Offerings
Offering
The COMeT6-1100 is a rugged industrial COM Express® Type 6 Compact module with an Intel® 11th Gen Intel Core™ i3/i5/i7 Processor. This industrial module is designed and manufactured in the USA. The small form factor module is designed as a processor mezzanine that can be plugged onto a carrier board that contains user-specific I/O requirements.
Offering
WinSystems’ PX1-C441 single board computer (SBC) is a PC/104 form factor SBC with PCIe/104™ OneBank™ expansion featuring the latest generation Intel® SOC processor. Its small size, rugged design, and extended operational temperature make it a great fit for industrial IoT applications and embedded systems in the industrial control, transportation, Mil/COTS, and energy markets. The WinSystems PX1-C441 single board computer features the Intel Atom® Dual core or Quad core System on Chip (SOC) for processing and graphics. It includes up to 8 GB of soldered down LPDDR4 system memory and a non-removable eMMC device for solid state storage of an operating system (OS) and applications. In addition, the board supports M.2 and SATA devices. This full-featured SBC has onboard I/O and supports simultaneous DisplayPort and LVDS video. It provides dual Gigabit Ethernet interfaces, eight USB 2.0 channels, one SuperSpeed USB 3.2 Gen 1 channel, four serial ports, one serial console port, 24 general purpose I/O (GPIO) lines, one I2C bus, stereo audio, and a watchdog timer. Additionally, the board has an M.2 socket and a PCIe/104 OneBank connector that provides four PCIe and two USB 2.0 I/O expansion channels. The PX1-C441 supports Linux, Windows® 10 desktop, Windows® 10 IoT, and other x86-compatible real-time operating systems. Drivers are available from the WinSytems website.
Offering
The COMeT10-3900 is an industrial-grade COM Express® Type 10 Mini module with an Intel Atom® E3900 processor, LPDDR4 RAM, and TPM 2.0 onboard hardware security. This low-power module is designed and manufactured in the USA. The small form factor module is designed as a processor mezzanine that can be plugged onto a carrier board that contains user-specific I/O requirements. Users have the option to choose the default BIOS settings and layout or request a custom branded configurable BIOS to support specific project requirements. The COMeT10-3900 supports Linux, Windows® 10, and other x86-compatible real-time operating systems. Drivers are available from the WINSYSTEMS website.
Offering
WINSYSTEMS’ SBC35-427 is a small form factor single board computer (SBC) featuring the Intel® SOC processor. Its small size, low power, rugged design, and extended operational temperature make it a great fit for rugged embedded systems in the industrial control, transportation, energy, and industrial IoT markets. This full-featured SBC supports three independent video displays (two DisplayPort and LVDS video), dual Ethernet, two USB 3.1 Gen 1 ports, four USB 2.0 ports, eight general-purpose I/O (GPIO) lines, two channels Analog-to-Digital Converter (ADC), stereo audio, and a watchdog timer. The WINSYSTEMS SBC35-427 single board computer features a Dual or Quad-Core processor and up to 8GB of socketed SODIMM DDR3L ECC SDRAM. The SBC includes an mSATA socket and optional soldered down eMMC device for solid-state storage of operating systems (OS) and applications. Additionally, the board supports an external SATA device. The board has expansion capabilities via an M.2 connector E-Key 2230, and Mini-PCIe socket (with mSATA support). The SBC35-427 supports Linux, Windows® 10, and other x86-compatible real-time operating systems. Drivers are available from the WINSYSTEMS website.
Offering
WINSYSTEMS’ EPX-C414 is an EPIC form factor single board computer (SBC) with PC/104-Plus expansion featuring the Intel Atom® E3800 SOC processor. Its small size, rugged design, and extended operational temperature make it a great fit for industrial IoT applications and embedded systems in the industrial control, transportation, Mil/COTS, and energy markets. The EPX-C414 single board computer features the industrial Intel Atom® E3800 Series SOC (formerly known as Bay Trail-I). Quad-core (E3845) and dual-core (E3825) solutions are available from inventory, while single-core (E3815) and custom variants require a minimum order quantity. The EPX-C414 includes a SODIMM socket that supports up to 8 GB DDR3-LV system memory and a non-removable 1MB SRAM for battery-backed data. An mSATA socket, CFast socket, and SATA interface are included for solid state storage of an operating system (OS) and applications. This full-featured SBC has onboard I/O and supports two simultaneous displays from the DisplayPort, LVDS, and VGA video interfaces. It provides dual Gigabit Ethernet interfaces, eight USB 2.0 channels, four serial COM channels, 48 general purpose I/O (GPIO) lines, HD audio, a bi-directional LPT port, and a watchdog timer. The board also has dual MiniCard sockets and PC/104-Plus expansion connectors to utilize the ecosystem of legacy modules. The EPX-C414 supports Linux, Windows® 10 desktop, Windows® 10 IoT, and other x86-compatible real-time operating systems.
