Offerings
Offering
Deep Micro-ATX (10.4" x 10.5") .Supports 4th Gen Intel® Xeon® Scalable processors, 8 DDR5 DIMM slots (1DPC), 4 PCIe5.0 / CXL1.1 x16 • 2 MCIO (PCIE5.0 / CXL1.1 x8) .Supports 1 M.2 (PCIe3.0 x4 or SATA 6Gb/s), 9 SATA 6Gb/s, 2 RJ45 (10GbE) by Intel® X550-AT2, remote management (IPMI).
Offering
．Half-width (6.6” x 17”)．Supports 3rd Gen Intel® Xeon® Scalable Processors．8 DIMM slots (1DPC), supports DDR4 RDIMM, LRDIMM, and Intel® Optane™ Persistent Memory．2 high-density PCIe4.0 x16．2 SlimSAS (PCIe4.0 x8), 2 OCuLink (PCIe3.0 x4 or 4 SATA 6Gb/s)．2 M.2 (PCIe3.0 x4 or SATA 6Gb/s)．Up to 11 SATA 6Gb/s．1 OCP NIC 3.0 (PCIe4.0 x16)．Remote management (IPMI)
Offering
Proprietary (16.53" x 13.79")Supports 3rd Gen Intel Xeon Scalable Processors16+16 DIMM slots (2DPC), supports DDR4 RDIMM, LRDIMM, and Intel Optane™ Persistent Memory12 SlimSAS (PCIe4.0 x8), 4 low-profile SlimSAS (PCIe4.0 x8), 1 SlimSAS (2 PCIe3.0 x4 or 8 SATA 6Gb/s)2 M.2 (PCIe3.0 x4 or SATA 6Gb/s)Up to 10 SATA 6Gb/s2 RJ45 (10GbE) by Intel X710-AT2Remote management (IPMI)
Offering
．EEB (12.2” x 13.12”)．Supports 3rd Gen Intel® Xeon® Scalable Processors．8+8 DIMM slots (1DPC), supports DDR4 RDIMM, LRDIMM, and Intel® Optane™ Persistent Memory．3 PCIe4.0 x16, 1 PCIe4.0 x8．3 SlimSAS (PCIe4.0 x8)．2 M.2 (PCIe3.0 x4 or SATA 6Gb/s)．Up to 8 SATA 6Gb/s．2 RJ45 (1GbE) by Intel i210．Remote management (IPMI)
Offering
．ATX (12” x 9.6”)．Supports 3rd Gen Intel® Xeon® Scalable Processors．8 DIMM slots (1DPC), supports DDR4 RDIMM, LRDIMM, and Intel® Optane™ Persistent Memory．4 PCIe4.0 x16, 3 PCIe4.0 x8．2 M.2 (PCIe3.0 x4 or SATA 6Gb/s)．Up to 10 SATA 6Gb/s．2 RJ45 (10GbE) by Intel X710-AT2, 2 RJ45 (1GbE) by Intel i210．Remote management (IPMI)
Offering
．L-shape (18.86” x 17.01”)．Supports 3rd Gen Intel® Xeon® Scalable Processor．16+16 DIMM slots (2DPC), supports DDR4 RDIMM, LRDIMM, and Intel® Optane™ Persistent Memory．2 PCIe4.0 x24, 1 PCIe4.0 x16．6 SlimSAS (PCIe4.0 x8)．1 M.2 (PCIe3.0 x4 or SATA 6Gb/s)．Up to 14 SATA 6Gb/s．1 OCP NIC 3.0 (PCIe4.0 x16)．Remote management (IPMI)
Offering
．Half-width (6.5” x 20”)．Supports 3rd Gen Intel® Xeon® Scalable Processors．8+8 DIMM slots (1DPC), supports DDR4 RDIMM, LRDIMM, and Intel® Optane™ Persistent Memory．1 high-density PCIe4.0 x24, 1 high-density PCIe4.0 x16．2 SlimSAS (PCIe4.0 x8)．1 M.2 (PCIe3.0 x4)．3 SATA 6Gb/s: 1 SATA 7-pin, 2 SATA Airmax．2 RJ45 (10GbE) by Intel X710-TM4, 2 SFP+ (10GbE) by Intel X710-TM4．Remote Management (IPMI)
