Extreme Engineering Solutions, Inc. (X-ES)
Titanium Partner | Extreme Engineering Solutions, Inc. (X-ES)'s Website
Offerings
Offering
The XPedite7750 is an enhanced, Type 7 COM Express® module based on the Intel® Xeon® D-1700 series of processors. COM Express® provides a standards-based form factor to bring PC processing to a wide range of applications. The XPedite7750 is ideal for the high-bandwidth and processing-intensive requirements of today’s commercial, industrial, and military applications. The small footprint and standards-based form factor make the XPedite7750 perfect for portable and rugged environments, while providing an upgrade path for the future. The XPedite7750 accommodates 32 GB of DDR4 ECC SDRAM in two channels to support memory-intensive applications. The XPedite7750 also hosts numerous I/O ports and interfaces, including 10 Gigabit Ethernet, Gigabit Ethernet, PCI Express, USB 3.0, and LVTTL serial. Wind River VxWorks and X-ES Enterprise Linux Support Packages (XEL) are available.
Offering
The XCalibur4840 is a secure, high-performance, 6U VPX-REDI, single board computer based on the Intel® Xeon® D-2700 series of processors. The XCalibur4840 is an optimal choice for computationally heavy applications requiring maximum data protection. The XCalibur4840 integrates SecureCOTS™ technology with an FPGA for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required. The XCalibur4840 provides incredible speed with two 40GBASE-KR4, two 1000BASE-X, and two 10/100/1000BASE-T Ethernet ports. It accommodates up to 64 GB of DDR4 ECC SDRAM in four channels and up to 32 GB of onboard SLC NAND flash in addition to numerous I/O ports, including USB 2.0, PCIe, and RS-232/422/485 serial through the backplane connectors. The XCalibur4840 provides additional expansion capabilities by including two integrated XMC/PMC sites. These sites each include a x8 PCIe connection to the Intel® Xeon® D processor and X12d+X8d I/O mapped directly to the VPX backplane connectors. Additionally, each mezzanine site offers a single PMC connector, which provides a build option for P64s or X38s to the VPX backplane connectors. Wind River VxWorks and X-ES Enterprise Linux (XEL) Board Support Packages (BSPs) are available.
Offering
The XCalibur4740 is a secure, high-performance, 6U VPX-REDI, single board computer based on the Intel® Xeon® D-1700 series of processors. The XCalibur4740 is an optimal choice for computationally heavy applications requiring maximum data protection. The XCalibur4740 integrates SecureCOTS™ technology with an FPGA for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required. The XCalibur4740 provides incredible speed with two 40GBASE-KR4, two 1000BASE-X, and two 10/100/1000BASE-T Ethernet ports. It accommodates up to 48 GB of DDR4 ECC SDRAM in three channels and up to 32 GB of onboard SLC NAND flash in addition to numerous I/O ports, including USB 2.0, PCIe, and RS-232/422/485 serial through the backplane connectors. The XCalibur4740 provides additional expansion capabilities by including two integrated XMC/PMC sites. These sites each include a x8 PCIe connection to the Intel® Xeon® D processor and X12d+X8d I/O mapped directly to the VPX backplane connectors. Additionally, each mezzanine site offers a single PMC connector, which provides a build option for P64s or X38s to the VPX backplane connectors. Wind River VxWorks and X-ES Enterprise Linux (XEL) Board Support Packages (BSPs) are available.
Offering
The XPedite7650 is an enhanced, Type 7 COM Express® module based on the Intel® Xeon® D-1500 family processors (formerly Broadwell-DE). COM Express® provides a standards-based form factor to bring PC processing to a wide range of applications. The XPedite7650 is ideal for the high-bandwidth and processing-intensive requirements of today’s commercial, industrial, and military applications. The small footprint and standards-based form factor make the XPedite7650 perfect for portable and rugged environments, while providing an upgrade path for the future. The XPedite7650 accommodates up to 32 GB of DDR4-2133 ECC SDRAM in two channels to support memory-intensive applications. The XPedite7650 also hosts numerous I/O ports and interfaces, including 10 Gigabit Ethernet, Gigabit Ethernet, PCI Express, SATA, USB 3.0, LPC, SMB, I²C, and LVTTL serial. Wind River VxWorks and X-ES Enterprise Linux Support Packages (XEL) are available. The XPedite7670 uses coreboot, powered by Intel®’s Firmware Support Package (FSP), to provide fast boot times and significantly simplify code traceability over legacy BIOS implementations.
