Offerings
Offering
The 6U OpenVPX CHAMP-XD2M rugged Intel® Xeon® D module is designed for use in high memory capacity, compute-intensive Industrial, Aerospace and Defense applications, enabling developers of High Performance Embedded Computing (HPEC) systems to take full advantage of the unmatched performance of today’s leading-edge Intel® Xeon® processor D architecture. The CHAMP-XD2M combines the high core count and floating-point performance of the Intel® Xeon® D processor with a massive 128 GB (maximum capacity supported by the Intel® Xeon® D) in addition to the substantial bandwidth and system-enabling features of the VITA 6U OpenVPX form factor. Providing a 16 core Intel® Xeon® D processor, the CHAMP-XD2M has a peak performance of 870 GFLOPS. This is coupled with 128 GB of high capacity DDR4-2133, with a bandwidth of >17 GBps per channel, two channels total of ECC memory. Key Features Intel® Xeon® D 16-core processor (870 GFLOPS @ 1.7 GHz)Alternative Intel® Xeon® D SKUs available128 GB DDR4 @ 2133 MT/s (34 GBps over 2 ECC channels)Four ports of 40G/10G Ethernet or DDR/QDR/FDR10 InfiniBand on Open VPX data plane Native dual KX 1 GigE or KR 10 GigE ports on OpenVPX control plane XMC PCIe up to Gen3, designed for up to 25W thermal dissipation Dual x16 PCIe Gen3 on OpenVPX expansion plane with switchPCH integrated in Intel® Xeon® D SoCCore Function FPGA and IPMIAir and conduction-cooledTrustedCOTS
Offering
The 3U OpenVPX™ CHAMP™-XD3 (VPX3-484) security-enhanced, cognitive, rugged digital signal processor (DSP) engine module is designed for use in very compute-intensive industrial, aerospace and defense applications, enabling developers of High-Performance Embedded Computing (HPEC) systems to take full advantage of the unmatched performance of today’s Intel® Xeon® D-1746 architecture. The CHAMP-XD3 combines the high core count and floating-point performance of the Intel® Xeon® D-1746 processors with the substantial bandwidth and system-enabling features of the VITA 3U OpenVPX form-factor. Providing an extended temperature Intel® Xeon® D-1746 LCC processor with 10 cores, the CHAMP-XD3 brings the new Intel® AVX512 floating-point capability to the rugged embedded marketplace. This is coupled with 48 GB of high capacity DDR4-2400 with a bandwidth of >19 GBps per channel with three channels per processor. The extra memory bank and speed provide over 50% more memory bandwidth than prior generation modules ensuring memory accesses are not a bottleneck.
Offering
The VPX3-1262 rugged, high performance 3U OpenVPX™ Processor Card was designed to meet the demanding performance needs of next-generation SOSA aligned processing systems by combining Intel® powerful 13th Gen hybrid processor with the power and flexibility of the VPX platform’s high speed fabric interconnects. The VPX3-1262 integrates the Intel® Core™ i7-13800HRE 14-core hybrid processor technology with Curtiss-Wright’s proven ruggedization technology to excel in harsh environments, making it ideal for architecting high performance computing and processing systems utilizing DSP, GPU and FPGA modules, and/or multiple SBC processors. This product is a member of Curtiss-Wright’s Fabric100 Ecosystem and offers end-to-end support for 100Gbps Ethernet fabrics, with proven performance for OpenVPX 25Gbaud signaling and enhanced interoperability for optimal configuration of the data fabric technology.
Offering
The CHAMP™-XD4 6U OpenVPX™ rugged processor card and cognitive DSP processor is designed for use in very compute-intensive industrial, and aerospace and defense applications, enabling developers of High-Performance Embedded Computing (HPEC) systems to take full advantage of the unmatched performance of today’s leading-edge Intel® Xeon® D-2700 architecture. The CHAMP-XD4 provides more than twice the processing capacity and bandwidth than prior generation products. Paired with our CHAMP-FX7 for front-end sensor ingest, the card-set enables a powerful back-end/front-end processing solution for the highest-performance radar and other sensor processing systems. The CHAMP-XD4 combines the high core count and floating-point performance of the Intel® Xeon® D-2700 processors with the substantial bandwidth and system-enabling features of Fabric100 100GbE connectivity of 25GBaud OpenVPX. Aligned with the SOSA Technical Standard, the CHAMP-XD4 supports a 100GbE Data Plane, dual 10 GbE control plane interfaces, and up to 32 lanes of Gen4 PCI Express® (PCIe) on the P2 and P5 expansion plane.
