About this offer
FormfactorCOM Express MiniCPUIntel® Atom™ x7-E3950 (4 x 1.6 / 2.0 GHz, 2MB L2 cache, 12W)Intel® Atom™ x5-E3940 (4 x 1.6 / 1.8 GHz, L2 cache 2MB, 9W)Intel® Atom™ x5-E3930 (2 x 1.3 / 1.8 GHz, L2 cache 1MB, 6.5W)Intel® Pentium® N4200 (4 x 1.1 / 2.5 GHz, L2 cache 2MB, 6W)Intel® Celeron® N3350 (2 x 1.1 / 2.4 GHz, L2 cache 1MB, 6W)DRAMDual channel onboard DDR3L memory support for up to 8 GByte at 1866MT/sChipsetIntegrated in SoCEthernetIntel® I210 (Industrial) / I211 (Commercial) Gigabit Ethernet ControllerI/O Interfaces4 x PCIe Gen22 x USB 3.06 x USB 2.02 x SATA3SDIOLPC busSM-BusI²C bus2 x UARTSoundHigh Definition Audio InterfaceGraphicsIntel® HD Graphics Gen 9 | PAVP 2.0 | H.265/HEVC | VP9 | OpenCL 2.0 | OpenGL 4.3 | OpenGL ES 3.0 | DirectX12 | HDCP1.4congatec Board ControllerMulti Stage Watchdog | non-volatile User Data Storage | Manufacturing and Board Information | Board Statistics | LVDS backlight control I²C bus (fast mode, 400 kHz, multi-master) | Power Loss Controlembedded BIOS FeaturesAMI AptioV® UEFI 2.x firmware8 MByte serial SPI firmware flashOEM LogoOEM CMOS DefaultsLCD ControlDisplay Auto DetectionBacklight ControlFlash UpdateSecurityInfineon’s Trusted Platform Module (TPM 2.0/1.2) SLB 9665/9660 optionPower ManagementACPI 5 .0 compliant, Smart Battery ManagementOperating SystemsMicrosoft® Windows 10 EnterpriseMicrosoft® Windows IoT CoreLinuxAndroidPower ConsumptionTyp. application <10 WattTyp. application <10 W @ 5 V, CMOS Battery BackupTemperatureStandard Operating: 0 to +60°CStorage: -20 to +80°CHumidityOperating: 10 to 90% r. H. non cond. / Storage 5 to 95% r. H. non cond.Size55 x 84 mm (2.17" x 3.31")
Availability and Pricing
Minimum Order Quantity (Unit): 10
Order Lead Time (Days): 30
North America Region
Latin America Region
Asia, Pacific, and Japan:
Rest of Asia
People's Republic of China:
People's Republic of China
Digital Security Surveillance
Health and Life Sciences
- Component: Board: COM Express
Included Intel Technology
Intel® Pentium® Processor
Intel® Pentium® Processor N Series
Intel® Celeron® Processor
Intel® Celeron® Processor N Series
Due to a technical difficulty, we were unable to submit the form. Please try again after a few minutes. We apologize for the inconvenience.
Your registration cannot proceed. The materials on this site are subject to U.S. and other applicable export control laws and are not accessible from all locations.
The recaptcha has identified the current interaction similar to a bot, please reload the page or try again after some time.
congatec AG offers a product portfolio that is comprised of embedded computer modules based on the most common form factors such as Qseven, COM Express and ETX/XTX. congatec also provides professional board support packages, extensive design-in support and specialized embedded BIOS features for industrial use.
Your request for information has been successfully sent to CONGATEC AG