Offering
The XCalibur4640 is a high-performance, 6U OpenVPX™, multiprocessing, single board computer that is ideal for ruggedized systems requiring high-bandwidth processing and low power consumption. Featuring Intel® Xeon® D-1500 family processors, four 10 Gigabit Ethernet ports on the data plane, two 10 Gigabit Ethernet ports on the control plane, and a configurable x16 PCI Express Gen3-capable expansion plane interface, the XCalibur4640 delivers enhanced performance and efficiency for today’s embedded computing applications. The XCalibur4640 provides up to 32 GB of DDR4 ECC SDRAM in two channels, two XMC/PrPMC slots, and up to 64 GB of SATA NAND flash. The XCalibur4640 also supports up to three Gigabit Ethernet ports, four SATA ports, one USB 2.0 port, up to two USB 3.0 ports, and up to five serial ports out the front panel and/or backplane. The XCalibur4640 is a powerful, feature-rich solution for the next generation of compute-intensive embedded applications. Wind River VxWorks and X-ES Enterprise Linux Support Packages (XEL) are available.
Offering
The XPedite8171 is an Intel® Atom® E3800-based 3U VPX-REDI single board computer available in conduction- and air-cooled configurations. The Intel® Atom® E3800 processors provide excellent computational performance and I/O functionality for their power profile and size. They are low-power system-on-chip (SoC) processors with integrated graphics and support for up to four cores operating at up to 1.91 GHz. Along with best-in-class performance-per-watt, the E3800 family supports extremely low operating temperatures, and its power-efficient 22 nm technology enables operation in the most demanding high-temperature environments. The XPedite8171 provides superior growth and expansion capabilities by including an XMC or PMC site with full 10 mm I/O envelope support, while maintaining a 0.8 in. VPX slot pitch and providing the system integrator with a plethora of COTS options for additional I/O, storage, or processing, all while minimizing total system SWaP-C. In addition, the XPedite8171 has been designed to support the XPedite5205 Embedded Services Router (ESR) utilizing Cisco IOS®. It also includes up to 8 GB of DDR3-1333 ECC SDRAM and up to 64 GB of SLC NAND flash in two devices, as well as two HDMI/DVI-D or Dual-Mode DisplayPort video interfaces and up to two Gigabit Ethernet ports. The XPedite8171 supports the E3845 processor in standard configurations and can be built to support the E3827, E3826, E3825, E3815, and E3805. The E3800 series is the 4th generation Atom® processor from Intel® and was formerly known as the Bay Trail-I platform and Valleyview processor. Wind River VxWorks and Linux Board Support Packages, as well as Microsoft Windows drivers, are available for the XPedite8171. It also supports the open source coreboot bootloader, powered by Intel®’s Firmware Support Package (FSP), to enable ultra-fast boot times and drastically simplify system security.
Offering
The XAct1012 provides an industry-leading combination of security, performance, and flexibility for a server motherboard. It features dual Intel® Xeon® E5-2600 family v4 (formerly Broadwell-EP) processors with a tightly coupled Xilinx Kintex® UltraScale™ security FPGA, two 40 Gigabit Ethernet ports, and six PCI Express expansion sites. The XAct1012 is designed and manufactured in the USA, using COTS components from trusted domestic supply chains. Supporting a standard Extended ATX (E-ATX) form factor with six standard PCI Express expansion slots, it is a true Open Systems Architecture (OSA) design that can be installed within COTS 1U/2U/3U rackmount or E-ATX tower chassis. The XAct1012 also integrates ruggedization features that enable it to perform in environmentally challenging applications without modifications or enhancements. X-ES Enterprise Linux (XEL) BSP is standard, please contact the factory for additional OS support options.
Offering
The XCalibur1412 with SecureCOTS™ technology provides an industry-leading combination of security and performance for an AdvancedTCA (ATCA) processing blade. It features dual Intel® Xeon® E5-2600 v4 family processors (formerly Broadwell-EP) with a tightly coupled Xilinx Kintex® UltraScale™ security FPGA and two up to 56 Gb/s InfiniBand or 40/56 Gigabit Ethernet ports.T he XCalibur1412 is designed and manufactured in the USA, using COTS components from trusted domestic supply chains. With full support for the PICMG 3.0 AdvancedTCA (ATCA) standard, it is a true Open Systems Architecture (OSA) design that can be installed within COTS ATCA chassis. The XCalibur1412 also integrates ruggedization features that enable it to perform in environmentally challenging applications without modifications or enhancements. An X-ES Enterprise Linux (XEL) Board Support Package (BSP) is available for the XCalibur1412.
