Scalable FPGA Design

Need something Faster? Bigger? More Features? Learn how to scale designs between the Agilex 3 and Agilex 5 families.

Agilex™ 3 FPGA and SoC FPGA

Bringing high performance and power to cost-optimized and compact form factor FPGAs, which enables innovators to reach the next level of performance for their optimized designs.​

Download the Agilex 3 FPGA Product Table ›​

Read the Agilex 3 FPGA Product Brief ›

Read the Power and Cost-Optimized Devices Portfolio Product Brief ›

Get started with the design journey ›

  • Overview
  • Documentation
  • Design Hub

Optimized for Cost-Effective and Space-Efficient Designs

Up to

1.9X

higher fabric performance1

Up to

38%

lower total power1

Up to

12.5Gbps

transceivers​

Up to

1.9X

higher fabric performance1

Up to

38%

lower total power1

Up to

12.5Gbps

transceivers​

Benefits

Upgraded Performance

Agilex 3 brings the high-performance Hyperflex™ FPGA architecture to power and cost-optimized applications. With 12.5 Gbps transceivers, 1.25 Gbps low-voltage differential signaling (LVDS), and 2.5G MIPI D-PHY, which improves system bandwidth, your data can get into and out of the FPGA, reducing data bottlenecks.

Higher Integration

AI-optimized DSPs with tensor blocks and hardened IP blocks deliver robust capabilities in a single chip while supporting dual ARM* Cortex*-A55 cores. Utilizing innovative variable pitch BGA packaging technology enables these capabilities while maintaining low-cost manufacturing PCB design rules.

Security and Reliability

Secure your design with SHA-384 bitstream integrity, ECDSA 256/384 bitstream authentication, AES-256, PUF key, side-channel attack resistance, SPDM attestation, cryptographic services, and physical anti-tamper support.

Show more Show less

Use Cases and Applications

Industrial

  • AI in Smart Factory
  • Smart Factory Automation
  • Sensors/motors/connectivity, functional safety, and security
  • I/O modules and IoT devices
  • Tiny PLC and Edge AI

Surveillance, Retail, Consumer

  • Smart city/retail, V2X​
  • Trucks, bus systems, trains and railways, EV charging​
  • Vision processing​

Video Processing

  • Connectivity and video processing​
  • Video over IP​
  • Consumer electronics​ (AR/VR, Drones, Gaming)

Medical

  • Diagnostic imaging & video​
  • Patient monitoring​

Show more Show less

Key Features

Enhanced DSP with AI Tensor Block

Offers up to 2.8 peak INT8 TOPS with FPGA AI Suite support to enable push-button flow from industry standard frameworks to FPGA bitstream.

Transceivers​

The GTS transceiver supports data rates up to 12.5 Gbps. It integrates hard IP support for PCIe 3.0 x4 and 10GbE, reducing design time and on-chip resources required.

SDM (Secure Device Manager)

Offering key security features such as secure boot, AES encryption, and FPGA configuration management, which runtime sensors and tamper detection, providing ensure authenticated FPGA configuration, support bitstream encryption, and manage enhanced protection against unauthorized access and data integrity threats.

Show more Show less

Want to Learn More?

For documentation and product information, contact our sales team.​

Contact us

Related Links

Agilex™ 3 FPGAs and SoCs Product Brief​

Agilex™ 3 FPGAs and SoCs Device Overview

FPGA Community​

Additional Resources

Explore more content related to Altera® FPGA devices such as development boards, intellectual property, support and more.

Support resources icon

Support Resources

Resource center for training, documentation, downloads, tools and support options.

Development boards

Development Boards

Get started with our FPGA and accelerate your time-to-market with Altera-validated hardware and designs.

Intellectual property

Intellectual Property

Shorten your design cycle with a broad portfolio of Altera-validated IP cores and reference designs.

Design tools

FPGA Design Software

Explore Quartus Prime Software and our suite of productivity-enhancing tools to help you rapidly complete your hardware and software designs.

Contact sales

Contact Sales

Get in touch with sales for your Altera® FPGA product design and acceleration needs.

Where to buy

Where to Buy

Contact an Altera® Authorized Distributor today.

Compare Products

Product and Performance Information

1

Performance varies by use, configuration and other factors. Learn more at www.intel.com/PerformanceIndex​. Performance results are based on testing as of dates shown in configurations and may not reflect all publicly available ​updates. See backup for configuration details. No product or component can be absolutely secure. Your costs and results may vary.
