and 32GB capacities, as 4800MT/s. Very low profile specialized for use in 1U system, single error correction and detection available, fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards on module power management IC (JEDEC Standard: 1.1V) 30μ” gold finger, operating environment: -40°C - 95°C (Tc),anti-sulfuration protection against harsh environments RoHS compliance CE/FCC certification.
Offering
Overview: DDR5 Ultra-temperature SODIMM offers a compact design and the industry's fastest memory speed with 4800MT/s - the perfect fit for any in-vehicle, surveillance, automation, and embedded application. The modules comply with all relevant JEDEC standards and can operate from -40ºC to 105ºC. From the JEDEC standard, the DDR5 specification brings the maximum potential capacity for a single DDR5 DIMM to 128GB, a theoretical maximum transfer speed of 6400MT/s which is doubling the rate of DDR4, along with the improved power consumption as 1.1V.Specification: The modules from Innodisk comply with all relevant JEDEC standards and are available in 8GB and 16GB capacities, as 4800MT/s. Product features: High capacity and speed fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards, on module power management IC (JEDEC standard: 1.1V). Anti-sulfuration protection against harsh environments30μ” gold finger RoHS Compliance CE/FCC certification, operating environment: -40°C - 105°C (Tc).
Offering
Overview: The JESD79-5 DDR5 specification has significant improvements in capacity, speed, and voltage. By structure-wise, the Power Management IC (PMIC) is moved onto the DIMM, reducing redundant power management circuitry on the motherboard for unused DIMM slots in previous generations. The DDR5 specification brings the maximum potential capacity for a single DDR5 DIMM to 128GB, a theoretical top transfer speed of 6400MT/s which is doubling the rate of DDR4, along with the improved power consumption of 1.1V. The modules come equipped with 30μ” Gold Fingers. and another significant structural change is dual-channel DIMM architecture. For DDR5, each DIMM has two 40-bit channels (32 data bits plus 8 ECC data bits). Two independent subchannels improve memory access efficiency, leading to greater speeds with higher efficiency. The modules comply with all relevant JEDEC standards and are available in 16GB and 32GB capacities, as 4800MT/s. Specification: high capacity and speed (maximum potential Up to 128GB & 6400MT/s)register for enhancing clock, command, and control signals, single-bit error correction and detection available. Fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards, on module Power Management IC (JEDEC Standard: 1.1V),operating environment: -40°C - 95°C (Tc), anti-sulfuration protection against harsh environments30μ” gold finger RoHS compliance CE/FCC certification.
Offering
Overview: The JESD79-5 DDR5 SDRAM specification has significant improvements in capacity, speed, and voltage. By structure-wise, the Power Management IC (PMIC) is moved onto the DIMM, reducing redundant power management circuitry on the motherboard for unused DIMM slots in previous generations. The DDR5 specification brings the maximum potential capacity for a single DDR5 DIMM to 128GB, a theoretical maximum transfer speed of 6400MT/s which is doubling the rate of DDR4, along with the improved power consumption as 1.1V. The modules comply with all relevant JEDEC standards and are available in 16GB and 32GB capacities, as 4800MT/s. Specification: high capacity and speed (maximum potential up to 128GB & 6400MT/s)small outline dual In-line memory module, fully tested and optimized for stability and performance, uses original IC to meet strict industrial standards, on module power management IC (JEDEC standard: 1.1V). Operating environment: -40°C - 95°C (Tc) anti-sulfuration protection against harsh environment sRoHS compliance CE/FCC certification.
Offering
Overview: The JESD79-5 DDR5 SDRAM specification has significant improvements in capacity, speed, and voltage. By structure-wise, the Power Management IC (PMIC) is moved onto the DIMM, reducing redundant power management circuitry on the motherboard for unused DIMM slots in previous generations. The DDR5 specification brings the maximum potential capacity for a single DDR5 DIMM to 128GB, a theoretical maximum transfer speed of 6400MT/s which is doubling the rate of DDR4, along with the improved power consumption of 1.1V.Specification: The modules comply with all relevant JEDEC standards and are available in 8GB, 16GB, and 32GB capacities, as 4800MT/s. Product features high capacity and speed (maximum potential up to 128GB & 6400MT/s). Fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards, on module power management IC (JEDEC standard: 1.1V),operating environment: -40°C - 95°C (Tc).
Offering
Overview: DDR5 ECC UDIMM VLP offers a very low-profile design and the industry's fastest memory speed with 4800MT/s, and it is fully compatible with the Intel® Purely platform and 1U devices. The modules comply with all relevant JEDEC standards and are available in 16GB, and 32GB capacities. VLP modules are specialized for use in 1U systems, such as blade server data centers, where system height is lower than 1.18 inches. The design of these modules improves airflow inside the system and reduces thermal impact.DR4, along with the improved power consumption of 1.1V. The modules come equipped with 30μ” gold fingers, and another significant structural change is dual-channel DIMM architecture. For DDR5, each DIMM has two 40-bit channels (32 data bits plus 8 ECC data bits). Two independent subchannels improve memory access efficiency, leading to greater speeds with higher efficiency. The modules comply with all relevant JEDEC standards and are available in 16GB and 32GB capacities, as 4800MT/s. Very low profile specialized for use in 1U system. Single error correction and detection available, fully tested and optimized for stability and performance. Uses original IC to meet strict industrial standards on module power management IC (JEDEC standard: 1.1V) 30μ” gold finger operating environment: 0°C - 95°C (Tc) anti-sulfuration protection against harsh environments RoHS complianceCE/FCC certification.