Offering
The XPedite7674 is a high-performance, 3U VPX-REDI, multiprocessing, single board computer that is ideal for ruggedized systems requiring high-bandwidth processing and low power consumption. Featuring Intel® Xeon® D-1500 family processors coupled with the Xilinx Kintex® UltraScale™ FPGA, the XPedite7674 delivers enhanced performance and efficiency for today’s embedded computing applications. The XPedite7674 integrates SecureCOTS™ technology with the Xilinx Kintex® UltraScale™ FPGA for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required. The XPedite7674 provides secure network interfaces by providing one 1000BASE-X Gigabit Ethernet interface from the FPGA and passing two CPU 10 Gigabit 10GBASE-KR Ethernet interfaces through the FPGA.It accommodates up to 16 GB of DDR4-2133 ECC SDRAM in two channels and up to 32 GB of onboard SATA NAND flash in addition to numerous I/O ports, including USB, SATA, and RS-232/422/485 serial through the backplane connectors. The XPedite7674 provides additional expansion capabilities by including an XMC site. This XMC site includes a x8 PCIe connection to the Intel® Xeon® D processor and X12d I/O mapped directly to the VPX backplane connectors. Wind River VxWorks, X-ES Enterprise Linux (XEL), and LynxSecure Safety Bundle (LSB) are available for board support. The XPedite7674 uses coreboot, powered by Intel®’s Firmware Support Package (FSP), to provide fast boot times and significantly simplify code traceability over legacy BIOS implementations.
Offering
The XPedite7677 is a high-performance, 3U VPX-REDI, multiprocessing, single board computer that is ideal for ruggedized systems requiring high-bandwidth processing and low power consumption. Featuring Intel® Xeon® D-1500 family processors coupled with the Xilinx Kintex® UltraScale™ FPGA, the XPedite7677 delivers enhanced performance and efficiency for today’s embedded computing applications. The XPedite7677 integrates SecureCOTS™ technology with the Xilinx Kintex® UltraScale™ FPGA for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required. The Xilinx Kintex® UltraScale™ FPGA can control, intercept, and monitor the Xeon® D subsystem, implement penalties, and interface to the system through single-ended and differential I/O directly connected to the VPX backplane. Circuit board enhancements and optimized Two-Level Maintenance (2LM) metalwork provide additional protection to the physical hardware. The XPedite7677 maximizes network performance with two 10 Gigabit 10GBASE-KR interfaces, two 10/100/1000BASE-T ports, and two 1000BASE-KX ports. It accommodates up to 16 GB of DDR4-2133 ECC SDRAM in two channels and up to 32 GB of onboard SATA NAND flash in addition to numerous I/O ports, including USB, SATA, and RS-232/422/485 serial through the backplane connectors. The XPedite7677 provides additional expansion capabilities by including an XMC site. This XMC site includes a x8 PCIe connection to the Intel® Xeon® D processor and X12d I/O mapped directly to the VPX backplane connectors. Wind River VxWorks and X-ES Enterprise Linux (XEL) Board Support Packages (BSP) are available. The XPedite7677 uses coreboot, powered by Intel®’s Firmware Support Package (FSP), to provide fast boot times and significantly simplify code traceability over legacy BIOS implementations.
