Offerings
Offering
The CASwell CAR-5058 rackmount appliance is based on two Intel® Xeon® high-end processors and a highly configurable network architecture that allows up to 68 high-speed Ethernet ports together with up to four hard drives or SSDs.
Offering
The CASwell CAF-0101 is a fanless networking appliance in a compact desktop format. It offers superior energy efficiency in a small form factor with its new Intel Atom® processor and four Gigabit Ethernet ports plus supporting Wi-Fi expansion option. The CAF-0101 works best when used for routing and other networking purposes in small to medium businesses (SMB) or small and home offices (SOHO), for example as a dedicated firewall to protect network and data against cyberattacks. The CAF-0101 Is based on the latest Intel Atom® x6000 processors with two or four cores. The latest Intel Atom® series of processors offers 70 percent more performance in single-threaded and 50 percent more speed in multithreaded workloads than the previous generation, the widely used Intel Atom® x5- and x7-3900 series. The production node was also improved to 10 nanometers, so the already good energy efficiency of the Intel Atom® series of processors was optimized even more. The CAF-0101 can be equipped with up to 16 GB of DDR4 SO-DIMM main memory with IBECC, uses fast eMMC storage and one SATA port for additional mass storage or SATA DOM. The system also offers optional support for Wi-Fi connectivity via mPCIe module. For wired networking, the CAF-0101 provides four Gigabit Ethernet RJ45 ports plus one RJ45 system console port. Trusted Platform Module is supported with an onboard TPM header. The new processors of the CAF-0101 support the Intel® OpenVINO™ toolkit, with pre-optimized libraries for artificial intelligence (AI), machine learning (ML), and computer vision acceleration. The new Intel® Edge Software Hub is also supported, so customers can acquire pre-optimized, deployment-ready software packages optimized for Industrial, Retail and Vision, all of which additionally offer customizability. The CASwell CAF-0101 is a cost-effective solution with balanced performance and upgrade options for SMB and SOHO to monitor network traffic, for bandwidth management or medical and dental imaging systems. This appliance can be configured according to customer demand.
Offering
Cloud Storage Servers (White Box)2x Intel Xeon Scalable Processors (Skylake-SP)24 x DDR4 ECC 2666MHz RDIMM2 x RJ45 GbE Ports, 2 x SFP+ 10GbE PortsM.2 SSDs & Rear 2.5” SSDs Slot for Boot DriveSupport Up to 5 Expansion CardsTPM Enabled DesignCASwell has introduced the new R-5211 high-end cloud storage servers to provide high processing performance, fast data access and flexible storage configurations by supporting a variety of drives at different form factors.This devices is based on two Intel Xeon Scalable Processors (Skylake) using the C622 platform controller hub (Lewisburg) and offering 24 DIMM slots for up to 768 GByte DDR4-2666 ECC main memory. These cloud storage servers are equipped with two Gigabit-Ethernet RJ-45 ports and two 10-Gigabit-Ethernet SFP+ ports. More network connections like dual 25-Gigabit-Ethernet can be added by using two PCI Express slots and five NIC expansion slots. There are two M.2 slots for implementing the operating system and server applications on a boot drive.Six PWM-controlled fans are making sure the system runs cool while two redundant power supplies provide security in case of failure. PMBus 1.2 is supported for digital management of the PSUs and the "Intelligent Platform Management Interface" (IPMI 2.0) is used for system monitoring and administration.The CASwell R-5211 is a 2U rackmount device that can be equipped with a variety of CPUs from the energy-efficient Intel Xeon Silver 4116 with 12 cores up to the highest-end Intel Xeon Platinum 8180 with 28 cores for ultimate performance. The R-5211 is available in two versions: The first one can be equipped with up to twelve conventional 3.5-inch hard drives with SATA or SAS interface while the second SKU can be used with up to 24 2.5-inch drives.The CASwell R-5211 are available in many different configurations so they can be equipped according to almost every customer need and storage or networking requirement.
Offering
The CASwell CAR-3080 rackmount appliance, a verified Intel® Select Solution for uCPE, was developed for multi-access edge computing with its multiple network connections while also offering high-speed Ethernet —a common requirement nowadays and even more in the future. As an Intel® Select Solution for uCPE, the CASwell CAR-3080 brings the powerful performance of Intel® Xeon® D processors to the network edge as part of a workload-optimized hardware and software stack that offers verified performance. The platform includes PCI Express 3.0 (PCIe 3.0) for easy upgrading and Intel® QuickAssist Technology (Intel® QAT) to accelerate encrypted data traffic, reduce overall data size and lower storage demands. All of this in a compact 1U device that easily fits into any rackmount cabinet.
