4.1. Median Filter Design Example

The Median filter is a non-linear filter that removes impulsive noise from an image. These filters require the highest performance. The design requirement is to perform real time image processing on a factory floor.

You can find the supporting design example project and design files for this walk-through at https://www.intel.com/content/dam/www/programmable/us/en/others/literature/tt/median_filter_17_1.zip. You can download and unzip the verified project, constraint, design, RTL from the median.zip to complete this walkthrough.

Figure 97. Before and After Images Processed with Median Filtering

Median Filter Design Example Files

After download and extraction, the Median filter design example .zip file contains the following directories under the Median_filter_design_example_<version> directory:

Table 9.  Median Filter Design Example Files
File Name Description
Base Contains the original version of the design and project files.
Final Contains the final version of the design and project files with all RTL optimizations in place.
fpga-median.ORIGINAL Contains the original OpenSource version of the Median filter and the associated research paper.
Step_1 Incremental RTL design changes and project files for Fast Forward optimization step 1.
Step_2 Incremental RTL design changes and project files for Fast Forward optimization step 2.

This walk-through covers the following steps:

  1. Step 1: Compile the Base Design
    Follow these steps to compile the base design of the median project:
  2. Step 2: Add Pipeline Stages and Remove Asynchronous Resets
    This first optimization step adds five levels of pipeline registers in the design locations that Fast Forward suggests, and removes the asynchronous resets present in a design module. Adding additional pipeline stages at the interconnect between the ALMs eliminates some of the long routing delays. This optimization step increases fMAX performance to the level that Fast Forward estimates.
  3. Step 3: Add More Pipeline Stages and Remove All Asynchronous Resets
    The Fast Forward Timing Closure Recommendations suggest further changes that you can make to enable additional optimization during retiming. The Optimizations Analyzed tab reports the specific registers in the analysis for you to modify. The report indicates that state_machine.v still contains asynchronous resets that limit optimization. Follow these steps to remove remaining asynchronous resets in state_machine.v, and add more pipeline stages:
  4. Step 4: Optimize Short Path and Long Path Conditions
    After removing asynchronous registers and adding pipeline stages, the Fast Forward Details report suggests that short path and long path conditions limit further optimization. In this example, the longest path limits the fMAX for this specific clock domain. To increase the performance, follow these steps to reduce the length of the longest path for this clock domain.
The paper An FPGA-Based Implementation for Median Filtering Meeting the Real-Time Requirements of Automated Visual Inspection Systems first presented this design at the 10th Mediterranean Conference on Control and Automation, Lisbon, Portugal, 2002. The design is publicly available under GNU General Public License that the Free Software Foundation publishes.
