COMe-cWL6 (E2S)
COMe-cWL6 (E2S)
About this offer
COM EXPRESS® COMPACT TYPE 6 WITH 8TH GENERATION INTEL® CORE™ / CELERON® PROCESSORSSPECIFICATIONSUp to 24 GByte DDR4 memory (8 GByte DDR4 memory down)Optional NVMe SSD onboardIndustrial grade versionsKontron APPROTECT security solution based on Wibu-Systems CodeMeter® COM Express® Compact Type 6 with 8th Generation Intel® Core™ / Celeron® ProcessorsKontron now offers a total of four new Intel® processor variants for the Kontron COMe-cWL6 (E2S) module:Intel® Core™ i7-8665UE, 4x 1.7 GHz, GT2, 15 WIntel® Core™ i5-8365UE, 4x 1.6 GHz, GT2, 15 WIntel® Core™ i3-8145UE, 2x 2.2 GHz, GT2, 15 WIntel® Celeron® 4305UE, 2x 2.0 GHz, GT1, 15 WThe new Kontron COMe-cWL6 (E2S) modules allow up to 24 GB of DDR4 memory; optionally they are available in Compact format with fast NVMe SSD for the first time. The new COMe is also ideally suited for harsh operating conditions in industrial environments. For example, rugged modules are available that can be used within a temperature range from -40°C to +85°C. The option with a soldered main memory (memory down) of up to 8 GB DDR4 ensures even more robustness. Kontron will also offer a screened E2 variant.The COMe-cWL6 is ideally suited as a powerful successor for existing solutions, as it takes over their pin assignment and feature implementation. Typical applications include communication, digital signage, professional gaming and entertainment, medical imaging, surveillance and security, industrial edge computing as well as industrial plant-, machine- and robot-control at the shop floor level and/or from the control room. The new COM Express® Compact modules support the Kontron APPROTECT security solution based on Wibu-Systems CodeMeter®. Kontron APPROTECT Licensing also enables new business models such as 'pay-per-use' and time-based trial versions.
Details
Availability and Pricing
Mass Production Schedule: 2019-07-04
Working Sample Schedule: 2019-07-04
Minimum Order Quantity (Unit): 1
Order Lead Time (Days): 120
Regional Coverage
Americas:
North America Region
Latin America Region
Asia, Pacific, and Japan:
Japan
Rest of Asia
People's Republic of China:
People's Republic of China
Use Case
High Performance Computing
Digital Security Surveillance
Industry
Health and Life Sciences
Arts and Entertainment
Manufacturing
Agriculture
Automotive
Retail
Transportation and Warehouse
Technical Specifications
- Category:
- Component: Board: COM Express
Included Intel Technology
Intel® Celeron® Processor
Intel® Celeron® Processor 4000 Series
Intel® Core™ Processors
8th Generation Intel® Core™ i7 Processors
8th Generation Intel® Core™ i3 Processors
8th Generation Intel® Core™ i5 Processors