Offering
10GbE SFP+ Bypass Network Adapter based on Intel Fortville XL710-BM2 LAN Controller with 2x SFP+ 10GbE Ports over Proprietary PCIe Gen3 x8 offering Bypass (Failover) Function
Offering
The CASwell CAR-5060 rackmount appliance is based on two third generation Intel® Xeon® Scalable Processors and a highly configurable network architecture that allows up to 64 high-speed Ethernet ports. It uses the manufacturer's own designed network configuration with up to eight PCI Express connected, proprietary (NIN) modules that each provides a maximum of eight high-speed Ethernet ports for 64 network connections overall. Storage modules with either one 3.5" or two 2.5" hard drives or SSDs are also available. Each network or storage module is connected to the processors by PCIe 4.0 x8 interface introduced with the Intel® Xeon® SP Gen. 3 to provide extremely high bandwidth. Besides the modules there's also one PCI Express 4.0 x16 expansion slot that can be used for FPGA or GPU accelerators to support emerging machine learning and deep learning workloads with uncompromised bandwidth and lowest latency. Especially communication service providers, cloud service providers and enterprises with high internal networking workloads should benefit from using the CAR-5060. Network and security appliance companies can use the CAR-5060 as an upgraded next-generation unified threat management device.
Offering
Dual Port 40GbE QSFP+ Network Adapter: based on Intel Fortville XL710-AM2 LAN Controller, providing two QSFP+ 40 Gigabit Ethernet Ports by Proprietary PCIe Gen3 x8. This compact network interface module with dimensions of 85mm x 152mm x 16mm is ideal for CASwell's own rackmount network servers.
Offering
Dual Port 100-GbE QSFP+ Proprietary Adapter with Intel E810-CAM2 LAN Controller and two QSFP+ 100-GbE Ports
Offering
The CASwell CAF-0100 is a fanless multi-networking appliance in desktop format. It offers superior energy efficiency and high performance in a compact form factor with its new Intel Atom® processor and up to six high-speed Ethernet ports plus supporting Wi-Fi and mobile networks with 5G or 4G/LTE. The CAF-0100 is well suited for routing and other networking use in small to medium businesses (SMB) or small and home offices (SOHO), for example as dedicated firewall to protect network and data against unwanted intruders. The CAF-0100 Is based on the latest Intel Atom® x6000 processors with four cores but a model with two cores is also available for lighter usage. According to Intel®, this series of Intel Atom® processors offers 70 percent more performance in single-threaded and 50 percent more speed in multi-threaded workloads than the previous generation, the widely used Intel Atom® x5- and x7-3900 series like inside the fanless network appliance CAW-0111. The production node was also improved to 10 nanometer so the already good energy efficiency of the Intel Atom® series of processors gets even better. The CAF-0100 is also using up to 16 GB of DDR4 SO-DIMM main memory with IBECC, uses fast eMMC storage and has optional support for HDMI, Wi-Fi and 4G LTE or 5G mobile communication. Access to cellular networks can be provided by M.2 modules via a specific daughter board while WiFi can be made available will a miniPCI Express module. With WiFi the CAF-0100 offers five Gigabit Ethernet RJ45 ports but waiving Wi-Fi enables six Ethernet ports. The CAF-0100 furthermore supports Ethernet Bypass Gen. 4.4 which can be added by option. Trusted Platform Module is supported with the necessary TPM header onboard. Together with the new processors the CAF-0100 supports the Intel® OpenVINO™ toolkit, with pre-optimized libraries for artificial intelligence (AI), machine learning (ML), and computer vision acceleration. The new Intel® Edge Software Hub is also supported so customers can acquire pre-optimized deployment-ready software packages optimized for Industrial, Retail and Vision, all of which additionally offer customizability. The CASwell CAF-0100 is the ideal solution for SMB and SOHO to monitor network traffic, for bandwidth management or medical and dental imaging systems. This appliance can be configured according to customer demand.