Offering
The SBC35-CC405 is a high-performance, industrial, small form factor (SFF) computer capable of operating at extended temperatures without requiring a fan or heat-pipe. The Intel Atom® E3800 series processors are integrated into the solution using a Type 6 COM Express module. A low-profile thermal solution creates a rugged platform base that protects the PCB assembly and provides convenient four-point mounting.
Offering
The SYS-405Q is a rugged, industrial system capable of operating at extended temperatures without requiring a fan or heat-pipe. The SYS-405Q is based on the Intel Atom® E3800 processor and protected by a rugged enclosure. Benefiting from Intel® Silvermont microarchitecture, the Intel Atom® E3800 provides up to twice the performance of previous Intel Atom® processors while drawing less power. The SYS-405Q features a wealth of I/O and expansion options including USB3, USB2, dual Gigabit Ethernet, MiniPCIe, two RS-232/422/485 serial ports, I2 C and SPI bus. It is a great fit for Industrial IoT solutions requiring longevity and high reliability such as Energy, Transportation, SCADA, and Factory Automation.
Offering
WINSYSTEMS’ EBC-C413 is an EBX-compatible Single Board Computer (SBC) with PC104-Plus expansion featuring the Intel Atom® (formerly Bay Trail) SOC (System on a Chip) processor. Its rugged design and extended operational temperature make it a great fit for industrial IoT applications and embedded systems in the industrial control, transportation, Mil/COTS, and energy markets. This SBC is a full-featured unit with onboard I/O that supports CRT/DisplayPort/LVDS video simultaneously, dual Gigabit Ethernet ports, eight USB 2.0 ports, four serial RS-232/422/485 UARTs, 48 digital I/O lines, HD audio, watchdog timer, PS/2 keyboard and mouse controllers, and LPT. It also has two MiniPCIe sockets, PC/104 and PC/104-Plus connectors for additional I/O expansion. Additional expansion is available through MiniPCIe, mSATA, and PC/104-Plus interfaces. The EBC-C413 supports Linux, Windows® 10 desktop, Windows 10 IoT, and other x86-compatible real-time operating systems. The EBC-C413 is designed for long-term availability.
Offering
WINSYSTEMS’ PPM-C407 is a low power PC104 Single Board Computer (SBC) with long term availability. It utilizes the E3800 family of Atom® processors from Intel®, which allows you to choose between low power single-core and higher performance dual or quad-core solutions in the versatile PC104-Plus form factor. Designed for harsh environments and reliability, it includes soldered RAM for added shock and vibration resistance with an operating temperature range from -40oC up to +85oC.
Offering
WINSYSTEMS’ SBC35-427 is a small form factor single board computer (SBC) featuring the latest generation Intel® (formerly - Apollo Lake) - I SOC processor. Its small size, low power, rugged design, and extended operational temperature make it a great fit for rugged embedded systems in the industrial control, transportation, energy, and industrial IoT markets. This full-featured SBC supports three independent video displays (two DisplayPort and LVDS video), dual Ethernet, two USB 3.1 Gen 1 ports, four USB 2.0 ports, eight general purpose I/O (GPIO) lines, two channels Analog-to-Digital Converter (ADC), stereo audio, and a watchdog timer. The WINSYSTEMS SBC35-427 single board computer features a Dual or Quad-Core processor and up to 8GB of socketed SODIMM DDR3L ECC SDRAM. The SBC includes an mSATA socket and optional soldered down eMMC device for solid state storage of operating systems (OS) and applications. Additionally, the board supports an external SATA device. The board has expansion capabilities via an M.2 connector E-Key 2230, Mini-PCIe socket (with mSATA support) and WINSYSTEMS’ Modular IO80 interface. The SBC35-427 supports Linux, Windows® 10, DOS, and other x86-compatible real-time operating systems.
Offering
WINSYSTEMS’ PPC12-427 is a fanless, 12.1-inch panel PC featuring the latest generation Intel® (formerly - Apollo Lake) - I SOC processor. Its small size, low power, extended operational temperature, and IP65 rating make it a great fit for harsh environments in the industrial control, transportation, energy, and industrial IoT markets.
Offering
WINSYSTEMS’ SYS-427 is a rugged, embedded computer featuring the latest generation Intel® (formerly - Apollo Lake) - I SOC processor. Its small size, low power, and extended operational temperature make it a great fit for rugged embedded systems in the industrial control, transportation, energy, and industrial IoT markets.
