The SCB-1739 is a 1U Rack-Mount network appliance. It is based on Intel Atom® P5300/C5000 processor (Snowridge/Parkerridge) with increased CPU cores up to 24 for higher performance and better efficiency. The SCB-1739 has 2x channels DDR4 register ECC RDIMM (up to 2933 MHz), and maximum memory capacity is up to 128GB. With 32 PCI Express lanes, the SCB-1739 features up to two network expansion modules to support multiple different ethernet modules for building flexible configuration with options of 1/10/40/100 Gigabit fiber, Gigabit Copper/Fiber with or without BYPASS function. The strong IO elements of SCB-1739 include two management port (one for management, another for option IPMI function), a console port, USB ports, etc. In addition, the SCB-1739 also supports internal 2.5” SATA HDD/SSD and onboard m-SATA/miniPCI-E slot for network storage application.
Offering
The SCB-1942 is a 2U Rack-Mount hardware networking system. Supporting 4th Gen Intel® Xeon® Scalable Processors (Sapphire Rapids) and Intel® C741 PCH. The new generation platform provides remarkable performance with increased CPU cores (up to 60C per CPU) and 4 Ultra Path Interconnect (UPI) links up to 16 GT/s. The SCB-1942 supports 16x channels DDR5 register ECC RDIMM (up to 4800 MHz) and maximum memory capacity is up to 1.5TB. With 80 PCI express lanes per CPU, the SCB-1942 can support up to 8x PCIe x8 slots (4x PCIe Gen5 + 4x PCIe Gen4) for network expansion modules for flexible port configuration, such as 1/10/40/100 Gigabit fiber, Gigabit Copper/Fiber with or without BYPASS function. The SCB-1942 Series also provides the flexibility to change the 2x PCIe slots to 1x PCIe x16 slot for standard PCIe form factor which can install off-the-shelf add-on card for additional function required. It can support 400G NIC card installed such as Mellanox PCIe 5.0 NIC. The maximum ethernet bandwidth capacity is up to 1,200GbE.The strong IO elements of SCB-1942 include two management port (one for management, another for option IPMI function), a console port, USB ports, LEDs for power/HDD/2x GPIO. In addition, the SCB-1942 also supports two front hot-swappable 2.5” SATA HDDs/SSDs and onboard CompactFlash/m-SATA/mini-PCIe, M.2 slot for network storage application.
Offering
2U Rack-Mount Dual Intel® Skylake-SP/Cascade Lake Xeon® scalable series Processor and Intel® C621 PCH Network System, support DDR4 up to 384GB, 6x PCIe x8 slot for expansion LAN module, 2x 2.5" SATA HDD swappable, IPMI,FEATURES:Support Intel® Skylake-SP/Cascade Lake Xeon® scalable Series Processor, LGA3647Support Max 384GB DDR4 2400/2666MHz System MemoryMax support 6 x PCIe x8 slots for expansion LAN modules, up to 96 GbE Copper / Fiber portsSupport IPMI card with VGA (Optional)
Offering
Desktop Intel® Celereon®, Pentium®, and Atom® Network SystemSix Copper GbEeMMCmSATA and SATAmini-PCIeGen3 Bypass
Offering
BIS-5221 is a 2U/12 bays Hybrid Storage System with dual 3rd Gen Intel® Xeon® Scalable Processor (Ice Lake / Whitley platform). Refreshed CPU microarchitecture provides Higher performance & IPC, and 8-memory channels (16 RDIMMs per CPU) support high memory bandwidth & capacity. Also, with total 64 lanes PCIe 4.0 (16GT/s) per CPU, BIS-5221 provides flexible and scalable I/O scalability, supporting up to 2x OCP 3.0 network cards and multiple standard PCIe slots. From the system view, BIS-5221 features tool-less HDD/SDD tray and PCIe slots, which could support up to 2 GPU, and edge-cutting thermal airduct design solution. All above provides customer the most reliable system for application of AI computing/cloud computing/security solution. Last but not the least, BIS-5221 also features flexible customization for data center/ISV/CSP on hardware/firmware/BIOS/software.