Offering
The XPedite7670 is a high-performance, 3U VPX-REDI, single board computer based on the Intel® Xeon® D-1500 family processors (formerly Broadwell-DE). The Intel® Xeon® D processor can provide up to 16 Xeon®-class cores in a single, power-efficient System-on-Chip (SoC) package. The XPedite7670 maximizes network performance with two 10 Gigabit Ethernet ports configured as 10GBASE-KR and two Gigabit Ethernet ports which are configured as 10/100/1000BASE-T.Up to eight lanes of PCI Express Gen3 are routed to the backplane P1 connector, supporting a single x8 PCIe interface or two x4 PCIe interfaces. This interface also supports Non-Transparent Bridging, enabling direct communication with other Intel® processors, and there is no need for a separate switch module in the system, further reducing SWaP-C for the system integrator. The XPedite7670 provides superior growth and expansion capabilities by including an XMC site with full 10 mm I/O envelope support, while maintaining a 0.8 in. VPX slot pitch (12 core processor configurations require 1.0 in. pitch). This gives system integrators a plethora of COTS options for additional I/O, storage, or processing. The XPedite7670 accommodates up to 16 GB of DDR4-2133 ECC SDRAM in two channels to support memory-intensive applications. The XPedite7670 also hosts numerous I/O ports, including USB, SATA, and RS-232/422/485 serial through the backplane connectors. Wind River VxWorks and X-ES Enterprise Linux Support Packages (XEL) are available. The XPedite7670 uses coreboot, powered by Intel®’s Firmware Support Package (FSP), to provide fast boot times and significantly simplify code traceability over legacy BIOS implementations.
Offering
The XCalibur4643 is a high-performance, 6U OpenVPX™, multiprocessing, single board computer that is ideal for ruggedized systems requiring high-bandwidth processing and low power consumption. Featuring Intel® Xeon® D-1500 family processors, a Xilinx Kintex® UltraScale™ FPGA, two 10 Gigabit Ethernet ports on the dataplane, and three x4 PCI Express Gen3-capable interfaces on the expansion plane, the XCalibur4643 delivers enhanced performance and efficiency for today’s embedded computing applications. The integrated SecureCOTS™ technology can protect critical data from being modified or observed and provides an ideal solution where stringent security capabilities are required. The XCalibur4643 provides up to 32 GB of DDR4-2133 ECC SDRAM in two channels, two XMC/PrPMC slots, and up to 64 GB of SATA NAND flash. The XCalibur4643 also supports up to four Gigabit Ethernet ports, four SATA ports, two USB ports, and up to five RS-232/422/485 serial ports out the back panel connectors. It supports one Gigabit Ethernet port, one USB 3.0 port, and one RS-232 serial port out the front panel connectors. The XCalibur4643 is a powerful, feature-rich solution for the next generation of compute-intensive embedded applications. Wind River VxWorks, X-ES Enterprise Linux (XEL), and Microsoft Windows 7 BSPs are available.
Offering
The XPedite7672 is a secure, high-performance, 3U VPX-REDI, single board computer based on the Intel® Xeon® D-1500 family processors. The Intel® Xeon® D processor can provide up to 16 Xeon®-class cores in a single, power-efficient System-on-Chip (SoC) package. The XPedite7672 is an optimal choice for computationally heavy applications requiring maximum data and information protection. The XPedite7672 integrates SecureCOTS™ technology with a SmartFusion 2 security SoC for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required. The SmartFusion 2 can control, intercept, and monitor the Xeon® D subsystem, implement penalties, and interface to the system through single-ended and differential I/O directly connected to the VPX backplane. Circuit board enhancements and optimized Two-Level Maintenance (2LM) metalwork provide additional protection to the physical hardware. The XPedite7672 maximizes network performance with two 10 Gigabit 10GBASE-KR Ethernet interfaces and two 10/100/1000BASE-T Gigabit Ethernet interfaces. It accommodates up to 16 GB of DDR4-2133 ECC SDRAM in two channels and up to 32 GB of onboard SATA NAND flash in addition to numerous I/O ports, including USB, SATA, and RS-232/422/485 through the backplane connectors. The XPedite7672 provides additional expansion capabilities by including an integrated XMC. This XMC site includes a x8 PCIe connection to the Intel® Xeon® D processor and X12d I/O mapped directly to the VPX backplane connectors. Wind River VxWorks and X-ES Enterprise Linux Support Packages (XEL) are available. The XPedite7672 uses coreboot, powered by Intel®’s Firmware Support Package (FSP), to provide fast boot times and significantly simplify code traceability over legacy BIOS implementations.