Offering
Bring the latest high-performance Intel® processing and trusted computing protections to your VME systems with the VME-1910 single board computer (SBC).Upgrade VME systems with cutting-edge processing technology, Protect critical data with enhanced security capabilities, Future-proof your investment, Featuring the latest 8th generation Intel® Xeon® E processor, the VME-1910 is a perfect replacement for legacy SBCs, bringing new life and increased performance into systems required to offer higher levels of functionality than previously deployed. Armed with modern Trusted Computing features and mechanisms, such as an Intel® TPM 2.0 hardware device for key management, Intel® Boot Guard for verified/trusted boot, UEFI secure boot, SSD encryption, and curtiss wright trusted COTS trusted boot protections, the VME-1910 provides enhanced protection against malicious cyber threats.
Offering
For highly compute-intensive industrial, aerospace, and defense applications, the CHAMP-XD1 processor card provides Trusted computing features alongside leading-edge processing technology for unmatched performance. High performance processing proven foundation for machine learning strengthened security capabilities support for today’s leading open standards, this high-performance module, designed for the rigors of digital signal processing (DSP) and emerging machine learning and artificial intelligence applications, delivers incredible processing capability through its 8 or 12-core Intel® Xeon® D processor. The board includes a core function FPGA for critical board functions and general-purpose I/O, and includes a dedicated intelligent platform ,management interface (IPMI) for system monitoring and health. The CHAMP-XD1 combines its processor’s high core count and floating-point performance with the substantial bandwidth and system-enabling features of the VITA 3U OpenVPX form-factor. Providing an extended temperature Intel® Xeon® D processor with 8 or 12 cores, the CHAMP-XD1 has a peak performance of 410 GFLOPS or 576 GFLOPS respectively. This is coupled with 16 or 32 GB of high capacity DDR4-2133 with a bandwidth of >17 GBps per channel with two channels per processor.
Offering
Optimal for high-performance embedded computing (HPEC), general processing, and a variety of C5ISR applications, the VPX3-1260 rugged 3U OpenVPX single board computer (SBC) delivers a fully-featured, all-in-one processing solution for your embedded system. Aligned with the SOSA™ technical standard, this powerful board features the 9th Gen Intel® Xeon® processor. The robust VPX3-1260 leverages the six-core Intel® processor and 10G and 40G Ethernet connectivity, providing customers with faster data transfer and higher network productivity than ever before. Its local NVMe SSD storage provides a 3-5x improvement in performance and up to 16x capacity over traditional SATA SSD interfaces.T he VPX3-1260 offers the latest Intel® Trusted Computing features, such as Intel® Boot Guard and UEFI Secure Boot, along with secured run-time software enclaves like Intel® Software Guard Extensions (SGX). Implemented as part of our TrustedCOTS Trusted Boot security framework, the VPX3-1260’s security protections help safeguard your system against physical and remote threats.
Offering
Curtiss-Wright’s CHAMP-XD2 offers higher compute density per slot allowing Intel® architecture into the most rugged environments. Our advanced designs allow you to take advantage of mainstream cooling methodologies with advanced techniques and proven tools from the high-performance computing, giving you the power and size you need with less risk and associated costs. The 6U OpenVPX Intel® Xeon® D DSP is available in a range of ruggedized configurations to deliver optimal performance in the harshest deployed environments, including air-cooled and conduction-cooled variants. There is also resident a core Function field programmable gate array (FPGA) used for Trusted COTS security and general-purpose I/O in addition to a dedicated Intelligent Platform Management Interface (IPMI) FPGA used for system monitoring and health.
Offering
The MPMC-932x system is equipped with unprecedented processing power, and provides all of the necessary elements required of modern mission computers including a full selection of standard and optional I/O. The MPMC-932x has the capability to accommodate up to two SBCs (or one SBC and one mezzanine carrier card) and support up to two XMC cards. If you need customization of this system to your program requirements, learn more about our system integration and program management services. Curtiss-Wright SBCs supported include Intel® Xeon®-based 3U VPX cards such as the VPX3-1260 or CHAMP-XD1.
Offering
The Data Transport System (DTS1) is a rugged Network Attached Storage (NAS) file server for use in Unmanned Aerial Vehicles (UAV), Unmanned Underwater Vehicles (UUV), and Intelligence Surveillance Reconnaissance (ISR) aircraft. The DTS1 is easily integrated into network centric systems providing an easy to use, turnkey, rugged network File Server. The DTS1 system houses one Removable Memory Cartridge (RMC) that provides quick off load of data. The RMC can be easily removed from one DTS1 and installed into any other DTS1 providing full data transfer, seamlessly between one or more networks in separate locations (e.g. ground => vehicle => ground). DTS1 Applications Deployed network-centric systems Mobile data loader Remote embedded client boot Flight test instrumentation