Offering
Intel® (formerly Coffee Lake) S series platform 8th Gen Intel® Core™ i7/i5/i3 and Intel® Xeon® E processors
Offering
1U Rack-mount Intel® Celereon®, Pentium®, and Atom® Network System, Six Copper GbE, eMMC, mSATA, SATA, PCIe, Gen3 Bypass
Offering
1U Rack-Mount, Intel® Coffee Lake-S Xeon® Processor E Family / 8th CoreTM i7/i5/i3 processor with C246 PCH Network system, support DDR4 up to 64GB, 4 PCIe x8 slot for expansion NIC module, Console, 2 USB 2.0, 2 GbE, 2.5” or 3.5” SATA HDD/SSD, CF, m-SATA
Offering
The SCB-1932 is a 2U Rack-Mount hardware networking system. Supporting Intel® with efficient performance processor Intel® Xeon® scalable series and Intel® C621A/C627A PCH. The new generation platform provides highly performance, CPU cores up to 38 cores, 3 Ultra Path Interconnect (UPI) links up to 11.2 GT/s. The SCB-1932 supports 8x channels DDR4 register ECC RDIMM (up to 3200 MHz) and maximum memory capacity is up to 1TB with 64 PCI Express lanes per CPU, the SCB-1932 can support up to 8xNetwork Expansion Modules, support multiple different ethernet modules for flexible port configuration, such as 1/10/40/100 Gigabit fiber, Gigabit Copper/Fiber with or without BYPASS function. The maximum ethernet bandwidth capacity is up to 1,000GbE. The strong IO elements of SCB-1932 include two management port (one for management, another for option IPMI function), a console port, USB ports, LEDs for power/ HDD/ 2x GPIO. In addition, the SCB-1932 also supports two front hot-swappable 2.5” SATA HDDs/SSDs and onboard CompactFlashTM/m-SATA/miniPCI-E, M.2 slot fornetwork storage application.
Offering
The SCB-1931 is a 1U Rack-Mount hardware networking system. Supporting Intel® with efficient performance processor Intel® Xeon® scalable series and Intel® C621A PCH. The new generation platform provides highly performance, CPU cores up to 40 cores, 3 Ultra Path Interconnect (UPI) links up to 11.2 GT/s. The SCB-1931 supports 8x channels DDR4 register ECC RDIMM (up to 3200 MHz) and maximum memory capacity is up to 1TB with 64 PCI Express lanes per CPU, the SCB-1931 can support up to 4x Network Expansion Modules, support multiple different ethernet modules for flexible port configuration, such as 1/10/40/100 Gigabit fiber, Gigabit Copper/Fiber with or without BYPASS function.
Offering
The SCB-1826 is a 1U Rack-Mount high-performance networking system, that supports a single 10th Generation Intel® Core™ / Xeon® W processor for IoT applications. It is based on the new 14nm Intel® architecture to deliver breakthrough computing performance. CPU up to 10 cores / 20 Threads, 20MB cache, and maximum turbo frequency of 4.8GHz. Platform is powered by the W480E chipset.
Offering
The SCB-1836 is a 1 U Rack-Mount high-performance networking system, supporting 12th Gen core processors (Alder Lake-S) with increased CPU cores and threads (up to 16 cores/24 threads) for outstanding performance. Also, it is with increased L2 & L3 cache with up to 30MB Intel® Smart cache which is 50% growth compared to Comet Lake one.SCB-1836 supports total four DDR5 DIMM (two channels and 2 DIMM per channel), up to 4800MHz and 128GB to enable faster computing. As for the expansion slots, it supports the latest PCIe Gen 5 for superior performance. Combining with PCIe Gen 4 slots to have total 4x expansion slots (2x PCIe Gen 5 & 2x PCIe Gen 4 lots), the system can build the exact configurations required per cases effortlessly as it is also compatible with AEWIN various NIC cards for 1/10/25/40/100 Gigabit fiber or copper with optional Bypass function. In addition to the great capability and function mentioned, SCB-1836 supports DPDK to accelerate packet processing to benefit the system with higher efficiency. Furthermore, it is featured with IPMI for monitoring and better managing the system intelligently. To ensure the networking security, the system is with TPM to protect its start-up process. With all the features mentioned, SCB-1836 is no doubt perfect as a performant network appliance for diverse applications.
Offering
The IS-B135 based on Intel® Ice Lake D 2775TE is a 200mm x 300mm motherboard designed for network service applications. With the feature of the wide operating temperature of Ice Lake D, AEWIN designs the motherboard to endure wide operating temperature of -20 to 75 degree C which make it suitable to operate under rugged environment with high reliability. IS-B135 supports up to six DDR4 2666 (2DPC)/2933 (1DPC) MHz UDIMM sockets with max capacity up to 192 GB. For the storage, it not only provides M.2 2280 for fast speed module, but also has additional eMMC and SATA pin header for the flexible configurations. Regarding the ethernet port, it supports 3x 10GbE SFP+, 10GbE Copper, and 1GbE Copper for IPMI. Furthermore, it has PCIe x8 connector for riser board to support the expansion module for additional function required.IS-B135 is also with TPM 2.0 to protect the system start-up without compromise the computing performance. In addition to the rich I/O and function mentioned, it supports DPDK for fast packet processing to accelerate the overall speed of the information forwarding for better efficiency.