Offering
The XCalibur4646 is a secure, high-performance, 6U OpenVPX, single board computer based on the Intel® Xeon® D-1500 family processors. The Intel® Xeon® D processor can provide up to 16 Xeon®-class cores for high-bandwidth processing and I/O applications. The integrated SecureCOTS technology can protect critical data from being modified or observed and provides an ideal solution where stringent security capabilities are required. The XCalibur4646 includes a customizable Microsemi SmartFusion 2 security SoC with 1 GB of ECC DDR3 to implement the SecureCOTS features. It can host many types of custom functions, such as data encryption, and additionally supports the ability to control, intercept, and monitor the Xeon® D subsystem, implement penalties, and interface to the system through I/O directly connected to the VPX backplane. Circuit board enhancements and optional, optimized Two-Level Maintenance (2LM) metalwork provides added protection to the physical hardware. The XCalibur4646 optimizes network performance and power efficiency with two 10GBASE-KR Ethernet interfaces direct from the CPU and two 1000BASE-T Ethernet interfaces to the VPX backplane. It accommodates up to 32 GB of DDR4-2133 ECC SDRAM in two channels and up to 64 GB of SLC SATA NAND flash in addition to other I/O ports, including USB, SATA, and four configurable RS-232/422/485 serial ports through the backplane connectors. The XCalibur4646 supports additional expansion from two XMC sites, each of which includes a x8 PCIe connection to the Intel® Xeon® D processor and mezzanine I/O mapped directly to the VPX backplane. The XCalibur4646 is a powerful, feature-rich solution for the next generation of compute-intensive embedded applications. Wind River VxWorks and X-ES Enterprise Linux (XEL) BSPs are available. The XCalibur4646 uses coreboot, to provide fast boot times and significantly simplify code traceability over legacy BIOS implementations.
Offering
The XPedite7683 is a secure, high-performance, 3U OpenVPX™, single board computer based on the Intel® Xeon® D-1500 family of processors. Providing up to 16 Xeon®-class cores, up to 32 GB of DDR4-2133 ECC SDRAM, and XMC support, the XPedite7683 is an optimal choice for computationally heavy applications requiring maximum data and information protection. The XPedite7683 integrates SecureCOTS™ technology with a Microsemi SmartFusion®2 security SoC for hosting custom functions to protect data from being modified or observed, and provides an ideal solution when stringent security capabilities are required. The Microsemi SmartFusion®2 can control, intercept, and monitor the Xeon® D subsystem, implement penalties, and interface to the system through GPIO directly connected to the VPX backplane. Circuit board enhancements and optimized Two-Level Maintenance (2LM) metalwork provide additional protection to the physical hardware. The XPedite7683 maximizes network performance with two 10 Gigabit Ethernet interfaces and two Gigabit Ethernet interfaces. It accommodates up to 32 GB of DDR4-2133 ECC SDRAM in two channels and up to 256 GB of onboard SATA NAND flash in addition to numerous I/O ports, including USB, SATA, and RS-232/422/485 through the backplane connectors. The XPedite7683 provides additional expansion capabilities with an integrated XMC site, which includes a x8 PCIe connection to the Intel® Xeon® D processor and X12d I/O mapped directly to the VPX backplane connectors. Wind River VxWorks and X-ES Enterprise Linux Support Packages (XEL) are available. The XPedite7683 uses coreboot, powered by the Intel® Firmware Support Package (FSP), to provide fast boot times and significantly simplify code traceability over legacy BIOS implementations.
Offering
The XPedite8103 is an Intel Atom® E3800-based XMC available in conduction- and air-cooled configurations. The Atom™ E3800 processors provide excellent computational performance and I/O functionality for their power profile and size. They are low-power system-on-chip (SoC) processors with integrated graphics and support for up to four cores operating at up to 1.91 GHz. Along with best-in-class performance-per-watt, the E3800 family supports extremely low operating temperatures, and its power-efficient 22 nm technology enables operation in the most demanding high-temperature environments. The XPedite8103 supports up to 8 GB of DDR3 ECC SDRAM and up to 32 GB of SLC NAND flash. It supports up to four Gigabit Ethernet ports, two RS-232/422/485 serial ports, and one optional USB 2.0 port through the P14 connector. The XPedite8103 supports the E3845 processor in standard configurations and can be built to support the E3827, E3826, E3825, E3815, and E3805. The E3800 series is the 4th generation Atom™ processor from Intel® and was formerly known as the Bay Trail-I platform and Valleyview processor. Wind River VxWorks and Linux Board Support Packages are available for the XPedite8103. It also supports the open source coreboot bootloader, powered by Intel®’s Firmware Support Package (FSP), to enable ultra-fast boot times and drastically simplify system security.