Offering
．EEB (12” x 13”)．Supports 3rd Gen Intel® Xeon® Scalable Processors．16 DIMM slots (2DPC), supports DDR4 RDIMM, LRDIMM, and Intel® Optane™ Persistent Memory．2 PCIe4.0 x16．4 SlimSAS (PCIe4.0 x8)．2 M.2 (PCIe3.0 x2 or SATA 6Gb/s)．Up to 14 SATA 6Gb/s．1 OCP NIC 3.0 (PCIe4.0 x16), 1 OCP 2.0 connector A and B (PCIe3.0 x16)．Remote management (IPMI)
Offering
． m-ITX (6.7" x 6.7") ． Supports Intel® Xeon® E-2300 and Pentium® Series Processors ． 4 DIMM slots (2DPC), supports DDR4 ECC/non-ECC SODIMM Memory ． 1 PCIe4.0 x16 ． Supports 2 OCuLInk (PCIe3.0 x4 or 4 SATA 6Gb/s) ． Supports 1 M.2 (PCIe4.0 x4) ． 8 SATA 6Gb/s ． 2 RJ45 (10GbE) by Intel® X550 ． Supports ATX PSU or 12V DC-in ． Remote Management (IPMI)
Offering
． Micro-ATX (9.6" x 9.6") ． Supports Intel® Xeon® E-2300 and Pentium® Series Processors ． 4 DIMM slots (2DPC), supports DDR4 ECC/non-ECC UDIMM Memory ． 1 PCIe4.0 x16, 1 PCIe4.0 x4, 1 PCIe3.0 x1 ． Supports 1 M.2 (PCIe3.0 x4 or SATA 6Gb/s), 1 M.2 (PCIe3.0 x4) ． 8 SATA 6Gb/s ． 2 RJ45 (10GbE) by Intel® X710-AT2 ． 2 RJ45 (1GbE) by Intel® i210 ． VGA, HDMI, Remote Management (IPMI)
Offering
Micro-ATX (9.6" x 9.6") Supports Intel ® Xeon ® E-2300 and 10th Gen Intel ® Pentium ® series processors 4 DIMM slots (2DPC), supports DDR4 ECC/non-ECC UDIMM 1 PCIe4.0 x16, 1 PCIe4.0 x4, 1 PCIe3.0 x1 Supports 1 M.2 (PCIe3.0 x2 or SATA 6Gb/s) 6 SATA 6Gb/s 2 RJ45 (10GbE) by Intel ® X710-AT2 VGA, HDMI Remote Management (IPMI)
Offering
． m-ITX (6.7" x 6.7") ． Supports Intel® Xeon® E-2300 and Pentium® Series Processors ． 2 DIMM slots (1DPC), supports DDR4 ECC/non-ECC UDIMM Memory ． 1 PCIe4.0 x16 ． Supports 2 OCuLink (PCIe3.0 x4 or 4 SATA 6Gb/s) ． Supports 1 M.2 (PCIe4.0 x4) ． 8 SATA 6Gb/s ． 1 RJ45 (1GbE) by Intel® i210 ． 1 RJ45 (1GbE) by Intel® i219-LM ． Supports ATX PSU or 12V DC-in ． Remote Management (IPMI)
Offering
． Deep mini-ITX (6.7" x 8.2") ． Supports Intel® Xeon® E-2300 and Pentium® Series Processors ． 4 DIMM slots (2DPC), supports ECC/non-ECC UDIMM Memory ． 1 PCIe4.0 x16 ． Supports 2 OCuLink (PCIe3.0 x4 or 4 SATA 6Gb/s), 1 OCuLink (PCIe3.0 x4) ． Supports 1 M.2 (PCIe4.0 x4), 1 M.2 (PCIe3.0 x4) ． 8 SATA 6Gb/s ． 2 RJ45 (10GbE) by Intel® X710-AT2 ． Supports ATX PSU or 12V DC-in ． Remote Management (IPMI)