Offering
The CAD-0280 desktop appliance is using the Intel Xeon D-1700 (Ice Lake-D) Series of SoC with two to ten processsor cores and constitures an excellent basis for compact and effective solutions for network security and management, loT Gateway, UTM and Firewalls. The CAD-0280 offers up to ten Ethernet ports with optional bypass functinaliy that can be configured with a maxmimum speed of 25 Gbit/s. Networking options can be extended to wireless conectivity with WiFi, 4G/LTE and 5G by mPCIe or M.2 expansion cards.
Offering
CAR-4030, the latest network communication security platform from CASwell Inc. is a 1U rackmount system based on 6th Generation Intel® Core™ processors E3/i7/i5/i3/Pentium® G3/G4 family and Intel® PCH C236 chipset. The CAR-4030 features four DDR4 DIMMs, up to 2133MHz memory; flexible user interface; up to 29 RJ45/SFP ports by three swappable CASwell NIP module and one standard NIC. It also supports other features including a maximum of four 2.5˝ SATA HDDs, one 3.5˝ SATA HDD, one CF, one SATA DOM, IPMI 2.0, management ports (RJ45µ USB), a maximum of four USB3.0 ports, and 250W ATX/280W Redundant 80PLUS power supply. The whole system is designed with an 85 percent field replaceable unit (FRU), including fan, power supply, NIC module and HDD tray, to provide a convenient maintenance solution.The CASwell CAR-4030 is implemented with front I/O flexibility and a multi-function design concept. Customers can select various combinations of 2.5˝ HDD/SSD, copper/fiber media, GbE/10GbE/40GbE and third-party hardware acceleration smart module. In addition, the system equips a graphical/character LCD display module with function buttons. Inside the system, CASwell has reduced physical cable/wire connections to maximize airflow and electronic signal quality.
Offering
The world’s leading manufacturer of extreme performance network communication appliance provider, is thrilled to announce CAR-4040 specifications for latest 8th Gen Intel® Core™ and Intel® Xeon® workstation processors built on the 8th generation (formerly Coffee Lake) microarchitecture and C246 chipset, has adopted a 14nm process design and support up to 6 core/ 12 threads. Intel® preliminary estimates 8th generation (formerly Coffee Lake) CPU is up to 45% faster than its 7th generation (formerly Kaby Lake) counterpart.For enterprise-class resiliency, the CAR-4040 has been designed for extreme performance, application-optimized, functionality and extensibility in a 1U rack mount system. With 34 PCIe Express lanes, the CAR-4040 can support Four Network Modular Cards (NIP) with one PCIE x 8 slot reserved for modular, configurable networking I/O and acceleration.CASwell’s CAR-4040 system platform is targeted at network function virtualization (NFV) and software defined networking (SDN) applications, as well as traditional network security applications, such as firewall, VPN, IDS/IPS, anti-spam, anti-virus, UTM and WAN, and network management applications such as Virtualized Data Center, ADC, QoS, server load balancer, wireless controller, and industrial automation control via Ethernet TCP/IP.Samples for products based on 8th generation (formerly Coffee Lake-S) will be available for customer test in June 2018.
Offering
The CASwell CAR-2090 in low-profile 1U form factor is an upgraded and enhanced successor of the widely adopted CAR-2080. This server system offers multiple configuration options for professional security applications like firewalls and unified threat management (UTM) to effectively protect company networks. The CAR-2090 is based on Intel®'s 10th core generation ("Comet Lake") and can be equipped with Xeon W-1200E or Core i3- to i9-10000 and even Pentium or Celeron processor models that provide up to 10 cores and 20 parallel threads while staying at or under 95 watts thermal design power. This server system offers two DIMM slots for up to 64GB DDR4-2933 main memory and ECC depending on CPU model and PCH. This ensures the solution can handle demanding and advanced network tasks while staying cool and energy-efficient. Depending on PCH choice by customer the CASwell CAR-2090 offers six or eight Gbit-Ethernet ports supporting two pairs of Network Bypass 4.0. This can be expanded to 20 GbE ports with an optional CASwell NIP or NIN module with up to eight network ports and one internal daughter board for four more Ethernet ports (RJ45 or SFP) when the Intel® W480E PCH is used. Both CASwell network module and daughter board are connected to the main system by high-speed PCI Express 3.0. By standard, the CAR-2090 features four internal SATA 3.0 ports for storage (one for SATADOM). When the W480E PCH is used, there is one M.2 slot available onboard for a fast PCIe NVMe or SATA SSD. The LCD module in the front of the device holds one 2.5-inch SATA disk tray for storage but that EZIO module can be changed to an ISAM module for two front swappable 2.5" SATA drives.Besides traditional network security applications such as firewall, VPN, IDS/IPS, anti-spam, anti-virus, UTM and WAN, the CASwell CAR-2090 can also be used for software defined networking (SDN) and network function virtualization (NFV) applications as well as network management applications such as virtualized data center, ADC, QoS, server load balancer, wireless controller, and industrial automation control via Ethernet TCP/IP.