Offering
The XPedite7680 is a high-performance, 3U VPX-REDI, single board computer based on the Intel® Xeon® D-1500 family processors (formerly Broadwell-DE). The Intel® Xeon® D processor can provide up to 16 Xeon®-class cores in a single, power-efficient System-on-Chip (SoC) package. The XPedite7680 maximizes network performance with two 10 Gigabit Ethernet ports configured as 10GBASE-KR and one Gigabit Ethernet port configured as 10/100/1000BASE-T. Up to eight lanes of PCI Express Gen3 are routed to the backplane P1 connector, supporting a single x8 PCIe interface or two x4 PCIe interfaces. This interface also supports Non-Transparent Bridging, enabling direct communication with other Intel® processors, and there is no need for a separate switch module in the system, further reducing SWaP-C for the system integrator. The XPedite7680 provides superior growth and expansion capabilities through an XMC site, while maintaining a 0.8 in. VPX slot pitch (12-core processor configurations require 1.0 in. pitch). This gives system integrators a plethora of COTS options for additional I/O, storage, or processing. The XPedite7680 accommodates up to 32 GB of DDR4 ECC SDRAM in two channels to support memory-intensive applications. The XPedite7680 also hosts numerous I/O ports, including USB, SATA, and RS-232/422/485 serial through the backplane connectors. Wind River VxWorks and X-ES Enterprise Linux Support Packages (XEL) are available.
Offering
The XCalibur4630 is a high-performance 6U VME single board computer that is ideal for ruggedized systems requiring high-bandwidth processing and low power consumption. With the Intel® Xeon® D-1500 family of processors, the XCalibur4630 delivers enhanced performance and efficiency for today’s network information processing and embedded computing applications. The XCalibur4630 provides up to 32 GB DDR4 ECC SDRAM in two separate channels, two XMC/PrPMC slots, and up to 64 GB of NAND flash. The XCalibur4630 also hosts numerous I/O ports, including Gigabit Ethernet, USB 2.0 and USB 3.0, SATA, mezzanine I/O, and RS-232/422/485 through the backplane connectors and Gigabit Ethernet and USB 2.0 or 3.0 to an optional front panel. The XCalibur4630 is a powerful, feature-rich solution for the next generation of compute-intensive embedded applications. Wind River VxWorks and X-ES Enterprise Linux Board Support Packages (BSPs) are available.
Offering
The XPedite8150 is a Rugged COM Express® module based on the Intel® Atom™ E3800 series of processors. It is compliant with the COM Express® Mini form factor (55 mm x 84 mm) and provides up to 4 GB of DDR3 ECC SDRAM. The XPedite8150 also supports an enhanced Type 10 pinout with one Dual-Mode DisplayPort, one Embedded DisplayPort, and two Gigabit Ethernet interfaces. With built-in test (BIT) support, true configuration and obsolescence management, Class III PCB fabrication and assembly, environmental qualification per MIL-STD-810, as well as many other features, the XPedite8150 is designed and tested for maximum reliability in the most demanding environments and applications that require long life cycles. Wind River VxWorks and Linux Board Support Packages (BSPs), as well as Microsoft Windows drivers, are available for the XPedite8150. It also supports the open source coreboot bootloader, powered by Intel®’s Firmware Support Package (FSP), to enable ultra-fast boot times and drastically simplify system security. The Intel® Atom™ E3800 series processors are low-power system-on-chip (SoC) processors with integrated graphics and support for up to four cores operating at up to 1.91 GHz. Along with best-in-class performance-per-watt, the E3800 family supports extremely low operating temperatures, and its power-efficient 22 nm technology enables operation in the most demanding high-temperature environments. The XPedite8150 supports the E3845 processor in standard configurations and can be built to support the E3827, E3826, E3825, E3815, and E3805. The E3800 series is the 4th generation Atom™ processor from Intel® and was formerly known as the Bay Trail-I platform and Valleyview processor.
