Offerings
Offering
The V2406C computers are compliant with EN 50155:2017 and EN 50121-4 for railway onboard and wayside applications. Designed for heavy-duty data processing tasks, the V2406C computers are built around an Intel® Core™ i7/i5/i3 or Intel® Celeron® high-performance processor and come with up to 32 GB RAM, one mSATA slot, and two hot-swappable HDD/SSD for storage expansion. For reliable connectivity in train-to-ground (T2G) applications, the computers are provided with two mPCIe wireless expansion slots and four SIM-card slots. These help establish redundant LTE/Wi-Fi connectivity, ensuring solid bidirectional communications between a fast-moving train and the wayside applications. In addition, preinstalled QMA cable for wireless modules can help reduce assembly efforts and ensure low RF leakage. For connecting with onboard and wayside systems and devices, V2406C computers are equipped with a rich set of interfaces including 2 Gigabit Ethernet ports, 4 RS-232/422/485 serial ports, 6 DIs, 2 DOs, and 4 USB 3.0 ports. In addition, the V2406C computers provide 1 VGA video output and 1 HDMI output with 4K resolution support.
Offering
The MPC-2070 7-inch panel computers with Intel Atom® processor E3800 series deliver a reliable and durable platform of wide versatility for use in industrial environments. With two software selectable RS-232/422/485 serial ports and two gigabit Ethernet LAN ports, the MPC-2070 panel computers support a wide variety of serial interfaces as well as high-speed IT communications, all with native network redundancy. The MPC-2070 series panel computers are designed with a wide, -40 to 70°C temperature range, and come with a fanless, streamlined enclosure designed for highly efficient heat dissipation, making this one of the most reliable industrial platforms available for harsh, hot, outdoor environments like oil and gas fields, or drilling platforms. The MPC-2070 also features a 1000-nit LCD panel offering a sunlight-readable, projected-capacitive, glove-friendly, multi-touch screen, providing an excellent user experience for applications outdoors. The MPC-2070 series is Microsoft Azure Certified for IoT. It can leverage the Microsoft reference configuration and has been tested to work with Microsoft Azure IOT services for your industrial IoT applications.
Offering
The Moxa MC-1100 series DIN-rail, fanless, x86 embedded computers are based on the Intel Atom® E3800 series processor, feature the most reliable I/O design to maximize connectivity, and support wireless modules (WiFi/3G/LTE), making them suitable for a diverse range of communication applications. Powered by a wide operating temperature range (-40 to 70°C) and Safety/EMI/EMS compliances, the MC-1100 series is ideal for intelligent computing and communication solutions in critical environments, including marine communication, oil & gas field site monitoring, and transportation. The MC-1100 series is Microsoft Azure Certified for IoT. It can leverage the Microsoft reference configuration and has been tested to work with Microsoft Azure IOT services for your industrial IoT applications.
Offering
The MPC-2120 12-inch panel PCs with Intel Atom® E3800 processor deliver a reliable platform of wide versatility for use in industrial environments. 12-inch panel computer Intel Atom® Processor: E3845 1.91 GHz or E3826 1.46 GHz -40 to 70°C wide-temperature design, no fan or heater 1000-nit sunlight-readable display Wide-range 10 to 36 VDC power input Class 1 Division 2, ATEX Zone 2, and IECEx certified DNV GL certified for marine applications
Offering
IEC 61850-3, IEEE 1613, and IEC 60255 compliant for power substation automation systems EN 50121-4 compliant for railway wayside applications 7th Generation Intel® Xeon® Processor2 Built-in SO-DIMM ECC DDR4 memory slot, up to total 32GB capacity 4 hot-swappable SSD slots; support Intel® RST RAID 0/1/5/10 Highly reliable design, supporting dual power and PRP/HSR technology (with PRP/HSR expansion module)1 PCIe x16, 1 PCIe x4, 2 PCIe x1, and 1 PCI slots for expansion modules Redundant power supply (100 to 240 VAC/VDC)
Offering
The MC-1220 Series rugged edge computers feature high-performance Intel® Core™ i7/i5/i3 processor and multiple expansion interfaces. The expansion interfaces can incorporate hardware accelerators, such as VPUs, and support Intel® OpenVINO™ toolkit for AIoT application development. Designed based on Moxa’s extensive expertise in building rugged computing platforms, the computers can operate in a -40 to 70°C wide operating temperature range and are C1D2/ATEX Zone 2 certified for deployments in outdoor and hazardous environments. In addition, the ultra-compact fanless computers are one of the world’s smallest industrial computers that come with Intel® Core™ i7 processors, making it easy to fit them in small cabinets at field sites. In remote applications, wireless connectivity is required for continuous communications with the control center. MC-1220 Series computers support multiple Wi-Fi/cellular connectivity options, eliminating the need for an additional wireless gateway, thereby saving cost and space. Furthermore, the computing platform features TPM 2.0 technology for enhanced hardware security.