Offering
CAF-0260 is a CA standard desktop fanless product based on Intel Atom® C3538/C3558 processor (Formerly Denverton platform) which is designed for SD-WAN and vCPE application with 4G/LTE and WiFi Function. Following key features are:SIM/Wi-Fi Function SupportIntel Atom® C3000 Series Processor (Formerly Denverton)DDR4 Memory10GbE SFP+ dual Ethernet Ports1x mPCIe Socket(s) for LTE Module1x M.2 Socket(s) for WiFi ModuleHigh Reliability and Low Noise Fanless Design
Offering
The CASwell CAR-3080 rackmount appliance can be equipped with ultra-fast networking connections of up to 40 Gbit/s and also offers nearly infinite Ethernet configurations with a maximum of 40 ports in this flat, low-rise 1U design. This setup is made possible by the unique design and combination of CASwell's Network Interface Plug-ins (NIP) and Network Interface Cards (NIC), all connected via high-speed PCI Express 3.0.The CASwell CAR-3080 by default comes with six Gigabit-Ethernet ports and two SFP+ ports for 10-Gbit-Ethernet but can be enhanced almost endlessly with a standard NIC connected by PCI Express x16 and the three patented NIPs that use PCIe x4/x8 for data transfer. Each NIP and the NIC can offer up to eight Gigabit-Ethernet ports of their own but are also available in different configurations with 10-GbE, 25-GbE or even 40-GbE ports. Optional bypass switches ensure that the network keeps running even during maintenance or in case of power outages. PoE options are also available when "Power over Ethernet" is needed besides delivering data – seemingly infinite possibilities of networking configurations!The CASwell CAR-3080 is based on the Intel Xeon D-2100 processing platform (Skylake) with four to 16 CPU cores and can be combined with up to 128 GByte DDR4-2400 main memory. The CPU comes with integrated Intel Quick Assist Technology (QAT) to accelerate encrypted data traffic in a secure network and to reduce overall data size and lower storage demands by faster real-time compression while at the same time relieving the CPU of some of the processing workloads. An optional "Trusted Platform Module" (TPM) for encryption, authentification and digital rights management is also available for the CAR-3080 and the whole system can be monitored by the "Intelligent Platform Management Interface" (IPMI 2.0).The CASwell CAR-3080 will be available soon and can be equipped according to almost every customer need and networking requirement. Please contact your local CASwell representative for any questions!
Offering
To aim the network market trend with rapid network bandwidth demand with MEC (Mobile Edge Computing), CAD-0255 is designed for SDN/vCPE/MEC Market with high performance. With Intel® Xeon® D platform, CAD-0255 can meet every customer's requirement from low end to high end. Following key features are: 1. Wi-Fi/LTE Wireless Communication Support 2. Intel® Xeon® D Series Processors 3. High Performance Desktop Appliance 4. Dual 10G SFP+ Ethernet Ports 5. 2x mPCIe Socket (SIM Slot Support) 6. TPM (Trusted Platform Module) Enabled Design
Offering
CAR-2070, the latest network communication security platform from CASwell Inc., is a 1U rackmount system featuring 14nm microarchitecture, the 6th generation Intel® Core™ processor and Intel® H110 chipset. The CAR-2070 features two DDR4 DIMMs, up to 2133MHz memory; flexible user interface; on board six ports with 2 segments bypass function and up to 14 RJ45/SFP/10GbE RJ45/SFP+/QSFP+ ports by one swappable CASwell NIC module. Other features include maximum of two 2.5˝ SATA HDDs and one 3.5’’ SATA HDD, RJ45 /Micro USB console and two USB ports, 150W single ATX power supply. The CASwell CAR-2070 is implemented with front I/O flexibility and a multi-function design concept. Customers can select various combinations of 2.5˝ HDD/SSD, copper/fiber media, GbE/10GbE/40GbE and third-party hardware acceleration smart module and one character LCD display module with function buttons. In addition, the system equips a device information card which user can read the MAC or SN information without turn the system over, and front panel appearance can stay tidy. Inside the system, CASwell has reduced physical cable/wire connections to maximize airflow and electronic signal quality.