Offering
The XPedite8101 is an Intel® Atom™ E3800-based XMC/PMC available in conduction- and air-cooled configurations. The Atom™ E3800 processors provide excellent computational performance and I/O functionality for their power profile and size. They are low-power system-on-chip (SoC) processors with integrated graphics and support for up to four cores operating at up to 1.91 GHz. Along with best-in-class performance-per-watt, the E3800 family supports extremely low operating temperatures, and its power-efficient 22 nm technology enables operation in the most demanding high-temperature environments. The XPedite8101 supports up to 8 GB of DDR3 ECC SDRAM and up to 32 GB of SLC NAND flash, as well as a Dual-Mode DisplayPort video interface and two Gigabit Ethernet ports. Four USB 2.0 ports, two RS-232/422/485 serial ports, and up to two SATA interfaces are also available through the P14 and P16 connectors. Wind River VxWorks and Linux Board Support Packages, as well as Microsoft Windows drivers, are available for the XPedite8101. It also supports the open source coreboot bootloader, powered by Intel®’s Firmware Support Package (FSP), to enable ultra-fast boot times and drastically simplify system security. The XPedite8101 supports the E3845 processor in standard configurations and can be built to support the E3827, E3826, E3825, E3815, and E3805. The E3800 series is the 4th generation Atom™ processor from Intel® and was formerly known as the Bay Trail-I platform and Valleyview processor.
Offering
The XPedite8152 is a Rugged COM Express® module based on the Intel® Atom™ E3800 series of processors. It is based on the COM Express® Mini form factor, but is extended to 55 mm x 109 mm to provide up to 32 GB of SLC NAND flash as well as 4 GB of DDR3 ECC SDRAM. The XPedite8152 also supports an enhanced Type 10 pinout with one Dual-Mode DisplayPort, one Embedded DisplayPort, two Gigabit Ethernet interfaces, and three SATA interfaces. With built-in test (BIT) support, true configuration and obsolescence management, Class III PCB fabrication and assembly, environmental qualification per MIL-STD-810, as well as many other features, the XPedite8152 is designed and tested for maximum reliability in the most demanding environments and applications that require long life cycles. Wind River VxWorks and Linux Board Support Packages, as well as Microsoft Windows drivers, are available for the XPedite8152. It also supports the open source coreboot bootloader, powered by Intel®’s Firmware Support Package (FSP), to enable ultra-fast boot times and drastically simplify system security. The Intel® Atom™ E3800 series processors are low-power system-on-chip (SoC) processors with integrated graphics and support for up to four cores operating at up to 1.91 GHz. Along with best-in-class performance-per-watt, the E3800 family supports extremely low operating temperatures, and its power-efficient 22 nm technology enables operation in the most demanding high-temperature environments. The XPedite8152 supports the E3825 processor in standard configurations and can be built to support the E3845, E3827, E3826, E3815, and E3805. The E3800 series is the 4th generation Atom™ processor from Intel® and was formerly known as the Bay Trail-I platform and Valleyview processor.
Offering
The XPand9011 provides an industry-leading combination of security, performance, and flexibility for a rackmount server. It features dual Intel® Xeon® E5-2600 family v4 processors with a tightly coupled security FPGA, two 40 Gigabit Ethernet ports, and six PCI Express Gen3-capable expansion sites. The XPand9011 is designed and manufactured in the USA, using COTS components from trusted domestic supply chains. Supporting a standard 2U rackmount form factor with six PCI Express expansion slots, it is a true Open Systems Architecture (OSA) design. The XPand9011 also integrates ruggedization features that enable it to perform in environmentally challenging applications without modifications or enhancements. X-ES Enterprise Linux (XEL) BSP is standard, please contact the factory for additional OS support options.
Offering
The XPedite7676 is a secure, high-performance, 3U VPX-REDI, single board computer based on the Intel® Xeon® D-1500 family processors. The Intel® Xeon® D processor can provide up to 16 Intel® Xeon®-class cores in a single, power-efficient System-on-Chip (SoC) package. The XPedite7676 is an optimal choice for computationally heavy applications requiring maximum data and information protection. The XPedite7676 integrates SecureCOTS™ technology with a SmartFusion®2 security SoC for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required. The SmartFusion®2 can control, intercept, and monitor the Intel® Xeon® D subsystem, implement penalties, and interface to the system through I/O directly connected to the VPX backplane. Circuit board enhancements and optimized Two-Level Maintenance (2LM) metalwork provide additional protection to the physical hardware. The XPedite7676 maximizes network performance with two 10 Gigabit 10GBASE-KR Ethernet interfaces and one 10/100/1000BASE-T Gigabit Ethernet interface. It accommodates up to 16 GB of DDR4-2133 ECC SDRAM in two channels and up to 32 GB of onboard SATA NAND flash in addition to numerous I/O ports, including USB, SATA, and RS-232/422/485 serial through the backplane connectors. The XPedite7676 provides additional expansion capabilities by integrating an XMC site with X24s+X8d+X12d I/O to the backplane. Wind River VxWorks and X-ES Enterprise Linux Support Packages (XEL) are available. The XPedite7676 uses coreboot, powered by Intel® Firmware Support Package (FSP), to provide fast boot times and significantly simplify code traceability over legacy BIOS implementations.