Offering
CAF-1022 designed for rising demand of network usage can provide great network performance with compact design and adopting Intel® platform. The key of design is as following: 1. Integration of system performance. 2. Overall Heat dissipation system design 3. Easy assembly and energy conservation4. Simple architecture
Offering
CAF-0265 designed for rising demand of network usage can provide great network performance with compact design and adopting Intel® GRX-750 platform. The key of design is as following:1. Integration of system performance with on board memory and eMMC storage2. Overall Heat dissipation fanless system design3. Easy assembly and energy conservation4. Simple architecture5. Support with high performance SDN switch
Offering
Caswell's Industrial CAW series products are designed for wide deployment in application-specific environments, offering stability, longevity, high availability and a perfect balance between size, cost, performance and power consumption. Specifications: Intel Atom E3900 series (Formerly Apollo lake-I). PCIe switch for multi-ports. Mini-PCIe for a wireless solution. Bypass function with GbE RJ45. Dual power inputs and failure detection design. Available in the harsh environment -40-85c. DIN rail form factor Certification for smart grid (IEC-61850-3) & oil & gas (IECEx/ATEX/NRTL) application.
Offering
CAF-0250 is designed for rising demand of network usage can provide great network performance with compact design and adopting Intel® platform. The key of design is as following: Integration of system performance with on board Memory and eMMC storage Overall Heat dissipation Fanless system design Easy assembly and energy conservation Simple architecture Support with high performance SDN switch
Offering
The MEC-6300 is based on the Intel Atom Processor C3558R (Denverton-NS Refresh) with four cores running up to 2.4 GHz at only 17 watt thermal design power (TDP). Compared to the previous generation, the Atom 3558 , the 3558R reaches higher frequencies while keeping almost the same TDP, supports faster memory like DDR4-2400 instead of DDR4-2133 and provides 20 instead of 12 PCI Express 3.0 lanes for enhanced connectivity and bandwidth. Important for many industries is the support of Intel Quick Assist Technology (QAT) by the Intel Atom C3000 series because collecting data at the network edge and sending to the cloud requires encryption to keep the information protected from unauthorized access when operated outside corporate firewalls. Devices supporting QAT like the CASwell MEC-6300 can process encryption and decryption more than ten times faster than without QAT. For connectivity the MEC-6300 offers a variety of different networking options: Six Ethernet ports with up to 10 Gigabit, WiFi (5 GHz and 2.4 GHz) and cellular (mobile) networking with LTE and 5G. Wireless connectivity is supported by four outside antennas for 5G (sub6) and 18 inside antennas for LTE and WiFi. Internally the MEC-6300 offers one M.2 slot for expansion for 5G, LTE, SATA, storage, WiFi, DSL, Bluetooth and ZigBee but also for AI. Here, the system can be equipped with an Intel Movidius Myriad X Vision Processing Unit that uses artificial intelligence methods like neural networks for facial recognition in retail or for license plate examination at gas stations to accelerate the edge system with a balance of power efficiency and compute performance. The Intel Movidius Myriad X VPU features the Neural Compute Engine - a dedicated hardware accelerator for deep neural network inference - and is programmable with the Intel OpenVINO toolkit to provide the optimal solution for edge features that can benefit from AI or the underlying inference engine. Another reason for choosing the MEC-6300 is the support of OpenNESS. This open source software toolkit is inspired by the edge computing architecture and enables easy orchestration, network functions and access technologies. OpenNESS leverages major industry edge orchestration frameworks, such as Kubernetes and OpenStack, and provides an architecture that operates with 5G, LTE, WiFi, and wired networks - perfect for a multi-access, multi-wireless edge system like the CASwell MEC-6300. Overall the CASwell MEC-6300 is the optimal edge networking system for many use cases found throughout different industries due to its versatility and flexibility, numerous different connectivity options and its effective and efficient processing power in a rather compact form factor. Conceivable scenarios could be found in health care, retail, transportation, manufacturing or even smart city and home usage. The CASwell MEC-6300 will be offered in two versions - one for using indoors and one for outdoor deployment and wider temperature range. Please contact your local CASwell representative or sales for any questions.