Offering
The XCalibur4702 is a high-performance 6U CompactPCI single board computer based on the Intel® Xeon® D-1700 series of processors. Ideal for ruggedized systems requiring high-bandwidth processing and low power consumption, the XCalibur4702 delivers superior performance and efficiency for today’s network information processing and high performance embedded computing applications. The XCalibur4702 integrates SecureCOTS™ technology with an FPGA for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required. The XCalibur4702 provides up to 48 GB of DDR4 ECC SDRAM in three separate channels, one XMC/PrPMC slot, and up to 32 GB of SLC NAND flash. The XCalibur4702 also hosts numerous I/O ports, including 10/100/1000BASE-T Ethernet, USB 2.0, and RS-232/422/485 serial ports through the backplane connectors. The XCalibur4702 does not support PCI connectivity or functionality. Wind River VxWorks and X-ES Enterprise Linux (XEL) Board Support Packages (BSPs) are available.
Offering
The XCalibur4730 is a secure, high-performance, 6U VME, single board computer based on the Intel® Xeon® D-1700 series (formerly Ice Lake-D) of processors. The XCalibur4730 is an optimal choice for computationally heavy applications requiring maximum data protection. The XCalibur4730 integrates SecureCOTS™ technology with a Microsemi® PolarFire™ FPGA for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required. In addition to providing three 10/100/1000BASE-T Ethernet ports, the XCalibur4730 accommodates up to 48 GB of DDR4 ECC SDRAM in three channels and up to 32 GB of onboard SLC NAND flash. The XCalibur4730 provides additional expansion capabilities by including two integrated XMC/PMC sites. These sites each include a x8 PCIe connection to the Intel® Xeon® D processor. Each mezzanine site offers a single PMC connector, providing an I/O connection to the VME backplane connectors in addition to the USB and RS-232/422/485 ports. Wind River VxWorks and X-ES Enterprise Linux (XEL) Board Support Packages (BSPs) are available.
Offering
The XPedite7770 is a secure, high-performance, 3U VPX-REDI, single board computer based on the Intel® Xeon® D-1700 series of processors. The XPedite7770 is an optimal choice for computationally heavy applications requiring maximum data and information protection. The XPedite7770 integrates SecureCOTS™ technology with an FPGA for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required. The XPedite7770 provides incredible speed with a 40GBASE-KR4, up to two 10GBASE-KR, and one 10/100/1000BASE-T Ethernet ports. It accommodates up to 48 GB of DDR4 ECC SDRAM in three channels and up to 32 GB of onboard SLC NAND flash in addition to numerous I/O ports, including USB 2.0, PCIe, and RS-232/422/485 serial through the backplane connectors. The XPedite7770 provides additional expansion capabilities by including an integrated XMC site. This XMC site includes a x8 PCIe connection to the Intel® Xeon® D processor and X12d I/O mapped directly to the VPX backplane connectors. Wind River VxWorks and X-ES Enterprise Linux (XEL) Board Support Packages (BSPs) are available.
Offering
The XPedite7870 is a secure, high-performance, 3U VPX-REDI, single board computer based on the Intel® Xeon® D-2700 series of processors. The XPedite7870 is an optimal choice for computationally heavy applications requiring maximum data and information protection. The XPedite7870 integrates SecureCOTS™ technology with an FPGA for hosting custom functions to protect data from being modified or observed and provides an ideal solution when stringent security capabilities are required. The XPedite7870 provides incredible speed with two 40GBASE-KR4 and one 10/100/1000BASE-T Ethernet ports. It accommodates up to 64 GB of DDR4 ECC SDRAM in four channels and up to 32 GB of onboard SLC NAND flash in addition to numerous I/O ports, including USB 2.0, PCIe, and RS-232/422/485 serial through the backplane connectors. Wind River VxWorks and X-ES Enterprise Linux (XEL) Board Support Packages (BSPs) are available.
